4. Control (RS-232C)
Serial data port for controlling the projector with a computer
or other RS-232 control device.
5. S-Video connector
S-Video signal from a video source.
6. Video in
Component video signal from a video source.
7. Audio out
Connecting to an external speaker system.
8. Audio in
Stereo mini jack for PC input
9. USB mouse connector
Connects a USB mouse cable to a computer to control
computer mouse functions.
10. Power socket
Connects the power core to this connection.
11. Power switch
Turns the power on/off.
12. Rear IR receiver
When using the remote control, point the remote control
at this sensor.
