12. RIGGInG

KH7 is suitable for a wide range of applications ranging from permanent installations to large touring
applications. Please check all the available accessories on the

12.1 InsTallInG on a flaT sURfaCe

A single KH7 unit can be positioned on a flat surface in horizontal position without any additional
accessories. Ensure that the rubber feet are resting on the floor. To place a single unit in vertical position
or to ground stack a KH7 cluster, use the accessory shown in the picture below. Up to 3 units can be
stacked in horizontal position and up to two units can be stacked in vertical position.
KH7 web page.
WARNING!
• Do not install a KH7 unit in vertical
position without the KH7-BASE
accessory.
• Do not stack KH7 units without using
KH7-BASE accessory.
Please refer to the KH7 Rigging Manual
•
for operation instruction and safety
information.
