KH7 Ver. 1.2

1. InTRoDUCTIon

The K-array KH7 speaker is a compact, self-powered, weather resistant, mid-high line array element,
complying with the highest standards, both in sound quality and SPL. It features four 12" coaxial
neodymium magnet woofers, providing multiple setups, including both vertical and horizontal use, with
an exceptional peak output of 141 dB SPL.
An integrated, Class D amplifier delivers 4 x 2000W at 4Ω with a max THD of 1% (EIAJ test at 1
kHz, single channel driven). The four discrete amplifier channels are controlled by an integrated DSP
providing a hyper-detailed beam steering ability to meet any demanding setup requirement and control
sound spillover.
All DSP functions are remotely controlled via software over ethernet.
All KH7's components are designed by the K-array R&D department and custom-made under K-array's
quality control system.

2. KeY feaTURes

• Unique performance-to-size ratio
• Self powered
• Mechanically variable vertical coverage
• Mechanically variable horizontal coverage
• Integrated DSP with multiple analog and digital inputs
• Digital acoustic steering system
• Straight hanging
• RS485 connectivity for remote control

3. aPPlICaTIons

• Large scale events
• Touring sound reinforcement
• Theatres, stadiums, concert halls, arenas
• Houses of worship
• Portable and installed AV systems
