Chapter 7 - Installation

7.1 Hardware Installation

a.
Use the enclosed Allen key to detach the dome cover from the camera device.
b.
Put the three waterproof rubbers which are provided in the product package into the
location holes.
c. Hammer the three plastic anchors which are provided in the product package into the
three location holes. The user needs the three screws which are included in the product
package and a screwdriver. Mount the camera on the wall or ceiling and position the
three screw slots over the plastic anchors. Insert the screws into the holes and use the
screwdriver to tighten the screws clockwise until they are secure.
