User Manual
Digital Multimedia Projector
About User's manual
Features
The content of this manual is subject to change without period notice.
All rights reserved.
Downloaded From projector-manual.com Boxlight Manuals
Multimedia LCD Projector
Thank you for purchasing the LCD projector.
Please read this user's manual thoroughly to ensure
correct usage of the projector and its features.
After reading, store this instruction manual in
a safe place for future reference.
1. Design with 3LCD optical system, provide you:
Bright image, natural color, smooth video playback
and gentle for your eyes.
2. Support Dynamic Contrast and 3D Comb Filter,
great for home theater use.
3. Auto V keystone function, +/- 30 degrees.
4. Auto brightness control.
5. Auto ceiling function.
6. Support YPbPr signal.
-1-
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BOXLIGHT Beacon CP720e
Summary of Contents for BOXLIGHT Beacon CP720e
- Page 1 3. Auto V keystone function, +/- 30 degrees. 4. Auto brightness control. 5. Auto ceiling function. 6. Support YPbPr signal. The content of this manual is subject to change without period notice. All rights reserved. Downloaded From projector-manual.com Boxlight Manuals...
-
Page 2: Table Of Contents
Inserting the batteries ........………………………19 Remote Control…........……………………….…….20 Inserting the batteries ........………………………21 Installation Setting up the projector………………………………………….……..22 Screen size and projection distance…………………………...……….24 Adjusting the image position..………….………………………….…..25 Moving the projector………………………………………...…………26 How to connect Desktop PC......………..……………………..…27 Laptop PC........……………………………....28 USB Mouse......……...………………………....29 Video........……………………………....30 Downloaded From projector-manual.com Boxlight Manuals... - Page 3 Turning off the power…………….………………………………...….34 Function of Menu (OSD) Keypad operating…………………………………………..…………..35 Computer mode……………………………………………..……….…36 Video mode………………….……………………………..…………..42 Maintenance and Troubleshooting Ceiling Mounted Installation Guide……………………………………48 Cleaning the Projector/Lens……...………………….……..…………..49 Cleaning air filter…………………………………….…..….…………50 Lamp replacement………….……………………….……………….…51 Indicators…………………………………….…………….….………..52 List of Support Displays Modes…………………………..………..……53 Downloaded From projector-manual.com Boxlight Manuals...
- Page 4 This symbol indicates a compulsory action. The contents will be clearly indicated in an illustration or description near the symbol (for example: the symbol to the left shows that the power plug should be disconnected from the power outlet). Downloaded From projector-manual.com Boxlight Manuals...
- Page 5 Continued use could result in fire or electrical shock. Use special caution in households where children are present. Downloaded From projector-manual.com Boxlight Manuals...
- Page 6 Vision can be impaired if the laser beam enters the eyes. Especially pay attention if children are present. High temperatures are generated when the lamp is lit; so do not place objects in front of the lens. Downloaded From projector-manual.com Boxlight Manuals...
- Page 7 Contact your dealer to arrange for the service. Accumulations of dust inside the projector can result in fire or malfunction if not cleaned for an extended period. Ask your dealer for details about internal cleaning. Downloaded From projector-manual.com Boxlight Manuals...
- Page 8 When the projector is not to be used for an extended period. If the projector is not to be used for an extended period because of travel, etc., disconnect the power plug from the power outlet and replace lens cover. Downloaded From projector-manual.com Boxlight Manuals...
-
Page 9: Location Of Product Safety Labels
Location of product safety labels Safety labels are used on or within the projector to alert you to items or areas requiring your attention. WARNING Business card Business card LCD Projector LCD Projector Model: Model: Input: Input: Downloaded From projector-manual.com Boxlight Manuals... -
Page 10: Checking The Package Content
K eyst one St il l Bl ank □Power Cord □S-Video □Video Cable □Computer cable □Speaker Cable □Audio Cable □USB Cable □RS232 (Optional) □Carrying Bag Optional □Quick Start Guide □ Filter Sponge (included CD) -10- Downloaded From projector-manual.com Boxlight Manuals... - Page 11 Extend and retract to adjust the projection angle 6.Foot adjust button Lock/unlock the adjustable foot. 7.Lens cover Attach when not using to protect the lens from becoming dirty or damaged. 8.Control panel (key pads) Operating system. -12- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 12: Main Unit
Use the Zoom Ring to adjust the size of the projected image. Rotate the Zoom Ring until the image is the desired size. 2.Focus Ring Use the Focus Ring to focus the projector image. Rotate the Focus Ring until the image is clear. -11- Downloaded From projector-manual.com Boxlight Manuals... -
Page 13: Keypad Control
System will auto detect YPbPr or RGB signal in computer 2 port. 3. Blank Blanks the projected image. If the projector is left in blank mode for more than 15 minutes, the projector will automatically shut down. -13- Downloaded From projector-manual.com Boxlight Manuals... - Page 14 Lights on or flashes to indicate the operating status of the projector (See Page 50) 9. Lamp indicator Indicate a problem in the internal projector temperature, lamp cover or cooling down. (See Page 50) -14- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 15: Rear View I/O Board
Analog RGB signal from a computer or YPbPr signal from a video source. System will auto detect YPbPr or RGB signal in computer in 2 port. 3. Monitor out connector Connect an external monitor to this connection view the Computer1 input. -15- Downloaded From projector-manual.com Boxlight Manuals... - Page 16 10. Power socket Connects the power core to this connection. 11. Power switch Turns the power on/off. 12. Rear IR receiver When using the remote control, point the remote control at this sensor. -16- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 17: Bottom View
1. Suspension bracket fixing points (4 points) Install the optional ceiling mount here when suspending the projector from the ceiling. 2. Air filter cover Prevents dust and other foreign particles from being drawn into the projector. -17- Downloaded From projector-manual.com Boxlight Manuals... - Page 18 Display or hide the Keystone OSD main menu page. Still Blank Keystone Adjusts the horizontal keystone function. 6.Still Keep the current image on the Screen. 7.Blank Hide the current image, Become black color on the -18- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 19: Remote Control Batteries Installation
Do not place the remote control close to the cooling fan of the projector. Do not disassemble the remote control. If the remote control needs service. Please bring it to the service station. -19- Downloaded From projector-manual.com Boxlight Manuals... -
Page 20: Remote Control
Select an item or adjusts value in the On-Screen 12.Auto Sync Menu. 14.Still Refresh the current Keep the current image image. on the screen. 13.Blank Hide the current image, Become black color on the -20- Downloaded From projector-manual.com Boxlight Manuals... -
Page 21: Inserting The Batteries
The laser pointer function emits a class laser beam. Do not look directly into the laser beam outlet or point the laser beam at other people. Vision can be impaired by shining the beam in to the eyes. -21- Downloaded From projector-manual.com Boxlight Manuals... -
Page 22: Installation
The projector supports the following four different projection methods Front projection Rear A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. -22- Downloaded From projector-manual.com Boxlight Manuals... - Page 23 Multimedia LCD Projector Rear ceiling projection Front ceiling projection A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. -23- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 24: Screen Size And Projection Distance
Refer to the table below to determine the image size at a given distance.. Distance(M) Image Size (inch) Wide Tele 1.45 33.3 2.21 2.97 3.72 5.61 7.51 11.29 Wide Tele 33.3 1.45 2.21 2.97 3.72 5.61 7.51 11.29 -24- Downloaded From projector-manual.com Boxlight Manuals... -
Page 25: Adjusting The Image Position
When the foot is adjusted, it may cause the shape of the projected image to become distorted. Use the keystone correction function to correct this distortion. To retract the front adjustable foot, press the foot release button. The front adjustable foot will slowly retract inside the projector. -25- Downloaded From projector-manual.com Boxlight Manuals... -
Page 26: Moving The Projector
Do not transport the projector in an unsuitable transport case when using a courier or transport service. This may cause damage to the projector. Carrying bag (Optional, please contact your for more information) -26- Downloaded From projector-manual.com Boxlight Manuals... -
Page 27: How To Connect
2.1 Connect one end of the audio cable to the Audio in jack on the projector. 2.2 Connect the other end of the audio cable to the audio output port on the computer sound card. -27- Downloaded From projector-manual.com Boxlight Manuals... -
Page 28: Laptop Pc
2.1 Connect one end of the audio cable to the Audio in jack on the projector. 2.2 Connect the other end of the audio cable to the audio output port on the laptop PC. -28- Downloaded From projector-manual.com Boxlight Manuals... -
Page 29: Usb Mouse
1. Insert the end of the USB Cable (B-Type) to the projector’s USB port. 2. Connect the end of the USB Cable (A-type) to the computer’s USB port. 3. When the projector and computer are turned on, the appropriate drivers should load automatically. -29- Downloaded From projector-manual.com Boxlight Manuals... -
Page 30: Video
3 . Connect YPbPr plug at projector computer in2 port and video source ( like DVD player) for video signal. 4 For S-Video, using S-Video cable connect to projector and video source for video signal. Basic Operation -30- Downloaded From projector-manual.com Boxlight Manuals... -
Page 31: Turning On The Projector
2. Remove the lens cover. 3. Connect the power cord to the projector. 4. Turn on the power switch. 5. Press the button on the control panel or [POWER] button on the remote control. Power Mouse -31- Downloaded From projector-manual.com Boxlight Manuals... - Page 32 7. Press the [VIDEO]/[PC] button on the control panel or the Computer/Video buttons on the remote control to select the appropriate source. Power Mouse 8. Use the zoom ring to adjust the screen size. 9. Use the focus ring to adjust the focus. -32- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 33: Adjusting The Screen Image
2.Adjusting the image height. Extend or retract the front adjustable foot to adjust the height of the image. 3.Correcting Keystone Distortion Use the [ Keystone] button on the projector's control panel. *Correcting vertical keystone distortion -33- Downloaded From projector-manual.com Boxlight Manuals... -
Page 34: Keypad Operating
**Press the “Volume” button on remote control, you can adjust value, and select between Brightness – Contrast – Keystones – Volume directly. There is the same function for pressing the button on the keypad -35- Downloaded From projector-manual.com Boxlight Manuals... -
Page 35: Turning Off The Projector
If the projector will not be used for an extended period, set the power switch to off and disconnect the power cord. -34- Downloaded From projector-manual.com Boxlight Manuals... -
Page 36: Computer Mode
Keep the soft tender color Presentation For computer presentation use Natural Nature color Cinema Enhance contrast mode for Cinema mode User adjustments of each RGB color User Red 000/100 User Green 000/100 User Blue 000/100 -36- Downloaded From projector-manual.com Boxlight Manuals... - Page 37 Multimedia LCD Projector 2. AUDIO Volume 000/040 Adjusts the volume Mute On/Off Mutes the volume om/off -37- Downloaded From projector-manual.com Boxlight Manuals...
- Page 38 Automatically Corrects keystone distortion in image i.e. press once to do once Corrects vertical keystone distortion in image Keystone V -80/+80 Sets all of the above settings automatically Auto sync Execute Search signal source automatically. Auto search On/off -38- Downloaded From projector-manual.com Boxlight Manuals...
- Page 39 Multimedia LCD Projector -39- Downloaded From projector-manual.com Boxlight Manuals...
- Page 40 Auto detects brightness; it turns to economic Economic mode automatically when the brightness is low. Lamp mode Normal Economic mode reduces the lamp brightness Economic economic to extend lamp life and quiet the projector Lamp timer Show Lamp timer -41- Downloaded From projector-manual.com Boxlight Manuals...
- Page 41 Multimedia LCD Projector 2. AUDIO Volume 000/040 Adjusts the volume Mute On/Off Mutes the volume om/off -43- Downloaded From projector-manual.com Boxlight Manuals...
- Page 42 Multimedia LCD Projector 3.SETTING Auto keystone Execute Automatically Corrects keystone distortion in image i.e. press once to do once -80/+80 Corrects vertical keystone distortion in image Keystone V On/off Search signal source automatically. Auto search -44- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 43: Video Mode
Keep the soft tender color Presentation For computer presentation use Natural Nature color Cinema Enhance contrast mode for Cinema mode User adjustments of each RGB color User Red 000/100 User Green 000/100 User Blue 000/100 -42- Downloaded From projector-manual.com Boxlight Manuals... - Page 44 2. Press reset button on the remote control or the button on the keypad to reset the OSD Menu values. Press the ESC button or ignore the message to exit the Reset All function without changing any settings. -46- Downloaded From projector-manual.com Boxlight Manuals...
- Page 45 Multimedia LCD Projector -45- Downloaded From projector-manual.com Boxlight Manuals...
- Page 46 Auto detects brightness; it turns to economic Economic mode automatically when the brightness is low. Lamp mode Normal Economic mode reduces the lamp brightness Economic economic to extend lamp life and quiet the projector Lamp timer Show Lamp timer -47- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 47: Maintenance And Troubleshooting
Do not clean the lens with harsh materials or subject the lens to shock, as it can easily become damaged. Close the lens cover when the projector not in use. -49- Downloaded From projector-manual.com Boxlight Manuals... -
Page 48: Ceiling Mounted Installation Guide
*A special method of installation is required in order to suspend the projector from the ceiling. Please ask your dealer for more details. M4*MAX8 For Mount M4*MAX8 For Mount -48- Downloaded From projector-manual.com Boxlight Manuals... -
Page 49: Cleaning The Air Filter
*If the filter is difficult to clean or if it is deteriorating, it should be replaced 1.Remove the filter cover from the bottom of projector. 2.Pull out the air filter. 3.Install the new air filter. Air filter Air filter -50- Downloaded From projector-manual.com Boxlight Manuals... - Page 50 Press reset button on the remote control or the button on the keypad to reset the OSD Menu values. Press the ESC button or ignore the message to exit the Reset All function without changing any settings. -40- Downloaded From projector-manual.com Boxlight Manuals...
-
Page 51: Lamp Replacement
6. Reinstall the screws removed in step 3. 7. Reinstall the lamp door and press on the side closest to the lens until the latch snaps into place and the lamp door is flush with the top of the projector. -51- Downloaded From projector-manual.com Boxlight Manuals... -
Page 52: Indicators
*The lamp is nearing the end of its service *Replace with a new lamp life Video is blurred *Focus or RGB phase is out of adjustment. *Adjust the focus and phase. -52- Downloaded From projector-manual.com Boxlight Manuals... -
Page 53: List Of Supported Monitor Displays
Multimedia LCD Projector List of Supported Monitor Displays Refresh Signal Resolution Rate (Hz) 640x350 640x480 VGAEGA 640x400 VGA text 720x400 VESA 720x350 VESA 60/72/75/85 640x480 SVGA 56/60/72/75/85 800x600 60/70/75/85 1024x768 SXGA 60/70/75 1280x1024 TV(480i), NTSC TV(575i),PAL -53- Downloaded From projector-manual.com Boxlight Manuals...
