BOXLIGHT CP-775i User Manual

Boxlight user's manual multimedia lcd projector cp-775i
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Multimedia LCD Projector
CP-775i
USER'S MANUAL
Please read this user's manual thoroughly to ensure correct usage through understanding.
BEDIENUNGSANLEITUNG
Bitte lessen Sie diese Bedienungsanleitung zugunsten der korrekten Bedienung
aufmerksam.
MANUEL D'UTILISATION
Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le
fonctionnement de l'appareil.
MANUALE D'ISTRUZIONI
Vi preghiamo voler leggere attentamente il manuale d'sitruzioni in modo tale da poter
comprendere quanto riportato ai fini di un corretto utilizzo del proiettore.
MANUAL DE USUARIO
Lea cuidadosamente este manual del usuario para poder utilizar corretamente el
producto.
GEBRUIKSAANWIJIZING
Lees voor het qebruik alstublieft deze handleiding aandachtig door, om volledig profijt te
hebben van de uitgebreide mogelijkheden.
BRUKERHÅNDBOK
Vennligst les denne bruksanvisningen grundig for å være garantert driftssikker bruk.
INSTRUÇÕES DO PROPRIETÁRIO
Para assegurar o uso correto do equipamento, por favor leia atentamente este manual do
usuário.
TECHNICAL

REGULATORY NOTICES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-775i and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BOXLIGHT CP-775i

Summary of Contents for BOXLIGHT CP-775i

  • Page 1: Regulatory Notices

    Multimedia LCD Projector CP-775i USER'S MANUAL Please read this user's manual thoroughly to ensure correct usage through understanding. BEDIENUNGSANLEITUNG Bitte lessen Sie diese Bedienungsanleitung zugunsten der korrekten Bedienung aufmerksam. MANUEL D'UTILISATION Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le fonctionnement de l'appareil.

  • Page 2: Table Of Contents

    Multimedia LCD Projector USER'S MANUAL USER'S MANUAL Thank you for purchasing this LCD projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference.

  • Page 3: Features

    FEATURES FEATURES This liquid crystal projector is used to project various computer signals as well as NTSC / PAL / SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized. Outstanding Brightness The UHB lamp and high-efficiency optical system assure a high level of brightness.

  • Page 4: Part Names

    Control Panel STANDBY/ON Button KEYSTONE Button Foot Adjuster Button Filter Cover Air Filter and Intake for the Cooling Fan REAR/RIGHT VIEW OF THE PROJECTOR S-VIDEO Terminal COMPONENT VIDEO Y Terminal Terminal Terminal VIDEO IN Terminal AUDIO IN R Terminal AUDIO IN L Terminal...

  • Page 5: Remote Control Transmitter

    • Do not place the heavy objects on the remote control transmitter. • Do not wet the remote control transmitter or place it on any wet object. • Do not place the remote control transmitter close to the cooling fan of the projector. • Do not disassemble the remote control transmitter.

  • Page 6: Loading The Batteries

    Loading the Batteries Install the AA batteries into the remote control transmitter. 1. Remove the battery cover. Push the knob while lifting up the battery cover. 2. Load the batteries. Make sure the plus and minus poles are correctly oriented. 3.

  • Page 7: Installation

    • Do not install LCD projector in smoke effected environment. Smoke residue may buildup on critical parts (i.e.LCD panel, Lens Assy etc.). Angle Adjustment Use the foot adjusters on the bottom of the projector to adjust the projection angle. It is variable within 0˚ to 9˚ approximately. Foot Adjusters 1.

  • Page 8: Cabling

    • Before connecting, turn off to all devices to be connected, except for the USB cable. • The cables may have to be used with the core set to the projector side. Use the cables which are included with the projector or specified.

  • Page 9: Power Connection

    Plug & Play This projector is VESA DDC 1/2B compatible. Plug & play is possible by connecting to a computer that is VESA DDC (Display Data Channel) compatible. Please use this function by connecting the RGB cable with RGB IN 1 terminal (DDC 1/2B compati- ble), or by connecting a DVI cable with DVI terminal (DDC 2B compatible).

  • Page 10: Operations

    Incorrect procedure will reduce the life of the projector lamp and LCD panel. • To prevent any trouble, turn on/off the projector when the computer or video tape recorder is OFF. Providing a RS-232C cable is connected, turn on the computer before the projector.

  • Page 11: Basic Operation

    Basic Operation The basic operations shown in Table 3 is performed from the supplied remote control transmitter or the projector control panel. Items indicated by (*) may be used from the control panel. Table 3 . Basic Operation Item Select Input Signal ( RGB IN 1→RGB IN 2→DVI→...
  • Page 12 Items indicated by (*) may be used from the control panel. Table 3. Basic Operation (continued) Item VOLUME Volume Adjustment : Press the VOLUME Set/Clear Mute Mode : Press the MUTE button. No sound is heard in the MUTE MUTE mode. Automatic Adjustment at RGB Input : Press the AUTO button.

  • Page 13: Setup Menu

    Setup Menu The following adjustments and settings are possible when SETUP is selected at the top of the menu. Part of the Setup menu differs between RGB input and video input. Select an item with the buttons, and start operation. Use the Single menu to reduce menu size (see Table 3, MENU SELECT).

  • Page 14: Input Menu

    Input Menu The following functions are available when INPUT is selected on the menu. Select an item with the operation with the effective on video input mode only, not on RGB input mode, except in the P.IN P. window on RGB input mode. Table 5.

  • Page 15: Image Menu

    Image Menu The following adjustments and settings are available when IMAGE is selected on the menu. Select an item with the start or stop operation with the Table 6. Image Menu Item Select Blank Screen: Select the screen in case of the BLANK mode with the button.

  • Page 16: Options Menu

    Options Menu The following adjustments and settings are available when OPT. is selected on the menu. Select an item with the start or stop operation with the Table 7. Options Menu Item VOLUME Reduce MENU COLOR Select Menu Background Color: Select with the Select Menu Display Language: Select with the LANGUAGE Set AUTO OFF: Set 1~99 minutes with the...

  • Page 17: No Signal Menu

    No Signal Menu The same adjustments and settings are available with the Image and Options menus when the MENU button is pressed during display of the “NO INPUT IS DETECTED ON ***” or “SYNC IS OUT OF RANGE ON ***” message while no signal is received.Select an item with the buttons, and start or stop operation with the Table 8.

  • Page 18: Maintenance

    • Do not use the projector with the lamp cover removed. Lamp Life Projector lamps have a finite life. The image will become darker, and hues will become weaker, after a lamp has been used for a long period of time.

  • Page 19: Resetting The Lamp Timer

    Replacing the Lamp 1. Switch the projector OFF, remove the power cord from the power outlet, and wait at least 45 minutes for the unit to cool. 2. Prepare a new lamp. 3. Check that the projector has cooled sufficiently, and gently turn it upside down.

  • Page 20: Air Filter

    Other Maintenance Maintenance Inside the Equipment For safety reasons, ensure that the equipment is cleaned and checked by BOXLIGHT once every two years. Maintaining the equipment by yourself is dangerous. Cleaning the Lens Gently wipe the lens with lens cleaning paper.

  • Page 21: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING OSD Message The messages as described below may appear on the screen at power ON. Take the appropriate measures when such messages appears. Table 9. OSD Message Message CHANGE THE LAMP AFTER REPLACING LAMP, RESET THE LAMP TIME. CHANGE THE LAMP AFTER REPLACING LAMP, RESET THE LAMP TIME.

  • Page 22: Indicators Message

    Switch power OFF, and wait for 45 minutes until the equipment cools. Check fitting of the lamp and lamp cover, and switch power ON again. Contact BOXLIGHT if the same problem occurs again. The cooling fan is not operating. Switch power OFF, and wait for 20 minutes until the equipment cools.

  • Page 23: Symptom

    Symptom Before requesting repair, consult the following chart. If the situation cannot be corrected, then contact BOXLIGHT at 800-762-5757 or 360-779-7901. Table 11. Symptom Symptom The main power switch is not turned on. The power is not turned on. The power cord is disconnected.

  • Page 24: Specifications

    H/V. sync.: TTL level (positive/negative) Composite sync.: TTL level D-sub 15-pin shrink jack 200mVrms, output impedance 1 kΩ (max. 3.0Vp-p) Stereo mini jack D-sub 15-pin shrink plug USB jack (B type) Lamp: CP-775i-930 (DT00471) Air Filter: CP-775i-935 (NJ060131) * For others, consult BOXLIGHT. ENGLISH-23...

  • Page 25: Warranty

    BOXLIGHT CORPORATION's liability for the breach of the foregoing limited warranty is limited to the repair or replacement of the Product or refund of the purchase price of the Product, at BOXLIGHT's sole option. To exercise the Purchaser's rights under the foregoing warranty, the Product must be returned at the Purchaser's sole cost and expense, to BOXLIGHT or any authorized service center provided, however, that the Product must be accompanied by a written letter explaining the problem and which includes (i) proof of purchase;...
  • Page 26 Printed in Japan *QR52531 *...
