Summary of Contents for K-array Tornado KT2-HV
- Page 1 Ver. 2.7 Tornado KT2 - KT2-HV KT2C - KT2C-HV KTL2 - KTL2-HV KTL2C - KTL2C-HV USER GUIDE English KT2 - KT2-HV KTL2 - KTL2-HV KT2C - KT2C-HV KTL2C - KTL2C-HV All Tornado models are also available in a 70V version! See Paragraph 9.1 for details.
-
Page 2: Table Of Contents
Ver. 2.7 Tornado TABLE OF CONTENTS SYMBOLS ................3 1. INTRODUCTION ..............4 2. KEY FEATURES ..............4 3. OPTIONAL FEATURE ............... 4 4. APPLICATIONS ............... 4 5. SAFETY INFORMATION ............5 6. UNPACKING ................. 5 7. INCLUDED ACCESSORIES ............6 8. -
Page 3: Symbols
Ver. 2.7 Tornado SYMBOLS K-array declares that this device is in compliance with applicable CE standards and regulations. Before putting the device into operation, please observe the respective country-specific regulations! WEEE Please dispose of this product at the end of its operational lifetime by bringing it to your local collection point or recycling center for such equipment. -
Page 4: Introduction
In addition to the standard features of the Tornado loudspeakers, the KTL2 and KTL2C have 7 integrated RGB LEDs that can be controlled thanks the wide range of K-array accessories via DMX or by remote. With its ability to effortlessly reproduce speech, music and lighting, it is an excellent choice for fixed applications such as theatres, museum displays, restaurants, portable systems for corporate AV presentations, department stores, and in hidden locations such as chancel steps in houses of worship. -
Page 5: Safety Information
6. UNPACKING Each K-array amplifier is built to the highest standard and thoroughly inspected before leaving the factory. Upon arrival, carefully inspect the shipping carton, then examine and test your new amplifier. If you find any damage, immediately notify the shipping company. -
Page 6: Included Accessories
Ver. 2.7 Tornado 7. INCLUDED ACCESSORIES KT2C KTL2 KTL2C • • 1 x M5 turned steel thumb nut 1 x M5 turned steel thumb nut • • 1 x 4-pin Phoenix connector 2 x 4-pin Phoenix connector • • 1 x 4-pin Phoenix connector 2 x 4-pin Phoenix connector •... -
Page 7: Rear Panel And Wiring
Ver. 2.7 Tornado 9. REAR PANEL AND WIRING KT2 - KT2C KTL2 - KTL2C 4-pin audio input connector 4-pin light controller connector 32Ω Wiring Light Controller Wiring 2- 2+ 1- 1+ 2- 2+ 1- 1+ R G B V+ to (-)pin of the Amp to negative DC power for 2- 2+ 1- 1+ 2- 2+ 1- 1+... -
Page 8: Version
Ver. 2.7 Tornado 9.1 70V VERSION All Tornados are available also in the 70V version: KT2-HV, KT2C-HV, KTL2-HV, KTL2C-HV. The very high impedance of the speakers allows to drive up to 100 units by a single KA84 amplifier channel and up to 50 units by two bridged KA24 amplifier channels. KA24 KA84 70V Version Wiring with KA24... -
Page 9: Installation
Ver. 2.7 Tornado 10. INSTALLATION KT2 - KTL2 6 mm 0.24” KT2C - KTL2C 105 mm 4.13” plaster board or ceiling tile... -
Page 10: Accessories
Ver. 2.7 Tornado 11. ACCESSORIES ..iD you know that Designed as passive speaker, the new Tornados can be easily converted into self-powered devices by inserting the KA1-T2H amplifier module. KA1-T2H Amplifier module for Tornados (32 W) 15 W power supply K-AL15 for 1 KA1-T2H (in background music or speech applications) 66 W power supply... -
Page 11: Ka1-T2H Wiring
Ver. 2.7 Tornado 11.1 KA1-T2H WIRING 2- 2+ 1- 1+ B V+... -
Page 12: Service
12. SERVICE To obtain service: 1) Contact the official K-array distributor in your country. Your local distributor will direct you to the appropriate service center. 2) If you are calling for service, please have the serial number(s) of the unit(s) available for reference. -
Page 13: Specifications
Ver. 2.7 Tornado 13. SPECIFICATIONS KT2 - KT2C - KT2-HV - KT2C-HV ACOUSTICS TRANSDUCERS Power handling 18 W (AES) 2” Neodymium magnet woofer Full range Frequency range 150 Hz – 18 kHz (-10dB) with 2 x 0.8” voice coils POWER AUDIO INPUT KT2, KT2H: 8 Ω... - Page 14 Ver. 2.7 Tornado KA1-T2H ACCESSORY esigneD as passive speakers the new ornaDos can be easily converteD into ka1-t2h 12v/24v self powereD Devices by inserting the amplifier moDule AUDIO INPUT DC POWER Connectors Phoenix connector Nominal voltage 12/24 Vdc Wiring IN – (-) IN + (+) GRD (Ground) Operating range 10 - 26 Vdc POWER INPUT...
-
Page 15: Kt2 And Kt2C En54-24 Data
TYPE B The contents of this manual are furnished for informational purposes only. K-array s.u.r.l. assumes no responsibility for any errors or inaccuracies that may appear in this manual. K-array s.u.r.l. reserves the right to make modifications without prior notice.
