Rev 1.0
High-Resolution CCD Color Camera
MODEL CS6940CL

Specifications

Contents
1. Overview ...............................................................................1
2. Features .................................................................................1
3. Configuration ........................................................................1
4. Optional parts ........................................................................2
5. Specifications ........................................................................2
6. Serial control .........................................................................9
7. Explanation of operation .....................................................10
8. Outline Drawing..................................................................14
9. Cases for indemnity (Limited warranty) .............................15
10. Restriction for use .............................................................15
Printed on recycled paper
D4134176A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS6940CL and is the answer not in the manual?

Questions and answers

Related Manuals for Teli CS6940CL

Summary of Contents for Teli CS6940CL

  • Page 1: Table Of Contents

    Rev 1.0 High‐Resolution CCD Color Camera MODEL CS6940CL Specifications Contents 1. Overview ...1 2. Features ...1 3. Configuration ...1 4. Optional parts ...2 5. Specifications ...2 6. Serial control ...9 7. Explanation of operation ...10 8. Outline Drawing...14 9. Cases for indemnity (Limited warranty) ...15 10.

  • Page 2: Overview

    1. Overview This CCD color camera is a high-resolution color camera that features all pixel readout mode 1/1.8 CCD. 2. Features (1) High resolution Bayer array high pixel density CCD (number of effective pixels 2.01 M, number of total pixels 2.11 M) is used. (2) Square grids The CCD pixels arrayed in square grids facilitates computation for image processing.

  • Page 3: Optional Parts

    4. Optional parts (1) Power cable (2) Camera Link cable (3) Camera adapter (4) Camera mounting kit *NOTE: Application software is not supplied as a standard item. Notes on optional parts and compliance with safety standard conditions: We assure the compliance of this camera with the safety standard when it is used in combination with the optional parts listed above.
  • Page 4 (13) Power supply voltage (14) Power consumption ［Electronic shutter specification］ (1) Shutter speed ・Readout mode All pixel readout Partial scan High-speed draft readout (2) Random trigger shutter ・Fixed mode ・Pulse width mode (3) Multiple-shutter [Internal sync signal specification] (1) Driving frequency (2) Scanning frequency ・Readout mode All pixel readout...
  • Page 5 [Output signal specification] (1) WEN ・Signal level ・Polarity ・Pulse width ［Dimensions］ (1) Lens mount (2) Flange back (3) Dimensions (4) Mass (5) Camera body grounding: insulation status ［Operating ambient conditions］ (1) Performance assurance ［Typical spectral response］ The lens characteristics and light source characteristics is not reflected in table. ［Applicable safety standards］...
  • Page 6 ［Communication specification］ (1) Communication speed (2) Data bit (3) Parity (4) Stop bit (5) Parity bit (6) Handshake [Connector pin assignment] (1) Video output/controlling connector (Camera Link Base Configuration) CAMERA LINK ・Connector model Pin No. Tx CLK OUT- Ser TC（RxD）+ Ser TFG（TxD）- CC1（TRIG）- CC2（MULTI）+...
  • Page 7 [Switch setting] By using the DIP switches on the back surface of the camera body, you can set serial transmission speed and memory readout for when the power supply is turned on. (1) Transmission speed setting You can set the speed of serial transmission by camera link (2) Memory readout setting You can set the number of the setting value saving memory bank to be called when the power supply is turned on.
  • Page 8 ［Timing chart］ (1) Horizontal timing 1) All pixel readout, Partial scan LVAL DVAL DATA OUT a = 185CLK 2) High-speed draft readout LVAL DVAL DATA OUT a = 185CLK b = 107CLK c = 292CLK b = 587CLK c = 772CLK d = 1628CLK e = 1920CLK d = 1628CLK...
  • Page 9 (2) Vertical timing 1) All pixel readout FVAL LVAL DVAL DATA OUT A = 3H 2) Partial scan FVAL LVAL DVAL DATA OUT A = 3H 3) High-speed draft readout FVAL LVAL DVAL DATA OUT A = 3H B = 10H C = 13H D = 1236H B = 41H...

  • Page 10: Serial Control

    6. Serial control You can control following functions in camera link I/F. (1) Memory control ・Save ・Load ・Reset (2) Readout mode setting (3) Random trigger shutter setting ・trigger polarity ・Random trigger mode (4) Multiple‐shutter (5) Shutter settino ・AE setting ・MANU setting (6) Gain setting (7) Setup setting (8) White balance setting...

  • Page 11: Explanation Of Operation

    7. Explanation of operation 7.1 Readout mode Video is output from the camera link connector. The output video can be grabbed by the frame grabber board. The frame rate and resolution of output images that this model supports are as follows: 1) All pixel readout 2) Partial scan 3) High-speed draft readout : Approximately 48 fps / 1628(H) x 309(V)
  • Page 12 2) Partial scan Skips the top and bottom of the effective area and reads out 552 lines in the center area in approximately 1/30 second. FVAL LVAL DVAL DATA OUT 3) High-speed draft readout By reading 2 lines out of every 8 lines, reads out the whole valid area in approximately 1/48 seconds. FVAL LVAL DVAL...
  • Page 13 7.2 Random trigger shutter In the random trigger shutter mode, you can shoot and grab an image at an arbitrary timing by trigger signal input from the external. ・External trigger signals can be input either from the camera link I/F CC1 or DC IN connector. ・If polarity is set to negative polarity, exposure starts at the falling edge of the trigger.
  • Page 14 7.3 Multiple-shutter mode In the multiple-shutter mode, video is output in sync with a MULTI signal from the external after the end of exposure time. ・Valid only when the random trigger shutter mode is ON. ・MULTI signals can be input from the camera link I/F CC2. ・If exposure is executed several times before MULTI signal input, the images are output superposed.

  • Page 15: Outline Drawing

    Rev 1.0 8. Outline Drawing D4134176A...

  • Page 16: Cases For Indemnity (Limited Warranty)

    9. Cases for indemnity (Limited warranty) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions.
  • Page 17 (Overseas Sales Department) Phone : +81-42-589-8771 : +81-42-589-8774 : http://www.toshiba-teli.co.jp Distributor • This product must be classified for disposal according to the laws of each country and municipal laws. • Information contained in this document is subject to change without prior notice.
