Electrical Specifications

NOTE: Items qualified with "default" can be manually changed using the system display.

Table 14 Electrical Specifications for 12-Volt FXR Models

Specification
Continuous Output Power at 25°C
Continuous AC Output Current at 25°C
AC Output Voltage (default)
AC Output Frequency (default)
AC Output Type
AC Waveform
Typical Efficiency
Total Harmonic Distortion (maximum)
Harmonic Distortion (maximum single voltage)
AC Output Voltage Regulation
Appliance Protective Class (IEC)
Power Factor
Inrush Current
AC Maximum Output Current (1 ms peak)
AC Maximum Output Current (100 ms RMS)
AC Overload Capability (100 ms surge)
AC Overload Capability (5 second)
AC Overload Capability (30 minute)
AC Maximum Output Fault Current and Duration
Power Consumption (idle) – Invert mode, no load
Power Consumption (idle) – Search mode
Power Consumption – Off
AC Input Voltage Range
AC Input Frequency Range
AC Input Current (maximum continuous)
Grid-Interactive Voltage Range (default)
Grid-Interactive Frequency Range (default)
DC Input Voltage (nominal)
DC Input Voltage Range
DC Maximum Input Voltage
DC Input Power (continuous)
DC Input Maximum Current (continuous full power)
DC Input Maximum Current (surge)
DC Input Maximum Current (short-circuit)
Battery Charger Maximum AC Input
Battery Charger Maximum DC Output
DC Output Voltage Range (charging)
Auxiliary Output
900-0169-01-00 Rev A

Specifications

FXR2012E
2000 VA
8.7 Aac
230 Vac
50 Hz
Single-phase
True Sinewave
90%
< 5%
< 2%
± 2.5%
Class I
–1 to 1
None
28 Aac
20 Aac
4600 VA
4300 VA
2500 VA
28.3 Aac for 0.636 seconds
≈ 34 watts
9 watts
3 watts
170 to 290 Vac
45 to 55 Hz at 50-Hz setting
54 to 66 Hz at 60-Hz setting
30 Aac
—
—
12 Vdc
10.5 to 17 Vdc
17 Vdc
2.4 kVA
200 Adc
460 Adc
1891 Adc for 0.105 seconds
5 Aac
100 Adc
11 to 17 Vdc
0.7 Adc at 12 Vdc
VFXR2612E
2800 VA
11.3 Aac
230 Vac
50 Hz
Single-phase
True Sinewave
90%
< 5%
< 2%
± 2.5%
Class I
–1 to 1
None
28 Aac
20 Aac
4600 VA
4300 VA
3100 VA
28.3 Aac for 0.636 seconds
≈ 34 watts
9 watts
3 watts
170 to 290 Vac
45 to 55 Hz at 50-Hz setting
54 to 66 Hz at 60-Hz setting
30 Aac
—
—
12 Vdc
10.5 to 17 Vdc
17 Vdc
3.12 kVA
260 Adc
460 Adc
1891 Adc for 0.105 seconds
6 Aac
120 Adc
11 to 17 Vdc
0.7 Adc at 12 Vdc
