No.
Symbol
1
2
3
4
5
-
Display
Input
Output
Load
Storage cells
Mode/Error/Warning
Inverter
Bypass
Output voltage, frequency, BYBASS mode option
2011/07/22
POWERLINE 11 series UPS – Instruction Manual
Name
If the unit is in BYPASS mode or zero mode (STANDBY), pressing this button
SELECT
allows you to configure the unit's parameters: output voltage, frequency,
BYBASS mode options. To approve the selection, press ENTER (2)
If the unit is in BYPASS mode, parameters set by means of the SELECT key
ENTER
may be approved by pressing ENTER.
When the power supply is regular, pressing the OFF button causes the unit to
OFF
switch to BYPASS mode and turns off the inverter. If the BYPASS mode option
is available, the outlet is powered from the BYPASS line
Turns the unit on
ON
Deactivates sound alarms.
LCD
LCD
Description
Input voltage value
Input voltage frequency
Indicates excessively high input voltage; not displayed if the voltage is regular
Indicates excessively low input voltage; not displayed if the voltage is regular
Output voltage value
Output voltage frequency
Unit load in W or VA
Indicates short-circuit of the unit's output
Indicates unit overload
Storage cells voltage value
Charge level of storage cells
Indicates overload of the storage cells; the unit will switch to battery mode
Indicates that the storage cells are discharged; the unit will soon switch off
Displays the unit's mode, error codes and warnings
Indicates the operational status of the inverter
Indicates the operational status of the BYPASS circuits
If the unit is in STANDBY or BYPASS mode, one of the four output voltage values may be
selected
If the unit is in STANDBY or BYPASS mode, one of the two input voltage frequency values
may be selected
If the unit is in STANDBY or BYPASS mode, one of the two BYPASS mode options may be
selected
Description
www.ever.eu
5
