D BELT CLIPS
• MB-86
swivel belt clip
• MB-96N/MB-96F
• MB-98

belt clip

Exclusive alligator-type belt clip.
NOTE: In a hazardous area, you can use only the MB-98.
D OTHER OPTIONS
• HM-138/HM-168/HM-169/HM-170GP
HM-138 : Full-sized speaker-microphones. The HM-138 is water-
proof protection*. When it is connected, the transceiver's
waterproof rating is equivalent to IPX7.
HM-168 : Compact type speaker-microphone. The HM-168 meets
IPX7 requirements for waterproof protection*. When it is con-
nected, the transceiver corresponds to IPX7.
HM-169 : Rugged type speaker-microphone.
HM-170GP : GPS speaker-microphone for BIIS mode operation.
The HM-169/HM-170GP meet IP57 requirements for
dust-protection and waterproof protection*. When either
speaker-microphone is connected, the transceiver corre-
sponds to IPX7.
* Once these items have been dropped, the IP rating or waterproof protection can-
not be guaranteed because of possible damage to these cases or the waterproof
seals.
NOTE: In a hazardous area, you can use only the HM-138.
• OPC-966
interface cable
Provides advanced operation, such as printer, GPS connection for posi-
tion data transmission capabilities during BIIS operation.
• FA-S24V/FA-S59V/FA-S27U/FA-S56U/FA-S74U
FA-S24V: 136–150 MHz
FA-S27U: 400–470 MHz
Approved Icom optional equipment is designed for optimal performance when
used with an Icom transceiver. Icom is not responsible for the destruction or dam-
age to an Icom transceiver in the event the Icom transceiver is used with equip-
ment that is not manufactured or approved by Icom.
Some options may not be available in some countries. Please ask your dealer
for details.
leather belt hanger
s
-
speaker microphones
antennas
FA-S59V: 150–174 MHz
FA-S56U: 450–520 MHz
8

OPTIONS
