How to Connect

Before starting, make sure that the projector and computers are both

turned off.

1. Connect the computer cable.

1.1 Connect either end of the computer cable to the projector's

1.2 Disconnect the monitor cable from the computer and connect the

1.3 If needed, connect the monitor cable of the computer monitor to

1.4

.Connect the audio cable if necessary.

2.1 Connect one end of the audio cable to the Audio in jack on the

2.2 Connect the other end of the audio cable to the audio output port on

Downloaded From projector-manual.com Boxlight Manuals

computer 1/ computer port.

other end of the terminal where the monitor cable is disconnected

from the computer.

the projector's Computer out.

Tighten the screw on all connectors.

projector.

the computer sound card.

Multimedia LCD Projector

-27-
