AT-TQ4600
Enterprise-class Wireless Access Point
with IEEE802.11a/b/g/n/ac Dual Radio

Installation Guide

613-002009 Rev. A

Advertisement

Table of Contents
loading

Related Manuals for Allied Telesis AT-TQ4600

Summary of Contents for Allied Telesis AT-TQ4600

  • Page 1: Installation Guide

    AT-TQ4600 Enterprise-class Wireless Access Point with IEEE802.11a/b/g/n/ac Dual Radio Installation Guide 613-002009 Rev. A...
  • Page 2 * Neither the name of Allied Telesis, Inc. nor the names of the respective companies above may be used to endorse or promote products derived from this software without specific prior written permission.

  • Page 3: Electrical Safety And Emissions Standards

    This product meets the following standards. Federal Communications Commission Interference Statement Declaration of Conformity Manufacturer Name: Allied Telesis, Inc. Declares that the product: Wireless access point with PoE+ powered device function Model Number: AT-TQ4600 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 4 European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.
  • Page 5 Radio Equipment EN 300 328 EN 301 893 AS/NZS 4268 FCC 47 CFR Part 15, Subpart C FCC 47 CFR Part 15, Subpart E FCC part 2 RSS210 RSS-Gen RSS-102 Safety EN 60950-1 IEC 60950-1 TUV-T UL 60950-1...

  • Page 6: Translated Safety Statements

    Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF  document titled “Translated Safety Statements” on the Allied Telesis website at http:// www.alliedtelesis.com/support.

  • Page 7: Table Of Contents

    Reset Button .............................. 24 Chapter 2: Installing the Access Point ......................25 Reviewing Safety Precautions ........................26 Unpacking the AT-TQ4600 Access Point....................28 Installing the Access Point on a Table ....................... 29 Installing the Access Point on a Wall or Ceiling ..................33 Guidelines............................
  • Page 8 Contents...
  • Page 9 Figures Figure 1: Rear Panel Components ........................19 Figure 2: AT-TQ0091 AC/DC Power Adapter....................28 Figure 3: Installing the Rubber Feet ........................ 29 Figure 4: Connecting the Network Cable for Table or Desktop Installation............. 30 Figure 5: Connecting the Power Cable from the AT-TQ0091 AC/DC Adapter..........31 Figure 6: Removing an AC Plug from the AT-TQ0091 AC/DC Power Adapter ..........
  • Page 10 List of Figures...
  • Page 11 Table 1. Components on the Rear Panel ....................... 19 Table 2. Twisted Pair Cable for the LAN Port ....................22 Table 3. LEDs on the AT-TQ4600 Access Point .................... 23 Table 4. AT-TQ4600 Physical Specifications ....................45 Table 5. Environmental Specifications ......................45 Table 6.
  • Page 12 List of Tables...

  • Page 13: Preface

    Preface This guide contains the hardware installation instructions for the AT- TQ4600 Wireless Access Point. This preface contains the following sections: “Safety Symbols Used in this Document” on page 14  “Contacting Allied Telesis” on page 15 ...

  • Page 14: Safety Symbols Used In This Document

    Preface Safety Symbols Used in this Document This document uses the following conventions. Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury.

  • Page 15: Contacting Allied Telesis

    AT-TQ4600 Wireless Access Point Installation Guide Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: 24/7 Online Support —...
  • Page 16 Preface...

  • Page 17: Chapter 1: Overview

    Chapter 1 Overview This chapter describes the hardware components of the AT-TQ4600 Wireless Access Point. This chapter contains the following sections: “Features” on page 18  “Rear Panel Components” on page 19  “LAN Port” on page 21  “LEDs” on page 23 ...

  • Page 18: Features

    Chapter 1: Overview Features The main features of the product are listed here: Dual radio: 2.4 GHz and 5 GHz  IEEE 802.11a/b/g/n/ac  3x3:3ss MIMO with internal omni antennas  Maximum capacity 2.4 GHz: 450 Mbps  Maximum capacity 5 GHz: 1300 Mbps ...

  • Page 19: Rear Panel Components

    AT-TQ4600 Wireless Access Point Installation Guide Rear Panel Components The rear panel components of the AT-TQ4600 Access Point are illustrated in Figure 1. Kensington Reset LAN Port Lock Button DC Power Console Connector Port Figure 1. Rear Panel Components The components are listed in Table 1.
  • Page 20 This connector is for the AT-TQ0091 Power Adapter. The access point can be powered with PoE+ on the LAN port or the power adapter. The AT-TQ0091 Power Adapter does not come with the access point. It must be ordered separately from Allied Telesis.

  • Page 21: Lan Port

    The LAN port is used to connect the device to your Local Area Network (LAN), typically through an Ethernet switch. Power over The AT-TQ4600 Access Point supports Power over Ethernet (PoE+) on the LAN port. The unit is a PoE+ class 4 powered device with a maximum Ethernet power consumption of 16 watts.

  • Page 22: Automatic Mdix Detection

    Chapter 1: Overview Table 2. Twisted Pair Cable for the LAN Port 10Mbps 100Mbps 1000Mbps Cable Type Non- Non- Non- PoE+ PoE+ PoE+ PoE+ PoE+ PoE+ Standard TIA/EIA 568- B-compliant Category 3 shielded or unshielded cabling with 100 ohm impedance and 16 MHz frequency.

  • Page 23: Leds

    AT-TQ4600 Wireless Access Point Installation Guide LEDs The LEDs on the AT-TQ4600 Access Point are described in Table 3. Table 3. LEDs on the AT-TQ4600 Access Point State Description Solid Green The unit is receiving DC power that is within the normal operating range.

  • Page 24: Reset Button

    Chapter 1: Overview Reset Button The Reset button on the rear panel is used to return the parameter settings of the unit to their default values. You might use the button if you want to discard the current configuration of the device or because you forgot the password to the manager account and cannot manage the unit.

  • Page 25: Chapter 2: Installing The Access Point

    Chapter 2 Installing the Access Point This chapter describes how to install the AT-TQ4600 Wireless Access Point. This chapter contains the following sections: “Reviewing Safety Precautions” on page 26  “Unpacking the AT-TQ4600 Access Point” on page 28  “Installing the Access Point on a Table” on page 29 ...

  • Page 26: Reviewing Safety Precautions

    Note indicates that a translation of the safety statement is  available in a PDF document titled “Translated Safety Statements” on the Allied Telesis website at http://www.alliedtelesis.com/ support. Warning To prevent electric shock, do not remove the cover. No user- serviceable parts inside.
  • Page 27 AT-TQ4600 Wireless Access Point Installation Guide Warning Operating Temperature. This product is designed for a maximum ambient temperature of 40°C with the AC/DC adapter or with Power over Ethernet. Warning To reduce the risk of electric shock, the PoE port on this product must not connect to cabling that is routed outside the building where this device is located.

  • Page 28: Unpacking The At-Tq4600 Access Point

    One bracket for wall or ceiling mounting  If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. If you are not using the PoE feature on the LAN port of the access point to power the device, you need to separately order the AT-TQ0091 AC/DC Power Adapter.

  • Page 29: Installing The Access Point On A Table

    AT-TQ4600 Wireless Access Point Installation Guide Installing the Access Point on a Table To install the access point on a table, perform the following procedure: 1. Place the access point upside down on the table or desk selected for the device.

  • Page 30: Figure 4: Connecting The Network Cable For Table Or Desktop Installation

    Chapter 2: Installing the Access Point Figure 4. Connecting the Network Cable for Table or Desktop Installation 5. If you have not already done so, connect the other end of the network cable to a port on an Ethernet switch. 6.

  • Page 31: Figure 5: Connecting The Power Cable From The At-Tq0091 Ac/Dc Adapter

    AT-TQ4600 Wireless Access Point Installation Guide Figure 5. Connecting the Power Cable from the AT-TQ0091 AC/DC Adapter 8. Check the AC plug on the AC/DC Power Adapter to see if it is the correct plug for your region. If it is not the correct plug, remove it by pushing down on the release tab and sliding it from the slot on the adapter.

  • Page 32: Figure 7: Installing An Ac Plug On The At-Tq0091 Ac/Dc Power Adapter

    Chapter 2: Installing the Access Point Figure 7. Installing an AC Plug on the AT-TQ0091 AC/DC Power Adapter 10. Connect the AC plug on the power cord to an appropriate AC power source. Refer to Table 7 on page 46 for the power specifications of the power adapter.

  • Page 33: Installing The Access Point On A Wall Or Ceiling

    AT-TQ4600 Wireless Access Point Installation Guide Installing the Access Point on a Wall or Ceiling This procedure contains the following sections. “Guidelines” on page 33  “Attaching the Mounting Bracket to the Access Point” on page 34  “Installing the Access Point to a Wall or Ceiling” on page 35 ...

  • Page 34: Attaching The Mounting Bracket To The Access Point

    Chapter 2: Installing the Access Point Attaching the To attach the mounting bracket to the access point, perform the following: Mounting 1. Insert the mounting bracket under the clips on the bottom of the Bracket to the access point to lock the bracket in place, as shown in Figure 9. Access Point Mounting Bracket...

  • Page 35: Installing The Access Point To A Wall Or Ceiling

    AT-TQ4600 Wireless Access Point Installation Guide Mounting-Bracket Screw Figure 10. Attaching the Mounting-Bracket Screw Installing the To attach the access point and mounting bracket to a wall or ceiling, perform the following: Access Point to a Wall or Ceiling Note If you are using wall anchors, start with Step 1.

  • Page 36: Cabling The Access Point

    Chapter 2: Installing the Access Point Cabling the To install cabling on the access point, perform the following: Access Point 1. If the access point is to be powered with the AT-TQ0091 Power Adapter, connect the DC cable from the adapter to the DC 12V port on the access point.

  • Page 37: Kensington Lock

    AT-TQ4600 Wireless Access Point Installation Guide Kensington Lock A Kensington lock can be used to secure the device when it is installed on a wall, ceiling, or table. The lock is located on the rear panel (see Figure 11.) Kensington Lock Figure 11.

  • Page 38: Starting The Initial Management Session On The Access Point

    Chapter 2: Installing the Access Point Starting the Initial Management Session on the Access Point When you power on the access point for the first time, it queries the subnet on the LAN port for a DHCP server. If a DHCP server responds to its query, the unit uses the IP address the server assigns to it.

  • Page 39: Starting The Initial Management Session With A Direct Connection

    AT-TQ4600 Wireless Access Point Installation Guide Starting the To start the management session with a direct Ethernet connection between your computer and the access point, perform the following Initial procedure: Management Session with a Note Direct If the unit is using PoE for power, and you did not order an AC/DC...

  • Page 40: Starting The Initial Management Session Without A Dhcp Server

    Chapter 2: Installing the Access Point Starting the This procedure explains how to start the initial management session on the access point when the LAN port is connected to an Ethernet switch on Initial a network that does not have a DHCP server. To start the management Management session, perform the following procedure: Session without a...
  • Page 41 AT-TQ4600 Wireless Access Point Installation Guide 5. Enter “manager” for the username and “friend” for the password. The username and password are case-sensitive.

  • Page 42: Setting The Country Setting

    Chapter 2: Installing the Access Point Setting the Country Setting You should set the country setting during the initial management session of the access point to ensure that the device operates in compliance with the codes and regulations of your region or country. Note The non-US model of this product has a country code setting that must be set during the initial management session of the unit.
  • Page 43 If the setting is not correct for your country or region, contact your Allied Telesis sales representative for assistance. The access point displays a confirmation prompt. 3. Click OK to change the country setting or Cancel to cancel the procedure.
  • Page 44 Chapter 2: Installing the Access Point...

  • Page 45: Appendix A: Technical Specifications

     “Safety and Electromagnetic Emissions Certifications” on page 49  Physical Specifications Table 4. AT-TQ4600 Physical Specifications Dimensions (W x D x H) 170.0 mm x 170.0 mm x 35.0 mm (6.7 in. x 6.7 in. x 1.4 in.) Weight 0.47 kg (1 lb.)

  • Page 46: Power Specifications

    Appendix A: Technical Specifications Power Specifications Table 6. AT-TQ4600 Maximum Power Consumption AT-TQ4600 16 watts Table 7. AT-TQ0091 Power Adapter Input Range 240 Vac Input Frequency 47-63 Hz Input Power Consumption (no load) <0.3W max. Output Voltage +12 VDC Output Current 2A max.

  • Page 47: Lan Port

    AT-TQ4600 Wireless Access Point Installation Guide LAN Port Table 8. LAN Port Specifications Connector RJ-45 Standards IEEE 802.3 (10Base-T) IEEE 802.3u (100Base-TX) IEEE 802.3ab (1000Base-T) PoE standard IEEE 802.3at (class 4) Figure 14 illustrates the pin layout of the LAN port.

  • Page 48: Table 10. Mdi-X Pin Signals (10Base-T Or 100Base-Tx)

    Appendix A: Technical Specifications Table 10 lists the pin signals for the MDI-X configuration at 10 or 100 Mbps. Table 10. MDI-X Pin Signals (10Base-T or 100Base-TX) Signal Table 11 lists the pin signals when the LAN port is operating at 1000 Mbps.

  • Page 49: Safety And Electromagnetic Emissions Certifications

    AT-TQ4600 Wireless Access Point Installation Guide Safety and Electromagnetic Emissions Certifications Table 12. Safety and Electromagnetic Emissions Certificates Standard RoHs compliant Compliance European Union RoHS (Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.)
  • Page 50 Appendix A: Technical Specifications Table 12. Safety and Electromagnetic Emissions Certificates (Continued) Safety EN 60950-1 IEC 60950-1 TUV-T UL 60950-1...

  • Page 51: Appendix B: Regulatory Statements

    Appendix B Regulatory Statements This appendix contains the following regulatory statements: “Federal Communication Commission Interference Statement” on  page 52 “Industry Canada Statement” on page 54  “Europe - EU Declaration of Conformity” on page 56 ...

  • Page 52: Federal Communication Commission Interference Statement

    Appendix B: Regulatory Statements Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 53 AT-TQ4600 Wireless Access Point Installation Guide Country Code Selection (WiFi Devices) Note The non-US model of this product has a country code setting that must be set during the initial management session of the unit. The setting ensures that the unit operates in compliance with the laws and regulations of your country or region.

  • Page 54: Industry Canada Statement

    Appendix B: Regulatory Statements Industry Canada Statement This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 55 AT-TQ4600 Wireless Access Point Installation Guide (ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5 350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.; (iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5 825 MHz) doit se conformer à...

  • Page 56: Europe - Eu Declaration Of Conformity

    Appendix B: Regulatory Statements Europe - EU Declaration of Conformity This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The following test methods have been applied in order to prove presumption of conformity with the essential requirements of the R&TTE Directive 1999/5/EC: EN60950-1 ...
  • Page 57 Directive 1999/5/EC. Español Por medio de la presente Allied Telesis declara que el [Spanish] wireless access point cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
  • Page 58 Allied Telesis declara que este wireless access point [Portuguese está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovensko Allied Telesis izjavlja, da je ta wireless access point v [Slovenian] skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 1999/5/ES. Slovensky Allied Telesis týmto vyhlasuje, že wireless access point...
