High-resolution CCD Camera
Model CS3920
Operation Manual
Enter the blank below Product Serial Number, which is found on bottom/rear
chassis of your camera. Keep this number for your record.
Model No. CS3920
Serial No.
TOKYO ELECTRONIC INDUSTRY CO., LTD.
2000-04-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS3920 and is the answer not in the manual?

Questions and answers

Summary of Contents for Teli CS3920

  • Page 1 High-resolution CCD Camera Model CS3920 Operation Manual Enter the blank below Product Serial Number, which is found on bottom/rear chassis of your camera. Keep this number for your record. Model No. CS3920 Serial No. TOKYO ELECTRONIC INDUSTRY CO., LTD. 2000-04-07...
  • Page 2: Table Of Contents

    Thank you for purchasing our CS3920 B/W CCD camera. This operation manual contains some important information such as how to use this equipment correctly and safely. Please read through this manual carefully. After reading, keep this manual by the side of your equipment for your future reference.
  • Page 3: Handling Precautions

    BEFORE USING THE CAMERA ― GENERAL SAFETY INSTRUCTIONS This Operation manual contains important information for the operator (user) and/or people around him/her to avoid personal injuries, or property damages against him/her or people around him/her by using this product correctly. Prior to use, read this operation manual carefully to fully understand its instructions for correct use.
  • Page 4 If any foreign object gets into the camera, discontinue the use immediately. In the event that liquids, small particles, or any other foreign objects get into the camera, do NOT try to continue to use the camera. To do so invites a fire or an electric shock hazard.
  • Page 5 CAUTION Do NOT connect/disconnect connectors with power ON. Before connecting/disconnecting connectors, make sure to check if the system is powered OFF. Doing so with power ON may cause a damage or an electric shock accident. Do NOT give a strong shock/impact against the camera-head. Avoid giving a strong shock against the camera head.
  • Page 6: Restriction For Use

    RESTRICTION FOR USE Do not attempt irregular signal interface other than specified. Under signal interface other than recommended/specified in this instruction manual, the camera might fail to exert the maximum performance. In much worse case, if you continue to use the camera under incorrect signal interface, part(s) of circuits might burn down.
  • Page 7: Product Description

    1. Product description Model CS3920 is an integrated (one-body) type B/W CCD camera employing a 1/2” type frame-read-out CCD, featuring its ultra-high resolution of active 2,000,000 pixels. 2. Features (1) Ultra-high resolution CS3920 features an ultra-high picture resolution through the adoption of a MEGA-pixel CCD (Total pixel counts: 2,100,000 Active pixel counts: 2,000,000 [1,636(H)×...
  • Page 8: Designations And Workings Of Each Part

    5. Designations and workings of each parts ①DC IN/SYNC: DC+12V Power IN, Analog Video OUT, and TRIG/WEN Terminal This connector is for connection with a power supply, image processing equipment ②DATA OUT Connector: Digital Data Output Terminal This terminal is for outputting video signal and HD, VD, and CLK in RS-644 format. For connection with an image processing equipment.
  • Page 9: How To Mount The Camera

    6. How to mount the camera (1)Option 1 : Using a camera tripod fixing kit Use an optional tripod fixing kit to fix the camera onto the tripod. (See the diagrammatic sketch shown below) (2)Option 2 : Using the mounting holes (Camera flange) Put M3 screws through these holes (2 places) to fix the camera.
  • Page 10: Connection

    7. Connection (1)DC IN/SYNC Connector (Camera side): HR10A-7R-6PB (Manufactured by HIROSE DENKI) Plug (Cable side): HR10A-7P-6S (Manufactured by HIROSE DENKI) Pin number Signal name VIDEO VIDEO.GND TRIG +12V (2)DATA OUT Connector (Camera side): DX10A-28S (Cable side): DX30A-28P, DX-28-CV1 (Cover) Pin. Signal name Pin.
  • Page 11: Setting

    8. Setting Setting of each mode can be done with SW1 on PROCESS board (the top board inside). To select modes, slide DIP switches numbered 1 through 8. The status is OFF when SW is in left position, ON when in right position. Rear Panel SW (Left: OFF ―...
  • Page 12 (3)Shutter Speed (SW1 DIP4, 5&6) (Initial-Factory-Setting: DIP4, 5&6 OFF) DIP4 DIP5 DIP6 Shutter Speed 1/30s 1/60s 1/125s 1/250s 1/1000s 1/2000s 1/5000s 1/10000s (4)FLD Output / FRM Output Selection (SW1 DIP7) (Initial-Factory-Setting: OFF) OFF: Field output ON: Frame output Under OFF (= FLD) setting, only the 1st field data is output in response to one trigger input.
  • Page 13: Specifications

    9. Specifications Model CS3920 TV system Non standard Image sensor FRM readout CCD Total pixel 1688(H)×1248(V) Active pixel 1636(H)×1236(V) Unit cell size 3.9(H)×3.9(V)μm Optical size 1/2 type equivalent Scanning system Interlace Scanning frequency 9.74kHz(H) 15Hz(V) or 30Hz(V)(30Hz under High-speed Draft Mode)
  • Page 14: Timing Chart

    10. Timing chart 10-1. Analog output (1) H rate 1CLK = 55.5ns (18MHz) H-SYNC A = 40CLK=2.22μs B = 212CLK=11.77μs Front porch C = 40CLK=2.22μs Back porch D = 132CLK=7.33μs DATA E = 1636CLK=90.9μs H rate F = 1848CLK=102.7μs=9.74kHz (2) V rate Normal read-out mode (Interlace 1-field) High-speed draft mode A = 3H...
  • Page 15 ENLARGED VIEW, V-RATE, A VIDEO H rate a = 102.7μs V.SYNC b = 2.22μs ・WEN Output High: 1 VIDEO Low: 2 VIDEO...
  • Page 16 10-2. Digital output terminal EIA RS-644 (LVDS) Driver output voltage: ±350mV [Differential output] / 100Ω DATA 115CLK 97CLK 1636CLK 1848CLK Total clock counts 1848CLK / 1H DATA counts 1636CLK / 1H 55.5ns *=Delay V rate phase: Same as one in analog timing-chart 1st field 2nd field Digital output: Field ID signal superposed 1 line ahead of VS...
  • Page 17 10-3. Video output timing (1) Under normal operation (Electronic shutter) (Frame readout: Interlace) Exposure-time (Inner DIP SW) (Exposure) Video output 1 frame (2) Under random trigger shutter operation (Frame output) (Under this mode, 1-frame video is output. As the camera performs twice exposure under this mode, this mode is suited for still-image shooting) -1.
  • Page 18 (3) Under random trigger shutter operation (Field output) (Under this mode, only 1-field video is output after one exposure. This mode is suited for moving-subject shooting, but vertical resolution will be reduced into half) -1. Fixed speed mode (1FLD output) Exposure (Via inner DIP SW) TRIG...
  • Page 19: External-View Drawing

    11. External-view drawing...
  • Page 20 TOKYO ELECTRONIC INDUSTRY CO.,LTD. Head Office : 4-7-1, Asahigaoka, Hino-shi, Tokyo 191-0065, Japan Phone: +81-(0)42-589-8771 FAX: +81-(0)42-589-8774 Kansai Branch : Nitto Building, 2-1-2, Sakaemachi-dori, Chuo-ku, Kobe, Hyogo 650-0023, Japan, Phone : +81-(0)78-321-3461 FAX : +81-(0)78-321-3463 Fukuoka Office : Yen Building, 2-7-21, Hirao, Chuo-ku, Fukuoka 810-0014, Japan Phone : +81-(0)92-523-3395 FAX : +81-(0)92-523-3397...
