Part Names and Function:

Main Unit

Outlet ventilation Outlet ventilation
4.Filer cover( bottom) 4.Filer cover( bottom)
7.Lens cover 7.Lens cover
1.Zoom Ring
Use the Zoom Ring to adjust the size of the projected image.
Rotate the Zoom Ring until the image is the desired size.
2.Focus Ring
Use the Focus Ring to focus the projector image.
Rotate the Focus Ring until the image is clear.
Downloaded From projector-manual.com Boxlight Manuals
1.Zoom ring 1.Zoom ring
2.Focus ring 2.Focus ring
3.Front IR receiver 3.Front IR receiver
Multimedia LCD Projector
6.Foot adjust button 6.Foot adjust button
5.Front adjustable foot 5.Front adjustable foot
-11-
8.Control panel 8.Control panel
5.Speaker
