Page 1: Instruction Manual
Version 1.8 CCD COLOR CAMERA CS5260D/CS5260DP INSTRUCTION MANUAL OWNER’S RECORD Enter the blank below Product Serial Number, which is found on bottom/rear chassis of your device. Keep this number for your record. Serial No. Tokyo Electronic Industry Co.,Ltd... -
Page 2: Table Of Contents
7. How to set up the camera 8. Specifications 9. How to mount the camera 10. Caution : Operation under heavy vibration 11. Attached drawings : Ex-view of CS5260D/DP 12 Maintenance BEFORE USING THE CAMERA GENERAL SAFETY INSTRUCTIONS This instruction manual contains important information for the operator(user) and/or people around him/her to avoid personal injuries, or property damages against him/her or people around him/her by using your purchase correctly. - Page 3 The camera is designed to work only under specified voltage. Do NOT attempt to drive the camera with the power other than DC9V. Operating the camera under power other than DC12V may leads to a fire or a electric shock hazard. Do NOT use the camera under high-humidity-condition, such as, a place near a humidifier.
-
Page 4: Product Descriptions
In case damages or losses are caused by repair or modification by the user. 1. Product descriptions The CS5260D/DP is a one-piece type (*) CCD color camera with a ultra-compact & light-weight body. [*One-piece type : One integrated body made up of the camera head & the camera control unit] 2. -
Page 5: Connection(Recommendation)
5. Connection(recommendation) CAMERA CABLE CPRC5260D (optional accessory) CAMERA CCD COLOR CAMERA ADAPTER CA5260 CS5260D/DP ( ti AC100V 50/60Hz AC100V NOTE 50/60Hz SET 75 video output... -
Page 6: Control Of Inner Selection Switches
6. Control of inner selection switches (1)The inner structure The inner structure of this camera is shown as follows. The side-view of a CS5260D/DP without the cabinet S201 The top-view of a CS5260D/DP without the cabinet CONTROL BOARD Initial factory-setting... -
Page 7: How To Set Up The Camera
Shutter speed setting SW (Refer to table 5) S201 12dB 18dB *The initial factory setting NTSC:Electronic shutter speed 1/60s, Gain 0dB PAL :Electronic shutter speed 1/50s, Gain 0dB Table 5 Shutter speed (s) S201 CS5260D CS5260DP 1/60 1/50 1/100 1/120 1/250 1/250 1/500 1/500... -
Page 8: Specifications
8.Specifications (*The specs of PAL type which differ from those of NTSC type are shown in [ Model CS5260D [CS5260DP] TV system NTSC [PAL] Image sensor Interline CCD Total pixels 811(H) 508(V) [795(H) 596(V)] Active pixels 768(H) 494(V) [752(H) 582(V)] Pixel size 8.4 m(H) 9.8 m(V) -
Page 9: How To Mount The Camera
9. How to mount the camera There are several alternative ways to fix the camera. Choose your method among the following options. (1) Option 1: Using a camera tripod fixing kit Use an optional tripod fixing kit to fix the camera onto the tripod. Use attached screws to affix tripod-mounting hardware to your camera. -
Page 10: Caution : Operation Under Heavy Vibration
10 Caution : Operation under heavy vibration If the camera and the camera cable are used under heavy vibration, it may be possible that the pins of DC IN connector break. To prevent this from happening, fix the camera cable near the connection point, or use the fixing hardware as shown below (option) to eliminate rattling to protect the pins. -
Page 11: Attached Drawings : Ex-View Of Cs5260D/Dp
11. Attached drawings : Ex-view of CS5260D/DP... -
Page 12: Maintenance
(2) When the cabinet is dusty, clean by gently wiping with a soft close. And avoid the use of strong cleaning agents such as benzine or alcohol as they may damage the cabinet. (3) If malfunctioning occurs, stop using equipment immediately and consult TELI-service shop, the dealer purchased from or qualified personnel’s.
