Rear Panel

Ethernet 10/100 socket

Connect to Ethernet network with a UTP category 5 cable that cannot exceed 100 meters. Once the
Ethernet cable is connected without error, Video Server will utilize Ethernet interface regardless of
modem connection.

COM port

This RS232 serial port can connect with a modem or included null modem cable to utilize dial-up
network when Ethernet is not available. If Video Server operates with Ethernet interface, administrators
may use this port to control PT Z camera attached to VIDEO.
