BOXLIGHT Beacon CP720e User Manual

Hide thumbs Also See for Beacon CP720e:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Digital Multimedia Projector
About User's manual
Features
The content of this manual is subject to change without period notice.
All rights reserved.
Downloaded from ProjectorsManual.com Manuals
Multimedia LCD Projector
Thank you for purchasing the LCD projector.
Please read this user's manual thoroughly to ensure
correct usage of the projector and its features.
After reading, store this instruction manual in
a safe place for future reference.
1. Design with 3LCD optical system, provide you:
Bright image, natural color, smooth video playback
and gentle for your eyes.
2. Support Dynamic Contrast and 3D Comb Filter,
great for home theater use.
3. Auto V keystone function, +/- 30 degrees.
4. Auto brightness control.
5. Auto ceiling function.
6. Support YPbPr signal.
-1-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Beacon CP720e and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BOXLIGHT Beacon CP720e

Summary of Contents for BOXLIGHT Beacon CP720e

  • Page 1 Multimedia LCD Projector Digital Multimedia Projector About User’s manual Thank you for purchasing the LCD projector. Please read this user’s manual thoroughly to ensure correct usage of the projector and its features. After reading, store this instruction manual in a safe place for future reference. Features 1.

  • Page 2: Table Of Contents

    Multimedia LCD Projector Table of Contents Safety Instructions………………………………………………………04 Checking the Package Content….…………...……………………...….10 Before Use Names and Function of Each Part Main Unit..........………………………….…..11 Keypad Control ....……......………………………… 13 Rear View I/O Board ......……………..….……………15 Bottom View........………………………….…..17 Remote Control…........……………………….…….18 Inserting the batteries ........………………………19 Remote Control…........……………………….…….20 Inserting the batteries ....
  • Page 3 Multimedia LCD Projector Basic Operation Turning on the projector………………………………..…….………..31 Adjusting the screen image……………….……………………...…….33 Turning off the power…………….………………………………...….34 Function of Menu (OSD) Keypad operating…………………………………………..…………..35 Computer mode……………………………………………..……….…36 Video mode………………….……………………………..…………..42 Maintenance and Troubleshooting Ceiling Mounted Installation Guide……………………………………48 Cleaning the Projector/Lens……...………………….……..…………..49 Cleaning air filter…………………………………….…..….…………50 Lamp replacement………….……………………….……………….…51 Indicators…………………………………….…………….….………..52 List of Support Displays Modes…………………………..………..……53...
  • Page 4 Multimedia LCD Projector About the symbols Various symbols are used in this instruction manual and on the product itself to ensure correct usage, to prevent danger to the users and others, and to prevent property damage. The meanings of these symbols are described below.
  • Page 5 Multimedia LCD Projector Warning If a problem should occur If smoke or strange odors arise, continued use could result in fire or electrical shock. In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet. After making sure that the smoke or odor has stopped, contact your dealer for repairs.
  • Page 6 Multimedia LCD Projector Warning Do not look through the lens when the lamp is on. Never look through the lens when the lamp is on. The powerful light could adversely affect vision. Use special caution in households where children are present. Avoid shock or impact on the projector.
  • Page 7 Multimedia LCD Projector Caution Placing heavy objects on top of this projector could result in loss of balance or falling and cause personal injury or damage the projector. Do not block the ventilation openings. Do not block the ventilation openings of this projector. Blocking ventilation could lead to internal overheating which could result in fire.
  • Page 8 Multimedia LCD Projector Caution Avoid installation in humid or dusty locations. Do not install this projector in a humid or dusty location. This could result in fire or electrical s hock. Do not handle the power cord roughly. Keep the power cord away from heaters; the heat could melt the power cord and cause fire or electrical shock.

  • Page 9: Location Of Product Safety Labels

    Multimedia LCD Projector Location of product safety labels Safety labels are used on or within the projector to alert you to items or areas requiring your attention. WARNING Business card Business card LCD Projector LCD Projector Model: Model: Input: Input: Downloaded from ProjectorsManual.com Manuals...

  • Page 10: Checking The Package Content

    Multimedia LCD Projector Checking the Package Contents □Projector □Remote Control □Remote Control ( included battery) ( included battery) I NPU T MENU A uto K eyst one St il l Bl ank □Power Cord □S-Video □Video Cable □Computer cable □Speaker Cable □Audio Cable □USB Cable □RS232 (Optional)
  • Page 11 Multimedia LCD Projector 3. Front IR receiver When using the remote control, point the remote control at this sensor. 4.Filter cover Prevents dust and other foreign particles from being drawn into projector. Remove the Filter cover to clean the air filter. 5.Front adjustable foot Extend and retract to adjust the projection angle 6.Foot adjust button...

  • Page 12: Main Unit

    Multimedia LCD Projector Part Names and Function: Main Unit 8.Control panel 8.Control panel Outlet ventilation Outlet ventilation 4.Filer cover( bottom) 4.Filer cover( bottom) 5.Speaker 1.Zoom ring 1.Zoom ring 2.Focus ring 2.Focus ring 7.Lens cover 7.Lens cover 6.Foot adjust button 6.Foot adjust button 3.Front IR receiver 3.Front IR receiver 5.Front adjustable foot...

  • Page 13: Keypad Control

    Multimedia LCD Projector Keypad control 8. Power indicator 8. Power indicator 9. Lamp indicator 9. Lamp indicator 1. Power 1. Power 6. Menu-left/ right, 6. Menu-left/ right, Menu-up/down Menu-up/down 7. Keystone 7. Keystone 5. Menu 5. Menu 4.Auto 3. Blank 3.
  • Page 14 Multimedia LCD Projector 4. Auto Automatically adjusts the setting to match the current input. 5. Menu Display or hides the OSD main menu page. 6.Menu-up /down, Menu-right / left Selecting OSD menu item up or down / Selecting and adjusting the function of OSD menu item 7.

  • Page 15: Rear View I/O Board

    Multimedia LCD Projector Rear View / IO Board 1. Computer in 1 Input Analog RGB video signal from a computer 2. Computer in 2 Analog RGB signal from a computer or YPbPr signal from a video source. System will auto detect YPbPr or RGB signal in computer in 2 port. 3.
  • Page 16 Multimedia LCD Projector 4. Control (RS-232C) Serial data port for controlling the projector with a computer or other RS-232 control device. 5. S-Video connector S-Video signal from a video source. 6. Video in Component video signal from a video source. 7.

  • Page 17: Bottom View

    Multimedia LCD Projector Bottom View 1. Suspension bracket fixing points(4) Front adjustable foot Front adjustable foot 2.Air filter cover Business card EMI label Lamp label 1. Suspension bracket fixing points(4) 1. Suspension bracket fixing points (4 points) Install the optional ceiling mount here when suspending the projector from the ceiling.
  • Page 18 Multimedia LCD Projector Remote Control (type 1) 1. Power 8.Auto Sync Power on / operation Refresh the current mode, Standby mode, INPUT image. Cooling-down mode 9. Menu down/Menu up, 2 Esc Menu left/ Menu right Enters into last status at Selecting and adjusting OSD menu or hides the the function of OSD...

  • Page 19: Remote Control Batteries Installation

    Multimedia LCD Projector Remote Control Batteries Installation 1. Remove the battery cover. 2. Loading the batteries. Make sure the plus and minus poles are correctly oriented. 3. Close the battery cover. Caution Avoid excessive heat and humidity. Do not drop the remote control. Do not expose the remote control to water or moisture, this could result in malfunction.

  • Page 20: Remote Control

    Multimedia LCD Projector Remote Control 1.Power 2.Laser pointer Power on / operation Use laser pointer mode, Stand by mode, from remote control. Cooling-down mode 3.Mouse Left 4.Mouse Right Mouse left Mouse right multipurpose key. multipurpose key. 5.Menu 6.Menu-up / Menu-down Display or hides the Selects OSD menu item up OSD main menu page.

  • Page 21: Inserting The Batteries

    Multimedia LCD Projector Inserting the batteries Loading AAA batteries into the remote control. 1. Remove the battery cover. Push the knob while lifting up the battery cover. 2. Loading the batteries. Make sure the plus and minus poles are correctly oriented. 3.

  • Page 22: Installation

    Multimedia LCD Projector Installation Setting Up the Projector The projector supports the following four different projection methods Front projection Rear A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. -22- Downloaded from ProjectorsManual.com Manuals...
  • Page 23 Multimedia LCD Projector Rear ceiling projection Front ceiling projection A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. -23- Downloaded from ProjectorsManual.com Manuals...

  • Page 24: Screen Size And Projection Distance

    Multimedia LCD Projector Screen Size and Projection Distance The distance between the projector and screen determines the actual image size. Refer to the table below to determine the image size at a given distance.. Distance(M) Image Size (inch) Wide Tele 1.45 33.3 2.21...

  • Page 25: Adjusting The Image Position

    Multimedia LCD Projector Adjusting the Image Position Use the adjustable foot at the front of the projector to set the image height. Rotate the adjustable foot at the rear of the projector to fine-tune the image position. When the foot is adjusted, it may cause the shape of the projected image to become distorted.

  • Page 26: Moving The Projector

    Multimedia LCD Projector Moving the projector 1. Use the carrying handle when moving the projector.(option) 2. Replace the lens cover and retract the front adjustable foot when moving the projector to prevent damage to the projector. Caution The optional carry bag is intended to protect the projector from dust and scratches on the surface of the cabinet.

  • Page 27: How To Connect

    Multimedia LCD Projector How to Connect Before starting, make sure that the projector and computers are both turned off. 1. Connect the computer cable. 1.1 Connect either end of the computer cable to the projector’s computer 1/ computer port. 1.2 Disconnect the monitor cable from the computer and connect the other end of the terminal where the monitor cable is disconnected from the computer.

  • Page 28: Laptop Pc

    Multimedia LCD Projector Laptop PC A PC laptop computer Before beginning, make sure that the projector and computers are both turned off. 1. Connect the computer cable. 1.1 Connect either end of the computer cable to the projector’s computer 1or computer 2 port. 1.2 Connect the other end of the project cable to the monitor out connection on the laptop.

  • Page 29: Usb Mouse

    Multimedia LCD Projector USB Mouse_ USB mouse compatible MS-Window98/2000/NT/XP/Me, Macintosh :OS8.6~10.1, and a Microsoft Mouse driver installed. 1. Insert the end of the USB Cable (B-Type) to the projector’s USB port. 2. Connect the end of the USB Cable (A-type) to the computer’s USB port. 3.

  • Page 30: Video

    Multimedia LCD Projector Video A. Connect to a video source The Projector can receive composite AV ,YPbPr and S-Video. 1 Connect RCA plug at projector and video source ( like DVD player) for video signal. 2 . Connect RCA plug ( white and red) to audio source ( like DVD player) and connect the phone jack to projector for audio signal.

  • Page 31: Turning On The Projector

    Multimedia LCD Projector Turning on the projector Procedure 1. Check the power is turned off for the projector and all components connected to the projector. 2. Remove the lens cover. 3. Connect the power cord to the projector. 4. Turn on the power switch. 5.
  • Page 32 Multimedia LCD Projector 6. The power indicator will flash green. 7. Press the [VIDEO]/[PC] button on the control panel or the Computer/Video buttons on the remote control to select the appropriate source. Power Mouse 8. Use the zoom ring to adjust the screen size. 9.

  • Page 33: Adjusting The Screen Image

    Multimedia LCD Projector Adjust the Screen Image 1. Adjusting the image size Turn the zoom ring on the projector to adjustor to adjust the image 2.Adjusting the image height. Extend or retract the front adjustable foot to adjust the height of the image. 3.Correcting Keystone Distortion Use the [ Keystone] button on the projector's control panel.

  • Page 34: Keypad Operating

    Multimedia LCD Projector Functions of Menu (OSD) Keypad Operating: 1. Power 1. Power 6. Menu-left/ right, 6. Menu-left/ right, Menu-up/down Menu-up/down 7. Keystone 7. Keystone 5. Menu 5. Menu 5.Auto 2. Blank 2. Blank 3. Input 3. Input : Turn on and turn off the projector BLANK: Blanks the projected image.

  • Page 35: Turning Off The Projector

    Multimedia LCD Projector Turning off the projector 1. Press the power button on the projector or r emote control. The power off confirmation message appears .I f you do not wan t to power off the projector, ignore the message and it will disappear. 2.

  • Page 36: Computer Mode

    Multimedia LCD Projector Computer mode 1. PICTURE Brightness 000/100 Adjusts the overall image brightness Contrast 000/100 Adjusts the difference between light and dark areas of the image sharpness 000/006 Adjusts the image sharpness Display mode Select Powerful Enhance brightness Video Keep the soft tender color Presentation For computer presentation use...
  • Page 37 Multimedia LCD Projector 2. AUDIO Volume 000/040 Adjusts the volume Mute On/Off Mutes the volume om/off -37- Downloaded from ProjectorsManual.com Manuals...
  • Page 38 Multimedia LCD Projector 3.SETTING 000/100 Move the image position horizontally H position 000/100 Move the image position vertically V position 000/100 Set the synchronization polarity Phase Frequency 000/100 Set the horizontal scanning frequency Auto keystone Execute Automatically Corrects keystone distortion in image i.e.
  • Page 39 Multimedia LCD Projector -39- Downloaded from ProjectorsManual.com Manuals...
  • Page 40 Multimedia LCD Projector 5.PRESENTATION Auto ceiling On/off Automatically inverts the image when the projector is turned upside down i.e. when the projector is mounted on the ceiling Front Execute Normal projection mode Ceiling Execute Inverts the image vertically, used when the projector is mounted upside down Rear Execute Inverts the image horizontally, used when...
  • Page 41 Multimedia LCD Projector 2. AUDIO Volume 000/040 Adjusts the volume Mute On/Off Mutes the volume om/off -43- Downloaded from ProjectorsManual.com Manuals...
  • Page 42 Multimedia LCD Projector 3.SETTING Auto keystone Execute Automatically Corrects keystone distortion in image i.e. press once to do once -80/+80 Corrects vertical keystone distortion in image Keystone V On/off Search signal source automatically. Auto search -44- Downloaded from ProjectorsManual.com Manuals...

  • Page 43: Video Mode

    Multimedia LCD Projector Video Mode_ 1. PICTURE Brightness 000/100 Adjusts the overall image brightness Contrast 000/100 Adjusts the difference between light and dark areas of the image sharpness 000/006 Adjusts the image sharpness Color 000/100 Adjusts the image color Tint 000/100 Adjusts the image tint Display mode...
  • Page 44 Multimedia LCD Projector 4.ADVANCE Execute digital zoom and pan function Zoom/pan Execute Freezes the current image on the screen. Still On/Off Blank On/Off Hide the image, displays a blank, black screen*(see below) Resets all OSD Menu function to their factory Reset all Execute default values*( see below)
  • Page 45 Multimedia LCD Projector -45- Downloaded from ProjectorsManual.com Manuals...
  • Page 46 Multimedia LCD Projector 5.PRESENTATION Auto ceiling On/off Automatically inverts the image when the projector is turned upside down i.e. when the projector is mounted on the ceiling Front Execute Normal projection mode Ceiling Execute Inverts the image vertically, used when the projector is mounted upside down Rear Execute Inverts the image horizontally, used when...

  • Page 47: Maintenance And Troubleshooting

    Multimedia LCD Projector Maintenance and Troubleshooting Cleaning the projector Warning: Always unplug the projector before performing any maintenance. Clean the projector case by wiping it gently with a soft cloth. If necessary, the case can be cleaned using a neutral detergent and a soft cloth ensure the case is completely dry before turning the projector back on.

  • Page 48: Ceiling Mounted Installation Guide

    Multimedia LCD Projector Ceiling Mounted Installation Guide Attach the optional ceiling mount at four-suspension bracket fixing points when suspending the from a ceiling. *A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for more details. M4*MAX8 For Mount M4*MAX8 For Mount -48-...

  • Page 49: Cleaning The Air Filter

    Multimedia LCD Projector Cleaning the Air Filter A. When the air filter becomes clogged with dust, etc., the projector may overheat and turn itself off to prevent internal damage. When cleaning the filter, stand the projector up on its side to prevent dust from entering the projector.
  • Page 50 Multimedia LCD Projector 4.ADVANCE Zoom/pan Execute Execute digital zoom and pan function Still On/Off Freezes the current image on the screen. Blank On/Off Hide the image, displays a blank, black screen*(see below) Resets all OSD Menu function to their factory Reset all Execute default values*( see below)

  • Page 51: Lamp Replacement

    Multimedia LCD Projector Lamp Replacement Caution: The lamp and inside of the projector become very hot while the projection lamp is lit. Allow the projector to cool for at least 15 minutes prior to opening the lamp door. Lamp Screw Lamp Screw Lamp door Lamp door...

  • Page 52: Indicators

    Multimedia LCD Projector Indicators The Power and Lamp indicators show the status of the projector. Before requesting repair, check the projector status using the chart below. If the problem cannot be resolved contact your dealer. Power (Green) Lamp (Red) Conditions Notes Slow flashing Stand by *Projector is ready to be turned on (normal)
  • Page 53 Multimedia LCD Projector List of Supported Monitor Displays Refresh Signal Resolution Rate (Hz) 640x350 640x480 VGAEGA 640x400 VGA text 720x400 VESA 720x350 VESA 60/72/75/85 640x480 SVGA 56/60/72/75/85 800x600 60/70/75/85 1024x768 SXGA 60/70/75 1280x1024 TV(480i), NTSC TV(575i),PAL -53- Downloaded from ProjectorsManual.com Manuals...
