Summary of Contents for 4xem IPVS1A

  • Page 2: Before You Use

    Before You Use It is important to carefully examine the contents with the Chapter Package Contents after opening the package. If there is anything missing, contact your reseller. Read the Chapter Physical Description before assembling and operating the device and peripherals.
  • Page 3: Table Of Contents

    Table of Contents Before You Use…………………………………………………………………..1 Package Contents ... 4 Features and Benefits... 5 Physical Description ... 7 Front Panel ...7 Rear Panel ...8 How to Install... 11 Ethernet Environment... 12 Modem Environment ... 17 How to Use ... 26 Authentication ...
  • Page 4 Configure System via FTP ... 55 Telnet Commands ... 61 Appendix ... 63 A. Troubleshooting ... 63 B. Frequently Asked Questions... 64 C. Upgrade System Firmware ... 68 D. URL Commands of Video Server... 69 E. Settings of Supported PTZ Cameras ... 81 F.
  • Page 5: Package Contents

    Package Contents If any of the following items are missing, please contact your reseller. Video Server Power adapter I/O terminal connector Camera control cable Null modem cable Software CD - 4 -...
  • Page 6: Features And Benefits

    Features and Benefits Video Server is a high-performance networking video transmitter. With powerful VLIW DSP core and fully optimized algorithm, it can compress and transmit the high quality real-time video through standard TCP/IP inter-network. In addition to meet the basic needs of video feed, many advanced features are added to help building applications of surveillance or web attraction.
  • Page 7 security system in your home or office. ☆ Weekly schedule for automatic surveillance The user-defined time period will repeat weekly to check any security settings and accordingly sending notification or drive external devices. It is easy to install in SOHO, retail shop and home as a security system.
  • Page 8: Physical Description

    Physical Description Front Panel BNC video input 75Ohms resistance video port for connecting an external camera. To ensure video modulation type being correctly detected, cameras should be attached and powered on before the Video Server is powered on. - 7 -...
  • Page 9: Rear Panel

    Rear Panel Status LED’s Each time Video Server starts up, it will perform power-on-self-test, abbreviated as POST, to examine every hardware module. As soon as the administrator plugs in the power connector both LED’s under the power LED will flash one by one until the diagnosis is done.
  • Page 10: Com Port

    COM port This RS232 serial port can connect with a modem or included null modem cable to utilize dial-up network when Ethernet is not available. If Video Server operates with Ethernet interface, administrators may use this port to control PTZ camera attached to VIDEO. General I/O terminal block SW_COMMON OUTPUT SW_NOPEN...
  • Page 11: Restore Button

    Restore button There is a button hidden in the box for restoring the system factory default settings. When the system fails to install or operates abnormally, use the included assistant stick in the package and follow the following procedures to reset the system back to its original status.
  • Page 12: How To Install

    How to Install To easily fit into various environments, Video Server automatically detects the attached interfaces and configures itself to the best condition. Therefore users need not care whether the connected cameras are either NTSC or PAL, how to select the network between Ethernet and modem, and whether the Ethernet speed is 10Mbps or 100 Mbps.
  • Page 13: Ethernet Environment

    Ethernet Environment Hardware installation Before installing multiple Video Server’s at the well-chosen locations, the administrator should memorize the serial numbers on the packages respectively for future use. Cable connection Shut down all the peripheral devices prior to connection. The video BNC, Ethernet cable and power adapter are essential for basic viewing function.
  • Page 14: Software Installation

    Software installation Easy way with installer program In order to configure Video Server’s remotely, administrators should keep the serial numbers of the new Video Server’s for identification and initial passwords. After successfully mounting Video Server’s in the proper position, run the Installer program on the PC in the same network to locate the newly mounted Video Server’s.
  • Page 15 After successful notification, administrators may keep the address information and ○ click directly on to access the Video Server in the default browser. If the IP address is taken by another network device in the network, the Installer program will pop out another message window to warn that the assigned IP conflicts.
  • Page 16 Manual way with existing programs For those environments such as MAC, Linux, Unix or other operating systems, whose installer is not yet available, some common network tools including ARP and PING can be used to install Video Server. Before proceeding further, make sure ARP and PING programs exist.
  • Page 17: First Access To Video Server

    First access to Video Server Change initial password of administrator Starting the Web browser to connect to the assigned IP address of Video Server, users will be asked for user name and password by an authentication message window. A root password, identical to the Video Server's serial number, is needed for the initial access to a newly installed Video Server.
  • Page 18: Modem Environment

    Modem Environment Hardware installation Though Video Server is designed to serve real-time images in Ethernet, it also supports the dial-up network. To use a dial-up network, the Ethernet socket should be left disconnected since Ethernet is the first priority among available interfaces. After powering up, Video Server will detect if any external modem is connected to the modem port .
  • Page 19 Shut down the peripheral devices prior to connection and keep the power adaptor unplugged until other cables are firmly connected. In the environment without Ethernet, administrators can use the included null modem cable to connect to Video Server directly and access point-to-point. After necessary information is entered and saved, turn off Video Server and remove the null modem cable.
  • Page 20 Software installation Via Ethernet Enter the COM configuration Web page and select the driver type as modem. Well configure each field for dialing information. Refer to the COM section in Definition of Configuration for detailed description. Via null modem Install a new modem 1.
  • Page 21 4. Choose the serial port that the included null modem cable is attached to and click on . The null modem is now ready for use. If no Dial-Up adapter exists in the system, Windows may automatically prompt install. Press continue.
  • Page 22 Setup a new connection 1. After the 33600 bps modem is installed, open the dialup network folder in Windows to build a new connection. 3. Just enter arbitrary digits as phone number and click on phone number here is not important. 2.
  • Page 23 5. Right-click on the newly setup connection icon for entering properties. 7. Select 115200 as the speed and click on 8. On the second page, only check "Enable software compression" and "TCP/IP" while leaving others blank. Keep other settings as default values and click 6.
  • Page 24 Now the connection is ready to use for null modem. Double click the newly setup connection. A dialing information window will pop up. Enter “root” as user name and the serial number labeled on the bottom side of the box as the password and click on .
  • Page 25 First access to Video Server in null modem mode After successful authentication, administrators should see the motion pictures in the main page. When using Microsoft Internet Explorer, administrators must allow installing a plug-in provided by Video Server additionally prior to viewing motion pictures. Change initial password of administrator For best security, administrators must change the password on the security page of configuration immediately.
  • Page 26 First access to Video Server in modem mode If the dial-out is not prohibited and the attached modem is recognized, Video Server will send out the system startup log and connection log by email or FTP according to user’s settings as soon as the system is ready. That can be used to verify if the settings work. Then Video Server will always wait for someone to dial in.
  • Page 27: How To Use

    How to Use Open your familiar web browser and connect to Video Server just like a general web site and the video will present on demand. Make sure the web address of the target Video Server is accurate. Authentication After opening the Web browser and typing in the URL of Video Server, a dialogue window will pop out to request a username and password.
  • Page 28: Installing Plug-In

    Installing Plug-in If it is initial access to Video Server via the Web browser supporting server push, the motioned pictures will display directly. If the Web browser is Internet Explorer in Windows, users will be asked to install a new plug-in that is provided by Video Server. This plug-in has been registered for certificate and is used to display motioned pictures in the Internet Explorer.
  • Page 29: Main Page

    Main Page Basic functions are displayed in main entrance page of Video Server. The first figure below is graphic mode that has better visual effect and the second one is text mode that will shorten download time. The main page may look different depending on the PTZ driver or the privilege of the user.
  • Page 30 Text mode Video quality selection It allows users to adjust the video quality for speed or smoothness. The performance is also subject to the network bandwidth and the number of users. Five options are available to be chosen from “Medium” to “Excellent”. “Medium” quality means the picture has the quickest refresh rate but the worst image quality and “Excellent”...
  • Page 31 “Standard×2” compared to “Double” is similar to the case. “Half×2” is especially suits in the low bandwidth environment like a dial-up network. To fit into the small image area, timestamp will be skipped in “Half” and “Half×2” modes. System configuration There is a button or text link in the left side of the system configuration that only appears in administrators’...
  • Page 32: System Configuration

    System Configuration Introduction The system configuration can be easily done remotely on Internet Explorer through the Web interface. There are two wizards in addition to classified categories of system configurations. They can give friendly instructions and facilitate the setup job. Alternately administrators may type directly the URL of system configuration, “http://<IP address of Video Server>/setup/config.html”, to directly enter the configuration page.
  • Page 33: Setup Wizard

    Setup Wizard The setup wizard will guide administrator to enter necessary information including system name, current date and time, administrator’s password, video configuration and captions, and network settings. Administrators can exit the procedures anytime to reserve the current configuration. Finally the setup wizard will ask for reboot to validate the changes and administrators can decide to reboot later.
  • Page 34: Definitions Of Configuration

    Definitions of Configuration System parameters Change host name The “host name” is used for the homepage title of main page and displays as the title over the video window on the main page. The maximum string length is 40 characters or 20 characters in double-byte-character-systems like Chinese or Japanese.
  • Page 35 Security privilege Change root password To change the administrator’s password, type the new password in both text boxes identically. What is typed will be displayed as asterisks for security purposes. The maximum password is 16 characters. After pressing , the web browser will ask administrators for the new password for access.
  • Page 36: Network Settings

    Network settings Fix the IP address To eliminate incautious mistakes during installation, Video Server will stay in installation mode whenever it starts unless "Reset network at next boot" is disabled. This option can also be disabled using the Installer program. Once the option is disabled, Video Server will skip installation at the next boot and the Installer program will not find the installed units.
  • Page 37 Even in modem application, Video Server will send out a connection log whenever it dials out to an ISP or dialup server outside. If the administrator has setup some applications in either event mode or sequential mode, Video Server will send out snapshots once conditions are met.
  • Page 38 Video and motion detection Adjust image settings "Time stamp" and "Text on image" will be enclosed in image for reference. The timestamp is captured from date and time of Video Server that is maintained by an on-board real-time clock. "Color" setting is independent of the connected camera and “B/W”...
  • Page 39: Com Port Configuration

    COM port configuration Choose serial interface There are two types of serial interfaces supported by COM port but only one interface can be used at one time. Administrators must set the correct “Interface mode” between RS232 and RS485 according to the attached device. Choose device driver If the attached device is PTZ driver, administrators should select the appropriate PTZ model.
  • Page 40 applications, also remember to choose Network option to enter mail server address and recipient's e-mail address. If "Dialout allowed" is not checked, Video Server will not send out any snapshots when events occur and the settings except for "Initial modem command"...
  • Page 41 Application constitution Administrators can use combinations of options on the application page to perform many useful security applications. Video Server provides two application modes; one is performed according to the settings on the web page, the other is performed according to the external command script.
  • Page 42 event” option to drive some device attached to the digital outputs several seconds after the event happens and/or send snapshots that are taken right at the moment. . If administrators want to receive some snapshots to check the event, please check the “Upload snapshot while input condition match”...
  • Page 43: Homepage Layout

    Homepage layout There are two homepage display modes. One is "Image mode" that uses graphics for links; the other is "Text mode" that mostly uses text for links. Administrators may easily give Video Server a different presence of homepage. The "logo graph"...
  • Page 44: View Log File

    View log file There is some useful information in the system log including current system configuration and activity history with timestamp for tracking. View parameters The whole system parameters will be categorized listed for administrators to check. The content is the same as CONFIG.INI. Factory default It is used to restore the factory default settings.
  • Page 45: Advanced Functions

    Advanced Functions Capture Up-to-date Still Images Get snapshot via URL Administrator and users can use the specific URL to capture the current still image. http://<IP of Video Server>/cgi-bin/video1.jpg[?<param>=<value>] Additional value parameters:param quality size Get snapshot via FTP Administrator and users can log-in the FTP daemon of Video Server to download the refreshed JPEG image named video1.jpg.
  • Page 46: Video Embedded In Customers' Homepage

    Video Embedded in Customers’ Homepage In additional to the URL, some scripts should be added to download a plug-in for motion pictures. The following example simply displays title text and a real-time video window in Internet Explorer or Netscape. The user name and password should be configured in advance.
  • Page 47: Download Event-Triggered Snapshots

    Download Event-triggered Snapshots There are three video image files for the video channel of three stages: pre-alarm, the moment when triggered and post-alarm. Only the snapshots captured by the last event are preserved. Administrator and users can use FTP or URL to get the saved snapshots. They can also be browsed from the application page in system configuration.
  • Page 48: Uploading Snapshots Periodically

    Uploading Snapshots Periodically Upload snapshots to external FTP server In sequential mode, Video Server will send out snapshots according to interval and period settings. If snapshot files are intended for quick updates, it is better to skip date and time suffix. The file name will then be video1.jpg. If the snapshots are used for occasional monitoring, suffix with date and time can help administrators classify them easily.
  • Page 49: Customize Graphics In Homepage

    Customize Graphics in Homepage While in text mode, there is a small icon named BTN_TEXT.GIF preceding with each link that can be changed by administrators. While in image mode, the default method will use the image stored in Flash memory. The followings are the referenced file name and size limitation of each stored images.
  • Page 50: Command Script For Complex Applications

    Command Script for Complex Applications Besides the application wizard, Video Server provides a more professional command script for advanced applications. The command script will be executed exclusively with the settings in Application page of system configuration except for the weekly schedule. To build the advanced application, follow the steps below.
  • Page 51 “Digital input state”: “M”: “Channel Number”: “Video input state”: “Delay time”: “Digital output number”: always 1 “Digital output state”: “V”: “P”: “W”: “IP”: “Port”: “Message”: “U”: “Method”: “S”: “N”: “;”: The filename format is, image characterization (pre, trg, pos) year month hour minute...
  • Page 52: Practical Examples

    Practical examples Command line Description MA=1C; When any motion is detected, “Normal Close” of relay output will short with “Common”. 1\=(5)1O; When DI transients from high to low, “Normal Open” of relay output will short with COMMON in 5 seconds. A\=W{192.168.0.1 If there is no video signal, a message “no signal!”...
  • Page 53: Url For External Device Control

    URL for External Device Control Query status of digital inputs /cgi-bin/getdi.cgi Video Server will return status of four digital inputs in one line. Drive digital outputs /cgi-bin/setdo.cgi?do1=<state> <state>: C, O denoting Normal Close or Normal Open respectively. Move motorized camera in PTZ direction /cgi-bin/control.cgi?<param>=<value>&<param>=<value>……...
  • Page 54: Transparent Remote Serial Driver

    Transparent Remote Serial Driver Video Server provides a highly customized control support to third-party serial interface devices aside from PTZ cameras. That means in addition to setting up a custom camera with PTZF commands, users may utilize this mode and introduce a customized homepage to transmit arbitrary user-defined commands from user-side to Video Server.
  • Page 55: Url Of System Maintenance

    URL of System Maintenance Download System Log via FTP Besides viewing the system log from the web page, administrators can download the system log file, SYSTEM.LOG, via FTP. To log into the FTP daemon, enter “root” as the user name and the same administrator’s password used in Web access. Restart System via URL /cgi-bin/reset.cgi Restart Video Server without warning.
  • Page 56: Configure System Via Ftp

    Configure System via FTP Administrators can use FTP to configure Video Server much quicker than Web page especially for multiple targets. To configure system via FTP, first download the parameter file, CONFIG.INI, to customize each field according to the environment and then upload back to validate the new settings.
  • Page 57 (10) (11) (12) (13) (14) (15) (16) (17) (18) (19) (20) <user password> (0)0002D1040011 (10) (11) (12) (13) (14) (15) (16) (17) (18) (19) (20) <more guests enabled> <more guests interval> [LAYOUT] <layout type> <font color> <background color> <logo type> <background type>...
  • Page 58 <com speedlink name> [NETWORK] <install enabled> <ppp enabled> <ethernet address> 00-02-D1-04-00-11 <host ip> 192.168.0.207 <subnet mask> 255.255.255.0 <gateway ip> 0.0.0.0 <primary name server> 0.0.0.0 <secondary name server> 0.0.0.0 <ntp enabled> <network timing server> <smtp mail server> <mail recipient address> <mail return address> Video Server <backup smtp mail server>...
  • Page 59 <bacup ftp username> <backup ftp password> <backup ftp init path> <backup ftp passive> <http server port> <bandwidth limit> [VIDEO] <camera modulation> AUTO NTSC <overlay timestamp> <caption text> <colored video> <video quality> <default size> <brightness> <contrast> <hue> <saturation> [SERIAL1] <data bits> <stop bits>...
  • Page 60 RS232 <speedlink commands> <custom ccd commands> HOME DOWN LEFT RIGHT TELESCOPE WIDE NEAR [ALERT] <script file enabled> <motion detection channel enabled> <snapshot channel enabled> <series snapshot channel enabled> <application mode> <visual alert> <upload method> <file with time suffix> <percentage of object size over screen> <percentage of sensitivity>...
  • Page 61 <time to start snapshot> 00:00:00 <time to stop snapshot> 00:00:00 [DEMO] <demo enabled> <PTZ enabled> <video is open> 24 hours format 24 hours format or YES or YES or YES - 60 -...
  • Page 62: Telnet Commands

    Telnet Commands Video Server has a Telnet daemon for only administrators to access some seldom used functions. Using any general terminal program to connect to Video Server will prompt the user for a password. Username is not requested here since only administrators can access the Telnet daemon.
  • Page 63: Erase Snapshots Stored In Flash Memory

    Erase snapshots stored in Flash memory Typing "erase image" will clear all snapshots saved in Flash memory. Erase logo and graphic buttons Typing "erase graph" will clear all images used on the homepage. If no new images are uploaded, the system will switch to text mode and use default images instead. Skip installation at next boot Typing "lock"...
  • Page 64: Appendix

    Appendix A. Troubleshooting Power-On-Self-Test After the power has been turned on, Video Server will perform a self-diagnostic to detect any possible hardware defects. If the power indicator is dim at the beginning, the system fails to proceed further without power. While the POST is proceeding, the status LED indicators will keep blinking interchanged until finished or any fatal error happens.
  • Page 65: Frequently Asked Questions

    B. Frequently Asked Questions Q Why can’t I see the Video Server in the installer after reboot? A The installer is only used to install the IP address of Video Server. If the IP address is fixed by checking the option in the installer, the Video Server will no longer appear in the installer.
  • Page 66 Q How can I use a name instead of the IP address to connect Video Server? A To allow users to connect to Video Server through an easily memorized name, the administrators must first configure the name server in his network. Here is an example: the administrator installs the Video Server with a reserved IP address and assigns it with a name in the domain name service, then users can connect to Video Server by typing a name instead of IP address.
  • Page 67 2. bandwidth share, 3. number of users, 4. number of video inputs are accessed at one time, 5. the complicated objects in view results in larger image file, 6. the level of your PC or notebook which is responsible of displaying images. In general, the transfer rate in general local network environment can achieve over 200 kilobytes per second and approximately 10 to 20 pictures of normal environment per second.
  • Page 68 A If user has defined the snapshot interval, Video Server will capture images periodically as pre-alarm stage. Once the pre-defined condition is match, the pre-alarm images will be kept and the current images will be saved. The subsequent images will be stored as post-alarm stage.
  • Page 69: Upgrade System Firmware

    C. Upgrade System Firmware Customers can frequently check the appropriate product folder on our web site to download the latest firmware. Only administrators can upgrade the system firmware of Video Server. Easy way via Upgrade Wizard Run the Upgrade Wizard included in the product CDROM and proceed by the prompts. Refer to the user's guide of Upgrade Wizard for details.
  • Page 70: Url Commands Of Video Server

    D. URL Commands of Video Server For some customers who already have their own web site or web control application, Video Server can be easily integrated through convenient URL. This section lists the commands in URL format corresponding to the basic functions of Video Server. Some RFC standards related to HTML may be a good reference for implementation of the customized homepage.
  • Page 71: System Resource Url

    System resource URL There are some images used on the homepage when the homepage layout is in image mode. Administrators may use the following links to show the images saved in Video Server on another page. To change the logo or the background images referenced by the URL, refer to the homepage layout section in configuration.
  • Page 72: General Format Of Command Url

    General format of command URL Every configuration can be set through URL with POST method by administrators only. <general format> URL[?[name=value][&name=value]……] <method> POST <authorized user> root System configuration URL URL: /cgi-bin/system.cgi NAME VALUE host <text string shorter than 15 characters> method keep auto...
  • Page 73: Network Configuration Url

    characters> slow <not required> open <not required> camctrl <not required> demoioallowed <not required> slow <not required> delay <integer> Network configuration URL URL: /cgi-bin/network.cgi NAME VALUE reset <other than yes> <IP address> subnet <IP address> router <IP address> domain <text string shorter than 40 characters>...
  • Page 74: Video Configuration Url

    mailto2 <text string shorter than 80 characters> returnmail <text string shorter than 80 characters> ftp1 <domain name or IP address> primary FTP server ftprp1 <number less than 65535> ftpuser1 <text string shorter than 15 characters> ftppass1 <text string shorter than 15 characters>...
  • Page 75 Detailed Excellent mode Auto NTSC higher resolution highest resolution let Video Server detect video modulat set directly to NTSC type set directly to PAL type - 74 -...
  • Page 76: Image Quality Configuration Url

    Image quality configuration URL URL: /cgi-bin/image.cgi NAME VALUE brightness <-5 ~ 5> contrast <-5 ~ 5> <-5 ~ 5> saturation <-5 ~ 5> preview <not required> restore <not required> save <not required> Motion detection configuration URL URL: /cgi-bin/motion.cgi NAME VALUE <integer>...
  • Page 77: Custom Camera Configuration Url

    COM configuration URL URL: /cgi-bin/serial1.cgi NAME VALUE interface RS232 RS485 detect generic modem none driver Sony VISCA Canon VCC1 Canon VCC3 Canon VCC4 DynaDome/SmartDOME Pelco D protocol Lilin PIH-7x00 Ernitec Custom Camera Custom camera configuration URL URL: /cgi-bin/serialportsettings.cgi NAME VALUE baud1 <integer>...
  • Page 78: Camera Custom Command Configuration Url

    Camera custom command configuration URL URL: /cgi-bin/cuscom.cgi NAME VALUE <text string shorter than 80 characters> down1 <text string shorter than 80 characters> left1 <text string shorter than 80 characters> right1 <text string shorter than 80 characters> home1 <text string shorter than 80 characters>...
  • Page 79: Camera Preset Configuration Url

    Camera preset configuration URL URL: /cgi-bin/camerasetting.cgi NAME VALUE addpos <text string shorter than 40 characters> add preset position delpos <existing position name> Modem configuration URL: /cgi-bin/serialmodem.cgi NAME VALUE dialout method Tone (ATDT) Pulse (ATDP) reatt <integer> discon <integer> init <text string shorter than 40 characters> phone1 <text string shorter than 40 characters>...
  • Page 80 <not required> <not required> <not required> sbegin <hh:mm:ss> send <hh:mm:ss> <not required> enfile <not required> emode <not required> showalert <not required> mdmode <not required> dihigh <not required> dilow <not required> dirise <not required> difall <not required> delay <integer> ioalarm <not required> mdalarm <not required>...
  • Page 81: Homepage Layout Configuration Url

    Homepage layout configuration URL URL: /cgi-bin/layout.cgi NAME VALUE cuslogo blank logourl <text string shorter than 80 characters> linkurl <text string shorter than 80 characters> cusback blank backurl <text string shorter than 80 characters> fcolor <0 ~ 15> bcolor <0 ~ 15> dismode image text...
  • Page 82: Settings Of Supported Ptz Cameras

    E. Settings of Supported PTZ Cameras Since the COM port settings can be adjusted to other than the default settings, check the correct default settings for the attached camera. Camera model Baud rate Sony VISCA 9600 Canon VC-C1 9600 Canon VC-C3 9600 Canon VC-C4 9600...
  • Page 83: Camera Control Cable

    F. Camera Control Cable The included cable can be used to control motorized cameras of desktop types from Sony and Canon. The pin assignment is illustrated in the following chart. To control cameras of another brand, check the user’s manual of the motorized camera if the pin assignment of the control cable is appropriate.
  • Page 84: Time Zone Table

    G. Time Zone Table While setting the time zone in automatic date/time synchronization, find the hour offset in the followings for your region. GMT stands for Greenwich Mean Time, which is the global time that all time zones are measured from. (GMT–12:00) International Date Line West (GMT-11:00)
  • Page 85 (GMT+01:00) West Central Africa (GMT+02:00) Athens, Istanbul, Minsk (GMT+02:00) Bucharest (GMT+02:00) Cairo (GMT+02:00) Harare, Pretoria (GMT+02:00) Helsinki, Kyiv, Riga, Sofia, Tallinn, Vilnius (GMT+02:00) Jerusalem (GMT+03:00) Baghdad (GMT+03:00) Kuwait, Riyadh (GMT+03:00) Moscow, St. Petersburg, Volgograd (GMT+03:00) Nairobi (GMT+03:30) Tehran (GMT+04:00) Abu Dhabi, Muscat (GMT+04:00) Baku, Tbilisi, Yerevan (GMT+04:30)
  • Page 86 (GMT+10:00) Hobart (GMT+10:00) Vladivostok (GMT+11:00) Magadan, Solomon Is., New Caledonia (GMT+12:00) Auckland, Wellington (GMT+12:00) Fiji, Kamchatka, Marshall Is.. (GMT+13:00) Nuku’alofa - 85 -...
  • Page 87: Technical Specifications

    H. Technical Specifications System CPU: Trimedia PNX1300 RAM: 16MB SDRAM ROM: 2MB FLASH ROM Networking Adjustable bandwidth limit Protocol TCP/IP, HTTP, SMTP, FTP, Telnet, NTP, DNS and DHCP Modem PPP (dial-up, direct cable connection) Ethernet 10BaseT Ethernet or 100BaseT Fast Ethernet Video Algorithm Supported MJPEG...
