Functions of Menu (OSD)

Keypad Operating:

1.
2.
BLANK: Blanks the projected image. If the projector is left in Blank
mode for more than 15 minutes, the projector will automatically shut
off the lamp and enter cool-down mode.
3.
AUTO: Automatically adjusts the settings to match the current input.
4.
SOURCE: Selects VIDEO or PC input source.
5.
MENU: Enter or exit the main menu (Show and hide the OSD)
6.
Menus.
Keystone
7.
buttons.
**There is a "Quick Key" on the remote control and projector keypad
as well.
**Press the "Volume" button on remote control, you can adjust value, and
select between Brightness – Contrast – Keystones – Volume directly.
There is the same function for pressing the
Downloaded From projector-manual.com Boxlight Manuals
1. Power 1. Power
7. Keystone 7. Keystone
5. Menu 5. Menu
2. Blank 2. Blank
: Turn on and turn off the projector
: Up / Down arrow buttons, used to navigate through the OSD
: Right / Left arrow buttons, used to select and adjust OSD Menu
functions.
: Adjusts the vertical keystone with the right and left arrow
Multimedia LCD Projector
6. Menu-left/ right, 6. Menu-left/ right,
Menu-up/down Menu-up/down
5.Auto
3. Input 3. Input
button on the keypad
