Options - Icom IC-F61M Instruction Manual

8
D BATTERY PACK/CASE
• BP-226
battery case
Battery case for 5 × AA (LR6) alkaline cells. The BP-226 meets IPX4
requirements for splash resistance*. When it is connected, the trans-
ceiver corresponds to IPX4.
• BP-227/BP-274
Voltage
Capacity : BP-227; 1850 mAh (minimum)/1950 mAh (typical)
BP-227/BP-274 must be charged with the optional charger.
D CHARGERS
• BC-152
desktop charger
Used for regular charging of the battery pack. The power adapter must
be purchased separately.
Charging time: Approximately 9 to 10 hours for BP-274.
• BC-190
desktop charger
Used for rapid charging of the battery pack. The power adapter is not
supplied with some versions.
Charging time: Approximately 2.5 to 4.25 hours for BP-274.
• BC-119N
Used for rapid charging of battery packs. The power adapter is not
supplied with some versions.
Charging time: Approximately 2 to 2.5 hours for BP-274.
• BC-121N
BC-157S
Used for rapid charging of up to 6 battery packs (six AD-100's are
required) simultaneously. A power adapter should be purchased sepa-
rately.
Charging time: Approximately 2 to 2.5 hours for BP-274.
39

OPTIONS

-
i ion
l battery packs
: 7.4 V
BP-274; 1800 mAh (minimum)/1900 mAh (typical)
desktop charger
+ AD-100
-
multi charger
ac adapter
+ BC-147S
ac adapter
+ BC-123S
ac adapter
+ AD-100
charger adapter
charger adapter
+ BC-145S
ac adapter
(6 pcs.) +
