Thank you for purchasing the EVER POWERLINE battery back-up. It belongs to
the latest series of state-of-the-art power supply devices designed to work with
servers, computer networks, as well as data processing systems.
EVER POWERLINE series UPS was designed so as to meet all your expectations
for protection against power loss.
The following manual contains information on operating the device and safety rules.
Familiarising yourself in detail with the manual prior to using the EVER POWERLINE
UPS will help you operate the device correctly.

PURPOSE OF THE POWER SUPPLY

POWERLINE series battery back-ups are ONLINE-class (VFI) devices designed for
work with equipment powered by monophase ~230V mains.
WARNING! POWERLINE battery back-ups were not designed to
work with medical equipment, in particular life and/or health
support devices.

General features of the battery back-up

POWERLINE battery back-ups consist of the following functional units:
•
rectifier unit with PFC (power factor correction),
•
accumulator charger,
•
accumulator unit in a battery module
•
inverter manufactured in high-frequency IGBT technology,
•
automatic bypass system,
•
manual (service) bypass system,
•
microchip control system with measurement units.
The input inverter converts the AC energy into an internal DC bus. The power factor
correction (PFC) system enables a radical reduction of interference transmitted to the
power system. The DC bus is the basic power source for the inverrter creating
a nominal AC true sine wave used to power the receivers. An independent charger is
responsible for charging the accumulator. Its distinctive feature is a very low
