Table 16 Electrical Specifications for 48-Volt FXR Models

Specification
Continuous Output Power at 25°C
Continuous AC Output Current at 25°C
AC Output Voltage (default)
AC Output Frequency (default)
AC Output Type
AC Waveform
Typical Efficiency
Total Harmonic Distortion (maximum)
Harmonic Distortion (maximum single voltage)
AC Output Voltage Regulation
Appliance Protective Class (IEC)
Power Factor
Inrush Current
AC Maximum Output Current (1 ms peak)
AC Maximum Output Current (100 ms RMS)
AC Overload Capability (100 ms surge)
AC Overload Capability (5 second)
AC Overload Capability (30 minute)
AC Maximum Output Fault Current and Duration
Power Consumption (idle) – Invert mode, no load
Power Consumption (idle) – Search mode
Power Consumption – Off
AC Input Voltage Range
AC Input Frequency Range
AC Input Current (maximum continuous)
Grid-Interactive Voltage Range (default)
Grid-Interactive Frequency Range (default)
DC Input Voltage (nominal)
DC Input Voltage Range
DC Maximum Input Voltage
DC Input Power (continuous)
DC Input Maximum Current (continuous full power)
DC Input Maximum Current (surge)
DC Input Maximum Current (short-circuit)
Battery Charger Maximum AC Input
Battery Charger Maximum DC Output
DC Output Voltage Range (charging)
Auxiliary Output
900-0169-01-00 Rev A
FXR2348E
2300 VA
10 Aac
230 Vac
50 Hz
Single-phase
True Sinewave
93%
< 5%
< 2%
± 2.5%
Class I
–1 to 1
None
35 Aac
25 Aac
5750 VA
5175 VA
3100 VA
36 Aac for 0.636 seconds
≈ 34 watts
9 watts
3 watts
170 to 290 Vac
45 to 55 Hz at 50-Hz setting
54 to 66 Hz at 60-Hz setting
30 Aac
208 to 252 Vac
47 to 51 Hz
48 Vdc
42 to 68 Vdc
68 Vdc
2.7 kVA
57.5 Adc
143.75 Adc
1891 Adc for 0.105 seconds
5 Aac
35 Adc
42 to 68 Vdc
0.7 Adc at 12 Vdc
Specifications
VFXR3048E
3600 VA
13 Aac
230 Vac
50 Hz
Single-phase
True Sinewave
93%
< 5%
< 2%
± 2.5%
Class I
–1 to 1
None
35 Aac
25 Aac
5750 VA
5175 VA
3300 VA
36 Aac for 0.636 seconds
≈ 34 watts
9 watts
3 watts
170 to 290 Vac
45 to 55 Hz at 50-Hz setting
54 to 66 Hz at 60-Hz setting
30 Aac
208 to 252 Vac
47 to 51 Hz
48 Vdc
42 to 68 Vdc
68 Vdc
3.6 kVA
75 Adc
143.75 Adc
1891 Adc for 0.105 seconds
9 Aac
40 Adc
42 to 68 Vdc
0.7 Adc at 12 Vdc
