Removal of the pick-up pump

- Remove the 2 screws from the sheathing
holder plate.
- Remove the bushing (1) and the protective
rubber (2).
Check the condition of the
bushing and the rubber protection.
- Remove the piston (3).
Removal of the pick-up pump suction
valve
- Remove the jet.
- Remove the spring.
- Remove the ball.
Removal of the deceleration
enrichment device
- Remove the 2 bolts that secure the cover.
- Remove the cover.
- Remove the spring.
- Remove the membrane.
- Remove the O ring.
Check that the membrane is in
good condition.
Check the condition of the O-ring.
Reproduction or translation, even partial, is forbidden without the written consent of Peugeot Motocycles
1
2
FUEL SYSTEM
3
53
