- Page 1 User’s Guide Includes Mounting, Installation, and Product Registration...
-
Page 3: Notice Of Copyright
About OutBack Power Systems OutBack Power Systems is a leader in advanced energy conversion technology. Our products include true sine wave inverter/chargers, maximum power point charge controllers, system communication components, as well as breaker panels, breakers, accessories, and assembled systems. - Page 4 Warranty Introduction Dear OutBack Customer, Thank you for your purchase of OutBack products. We make every effort to assure our power conversion products will give you long and reliable service for your renewable energy system. As with any manufactured device, repairs might be needed due to damage, inappropriate use, or unintentional defect.
- Page 5 SAVE THESE INSTRUCTIONS! Requirements and Warnings The OutBack Power Systems FLEXware 250 is listed by ETL as an accessory enclosure for OutBack FX, GTFX, GVFX, and VFX Series Inverter/Chargers to UL standard UL 1741. This enclosure is intended for battery circuits configured for 12 to 48 volts nominal.
- Page 6 FLEXware 50 Parts List The FLEXware 250 consists of an aluminum enclosure which can be used for either the AC or DC side of an FX Series Inverter/Charger. Each FLEXware 250 includes: • Installed ground bus bar •...
- Page 7 Getting to Know FLEXware 50 When mounting the FLEXware 250, the various breaker FLEXware 250 mounted slots must be in a vertical (forward facing) position as an AC enclosure and cannot face downward or upward. Otherwise, the breakers can malfunction.
- Page 8 AC side Figure 2: FW250 Enclosure Unthreaded standoffs for attaching to FX Unthreaded standoffs insert into the AC or DC end of the FX Inverter/Charger’s top casting mounting holes. Bottom 2” knockout Figure 3: FLEXware 250 top view Ground Bus Bar...
- Page 9 DC breaker slots DC input breaker slot and Breaker Guard mounting holes 2” conduit knockout Unthreaded standoffs ½” conduit knockouts Figure 4: FLEXware 250 DC side AC breaker slots AC receptacle knockoff (off-grid Bypass Slide Plate systems only) mounting holes Unthreaded standoffs 2”...
- Page 10 Figure 6: FLEXware 250 AC and DC chassis mounting locations Unthreaded standoff Screw hole Figure 7: Side view of FLEXware 250 fitting onto AC side of an FX Series Inverter/Charger...
- Page 11 • After all wiring has been completed, install the DCC and securing with four M5 X 12mm screws (included with the DCC). • Install each FLEXware 250 top cover plate and secure the #10 X 3/8” sheet metal screws. For AC wiring instructions for the FLEXware 250, please see the schematics in the individual AC Input/Output/Bypass Assembly (IOB) kits.
- Page 12 Figure 9: FLEXware 250-DC Wiring Diagram...
-
Page 14: Product Registration
PSX-240 PSX-240-Relay Please circle the three most important factors affecting your purchase decision: Price Product Reputation Product Features Reputation of OutBack Power Systems Value I am interested in receiving information concerning OutBack Power Systems products and events (circle one): Revision.2007-11-12... - Page 16 European Sales Office Corporate Office C/ Castelló, 17 19009 62nd Avenue NE 08830 - Sant Boi de Llobregat Arlington, WA 98223 USA BARCELONA, España 360-435-6030 +34.93.654.9568 www.outbackpower.com 900-0088-01-00 REV A...
