URL commands of Video Server

For some customers who already have their own web site or web control application, Video Server can be
easily integrated through convenient URLs. This section lists the commands in URL format
corresponding to the basic functions of Video Server. Some RFC standards related to HT ML may be a
good reference for implementation of the customized homepages.

Capture update Snapshot of JPEG image

/cgi-bin/video.jpg

Move motorized camera in PTZ direction

<direction>: up, left, right, down, home
<vision>: wide, tele
<command>: 1, 2, 3, 4, 5
/cgi-bin/camctrl.cgi?move=<direction>&zoom=<vision>&cust=<command>

Preset/Recall camera position

/cgi-bin/recall.cgi?recall="POSIT ION"
, where " POSIT ION" denotes the text string of a location that is preset in system configuration.

Query status of digital inputs

/setup/getdi.cgi
Video Server will return status of digital input.

Drive digital outputs

/setup/setdo.cgi?do=<state>
, where state is H, L. H means NC connected with COMMON and L means NO connected with
COMMON.
For example, http://192.168.0.201/setup/setdo.cgi?do=h will command Video Server, with IP address of
192.168.0.201, to set digital output to connect to NC with COMMON.
