Specifications

Mechanical Specifications

Table 17 Mechanical Specifications for FXR Models

Specification
Inverter Dimensions (H x W x D)
Shipping Dimensions (H x W x L)
Inverter Weight
Shipping Weight
Accessory Ports
Non-volatile Memory
Neutral-Ground
Bond Switching
Chassis Type

Environmental Specifications

Table 18 Environmental Specifications for all FXR Models

Specification
Rated Temperature Range (meets component specifications; however,
please note that the inverter output wattage is derated above 25°C)
Operational Temperature Range (functions, but not rated for operation;
does not necessarily meet all component specifications)
Storage Temperature Range
IP (Ingress Protection) Rating of Enclosure
Environmental Category
Wet Locations Classification
Relative Humidity Rating
Pollution Degree Classification
Maximum Altitude Rating
Overvoltage Category (AC Input)
Overvoltage Category (DC Input)
70
FXR2012E, FXR2024E, and
FXR2348E
13 x 8.25 x 16.25"
(33 x 21 x 41 cm)
21.75 x 13 x 22" (55 x 33 x 56 cm)
62 lb (29 kg)
67 lb (30 kg)
RJ11 (batt temp) and RJ45 (remote)
Yes
No
Sealed
VFXR2612E, VFXR3024E, and
VFXR3048E
12 x 8.25 x 16.25"
(30 x 21 x 41 cm)
21.75 x 13 x 22" (55 x 33 x 56 cm)
61 lb (28 kg)
67 lb (30 kg)
RJ11 (batt temp) and RJ45 (remote)
Yes
No
Vented
Value
–4°F to 122°F (–20°C to 50°C)
–40°F to 140°F (–40°C to 60°C)
–40°F to 140°F (–40°C to 60°C)
IP20
Indoor unconditioned
Wet locations: No
93%
PD 2
6561' (2000 m)
3
1
900-0169-01-00 Rev A
