minutes" will force Video Server to drop the connection when there is no activity on the connection for
the specific period. The range of this period is from 1 to 240 minutes, with 0 indicating a continuous
connection. Administrators may let Video Server keep the connection for a while to allow connections
from outside. The IP address given by the ISP can be taken from the connection log that is mailed or
uploaded when dial-up connection is successful. Setting the value to zero will make Video Server always
keep the connection.
Based on the settings of DI/DO in the application, the system will send mail or upload via FTP with
image attachment upon the event occurring. In that case Video Server will need a network connection and
automatically dial out to the pre-configured server outside. When a connection is successfully established,
Video Server will send out a connection log to notify given network settings. For those installations that
may switch the network interface between Ethernet and PPP, administrators should notice that the settings
of FTP or SMTP servers might be different from what is in an Ethernet environment. If the network
interface is changed, administrators may need to configure them in advance.
Video Server will try the second ISP as a backup when the first ISP fails and exceeds the redial attempts.
"ISP phone numbe r" should be the complete phone number including country code and area code if
necessary. "Login use rname" and "Login password" are used to pass the PPP negotiation requested by
the ISP server. Note that the pair of login name and password is dependent on the ISP and is different
from what is used in the authentication process in web access.
When using modem as the network connection, Video Server will mute the audio automatically, and
send video only because the low bandwidth environment doesn't meet the requirement for both. In the
Client setting page, protocol option will be set as Http protocol.
