1.7
CREATING THE PROJECT
The first step is to create a project and a workspace in MPLAB IDE. Typically, there is
a single project per workspace.
MPLAB IDE contains a Project Wizard to help create new projects.
Perform the following steps to create the tutorial project.
1. Start MPLAB IDE.
2. From the menu bar, click File >Close Workspace to close any workspace that
might be open.
3. Click Project > Project Wizard... to start the wizard.
4. From the Welcome screen, click Next > to display the Project Wizard – Step One:
dialog window (Figure 1-1).
FIGURE 1-1:
5. From the Device drop-down list, select "PIC32MX360F512L". Click Next >.
The Project Wizard – Step Two: dialog displays, as shown in Figure 1-2.
© 2008 Microchip Technology Inc.
Programming Tutorial for PIC32MX
SELECTING THE DEVICE
DS61147A-page 3
