Table 23 Fxr Settings For 24-Volt Models - Outback Power Systems FXR2012E Operator's Manual

Specifications
Field
INVERTER Hot Key
Inverter Mode
CHARGER Hot Key
Charger Control
AC Input Hot Key
AC Input Mode
Sensitivity (see page 28 for increments)
Search
Pulse Length
Pulse Spacing
Input Type
Grid Input AC Limit
AC Input and
Gen Input AC Limit
Current Limit
Charger AC Limit
Input Mode
Voltage Limit Lower
(Voltage Limit) Upper
Transfer Delay
Grid AC Input
Connect Delay
Mode and Limits
If Mini Grid mode
is selected:
If Grid Zero mode
is selected:
Input Mode
Voltage Limit Lower
(Voltage Limit) Upper
Transfer Delay
Gen AC Input
Connect Delay
Mode and Limits
If Mini Grid mode
is selected:
If Grid Zero mode
is selected:
AC Output
Output Voltage
Cut-Out Voltage
Low Battery
Cut-In Voltage
Absorb Voltage
(Absorb) Time
Float Voltage
Battery Charger
(Float) Time
Re-Float Voltage
Re-Bulk Voltage
Equalize Voltage
Battery Equalize
(Equalize) Time
78
Table 23 FXR Settings for 24-Volt Models
Item
FXR2024E
VFXR3024E
Connect to Grid
(Connect) Delay
DoD Volts
FXR2024E
DoD
Amps
VFXR3024E
Connect to Grid
(Connect) Delay
DoD Volts
FXR2024E
DoD
Amps
VFXR3024E
Default Minimum
Off
On
Use
30
8 AC Cycles 4 AC Cycles
60 AC Cycles 4 AC Cycles
Grid
30 Aac
30 Aac
6 Aac
9 Aac
Generator, Support, Grid Tied, UPS, Backup,
Support
208 Vac
252 Vac
1.0 second 0.12 seconds
0.2 minutes 0.2 minutes
24.0 Vdc
10 minutes 2 minutes
25.0 Vdc
6 Aac
6 Aac
Generator, Support, Grid Tied, UPS, Backup,
Generator
208 Vac
252 Vac
1.0 second 0.12 seconds
0.5 minutes 0.2 minutes
24.0 Vdc
10 minutes 2 minutes
25.0 Vdc
6 Aac
6 Aac
230 Vac
X
21.0 Vdc
25.0 Vdc
28.8 Vdc
1.0 hours 0.0 hours
27.2 Vdc
1.0 hours 0.0 hours
25.0 Vdc
24.0 Vdc
29.2 Vdc
1.0 hours 0.0 hours
Maximum
On, Off, or Search
On or Off
Drop or Use
0 200
20 AC Cycles
120 AC Cycles
Grid or Gen
2.5 Aac 30 Aac
2.5 Aac 30 Aac
0 Aac 7 Aac
0 Aac 10 Aac
Mini Grid, Grid Zero
170 Vac 230 Vac
232 Vac 290 Vac
4.0 seconds
25.0 minutes
22.0 Vdc 32.0 Vdc
200 minutes
22.0 Vdc 32.0 Vdc
0.5 Aac 10 Aac
0.5 Aac 14 Aac
Mini Grid, Grid Zero
170 Vac 230 Vac
232 Vac 290 Vac
4.0 seconds
25.0 minutes
22.0 Vdc 32.0 Vdc
200 minutes
22.0 Vdc 32.0 Vdc
0.5 Aac 10 Aac
0.5 Aac 14 Aac
200 Vac 260 Vac
18.0 Vdc 24.0 Vdc
20.0 Vdc 28.0 Vdc
22.0 Vdc 32.0 Vdc
24.0 hours
22.0 Vdc 32.0 Vdc
24/7
22.0 Vdc 32.0 Vdc
22.0 Vdc 32.0 Vdc
22.0 Vdc 34.0 Vdc
24.0 hours
