B/W CCD Camera
Model CS3720
Operation Manual
TOKYO ELECTRONIC INDUSTRY CO., LTD.
2000-08-07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS3720 and is the answer not in the manual?

Questions and answers

Related Manuals for Teli CS3720

Summary of Contents for Teli CS3720

  • Page 1 B/W CCD Camera Model CS3720 Operation Manual TOKYO ELECTRONIC INDUSTRY CO., LTD. 2000-08-07...

  • Page 2: Handling Precautions

    BEFORE USE ------ GENERAL SAFETY INSTRUCTIONS This instruction manual contains important information for the operator(user) and/or people around him/her to avoid personal injuries, or property damages against him/her or people around him/her by using this product correctly. Prior to use, read this operation manual carefully to fully understand its instructions for correct use.
  • Page 3 If any malfunctioning sign is observed, discontinue the use immediately. NOT try to use the camera when it is malfunctioning. (Ex. No images on the monitor) In the event of malfunction, turn the power switch of the system OFF immediately, and remove the camera cable from the camera connector. In such case, contact us or our dealer/distributor from which you purchased the camera for repair service.
  • Page 4 Avoid shoat-circuiting its signal output. Otherwise, the camera might be damaged. If too much amount of light, (= the incoming light amount of 100 times or greater in comparison with standard light) enters CCD image pickup plane, video output might not be obtained.

  • Page 5: Table Of Contents

    IMPORTANT SAFETY INSTRUCTIONS (1) Use DC12V power. Avoid using any other unspecified power source. (2) This device is designed and guaranteed to work under the temperature range of 0 through 40 degree C. Avoid using the equipment beyond that limits. (3) Do NOT expose the camera’s image-pickup-plane to sunlight or other intense light directly.

  • Page 6: Product Description

    1. PRODUCT DESCRIPTION Model CS3720 is a separated-type (two-body) B/W CCD camera with all-pixel-data readout CCD. This model has twice greater driving frequency of CS3710 to achieve fast-speed data-processing. The model is suited for high-speed, high-resolution image processing use. 2. FEATURES (1) Double-speed scan This model reads out image-data twice as fast as conventional cameras do.

  • Page 7: Configuration

    3. CONFIGURATION (1) Camera head (With a 3.0m directly-fixed camera-cable) (2) Camera Control Unit (3) Accessory Operation Manual 4. OPTION UNIT (1) DC SYNC IN cable (Model name: CPRC3700) (2) Camera adapter (Model name: CA170) (3) Camera mounting kit 5. FUNCTION / LOCATION OF SWITCHES AND OTHERS 1: POWER Power ON / OFF selection SW 2: SHUTTER.

  • Page 8: Operation Mode

    6. OPERATION MODE (1)GAIN selection (CCU front-panel SW) MANU: Gain is adjustable via the manual gain potentiometer (GAIN) FIX: Factory-prefixed gain (2)Video output mode selection (CCU front-panel SW) 1/120: 1/120s----- 2:1 interlace mode (Dual-line output) 1/60: 1/60s----- Non-interlace mode (Single-line output) (3)Shutter mode selection (CCU front-panel SW) NOR mode: Normal electronic shutter ----- High-speed shutter: From 1/20,000s through OFF (8 position)
  • Page 9 (5)Partial-scan mode selection IMPORTANT Sometimes, white blooming is observed at the upper side of the screen when intensive light enters the image-pickup-area in a wide angle. This phenomenon is not attributable to malfunction of the camera. If the white blooming occurs, try and reduce the amount of incoming light.
  • Page 10 *1 Under ex-sync, user-defined value.
  • Page 11 Under 1/60 non-interlace, the screen-center 226H is readout out of effective 492H lines (= excluding BLK lines). This works both under internal and external sync operation. 1/60s Non-interlace *1 High-speed Transfer *2 Normal-speed Transfer *3 High-speed Transfer *2 Normal-speed Transfer *1: Under ex-sync user-defined value.
  • Page 12 (5-2) PROGRAMMABLE: Readout portion programmable mode (Inner SW 1-2 OPT, SW 1-3 ON) In this mode, the readout portion is programmable via external pulse. High-speed transfer segment is set with partial pulse input. This works under external synchronization only. An example is shown below.
  • Page 13 Example: Readout portion --- Upper part of image (Upper part of “A”, 70H, out of total effective pixel 485H) 1/120s 1st Field VIDEO1 OUT VIDEO2 OUT VIDEO1 OUT 1st Field VIDEO2 OUT *1: Under ex-sync, user-defined value...
  • Page 14 PARTIAL PULSE Input Example 1st Field EXT. VD VIDEO1 OUT (Normal) VIDEO2 OUT (Normal) WEN OUT (Normal) Partial Pulse VIDEO1 OUT VIDEO2 OUT (Partial) WEN OUT (Partial) *1 Under ex-sync, user-defined value. *2 “Over-partial” (=More than actual video lines) is OK. *3 Under partial-scan, WEN is output twice.
  • Page 15 (5-3) Reset: Sync-signal reset under partial-scan (Inner SW 1-4 ON) When the inner V-reset switch (SW 1-4) is set in ON position, VD signal will be reset immediately after image readout. This SW is enabled under 1/2 partial-scan mode only, and works under internal sync operation mode.
  • Page 16 (6)Multiple-shutter mode (Works under RTS mode) Under the random trigger shutter mode, consecutive trigger signals give cue for starting CCD exposure, arid image is output at user-defined timing. You can use this shutter mode under external synchronization operation (E.HD, E.VD) only. The video output timing is determined by E.VD.
  • Page 17 (7)Camera control unit inner SW setting (Factory-shipped setting) IMPORTANT To avoid shock hazard, follow the instructions given below. ■ Turn the power of your system OFF first. ■ Remove all connection cables. ■ For making inner SW setting, use an appropriate device available on market. ■...
  • Page 18 (7-2) Inner SW board layout Rear side Front side IMPORTANT All switches other than SW1 is factory-preset. Don’t touch any factory-preset switches. (7-3) Inner SW assignment SHUTTER (FIX/PULSE) PARTIAL (ON/OFF) PARTIAL (1/2 Partial/Programmable) PARTIAL V RESET (ON/OFF) TRIG (NEGA/POS1) NC (OFF Fixed) TEST1 (For factory-check) TEST2 (For factory-check) Inner SW (SW1)
  • Page 19 SW Number Function Shutter-speed PULSE (Electronic shutter) (TRIG width) Partial-scan Normal scan Partial-scan ON/OFF Partial-scan 1/2 Partial Programmable Partial-scan Non-reset V reset V reset TRIG polarity Negative Positive OFF Fixed ----- TEST 1 OFF Fixed ----- TEST 2 OFF Fixed ----- (7-4) Shutter-mode Video Output Mode...

  • Page 20: Connector Connection

    NOT use BNC connector outputs (2 places). If both are used at the same time, you will not obtain correct video signal due to double termination. 8. SPECIFICATIONS Model CS3720 Image sensor All Pixel’s Data Read-out Interline CCD Optical size 1/2 Type (= Equivalent to 1/2”...
  • Page 21 Illumination Standard 400 lx (F5.6) (1/60s Non-interlace mode, GAIN FIX) Minimum 4 lx (F1.4) (GAIN MAX) Gain MANU / FIX Switch-able through front-panel selection MANU (Manual) gain: Setting through GAIN VR FIX (Fixed) gain: Factory-shipped preset level Video output VS 1.0V (p-p) / 75-ohm Resolution 485 lines(H) (Under 1/60s Non-interlace) 350 TV lines(V) (Under 1/120s 2:1 Interlace)
  • Page 22 Spectrum Response the graph below, while (Lens characteristics is reflected in the characteristics of light source is not.) Optical Black Pattern...

  • Page 23: Timing Chart

    9. TIMING CHART (1)1/120s 2:1 Interlace mode Odd Field’s images and Even Field’s images are output in alternating sequence through both Video 1 and Video 2 terminal in 1/120s, with odd Field’s image through one terminal, and even Field’s image through the other terminal at the same timing. VIDEO1 OUT VIDEO2 OUT WEN OUT...
  • Page 24 (3)External-sync, 1/120s Interlace mode, Odd phase (1 Field) EXT. VD EXT. HD VIDEO1 OUT VIDEO2 OUT WEN OUT (4)External-sync, 1/120s Interlace mode, Even phase (2 Field) EXT. VD EXT. HD VIDEO1 OUT VIDEO2 OUT WEN OUT (5)External-sync, 1/120s Interlace mode, Field identification (HD-VD Phase-difference) E.
  • Page 25 (6)External-sync, 1/60s Non-interlace mode EXT. VD EXT. HD VIDEO1 OUT WEN OUT (7)External-sync, 1/60s Non-interlace mode, HD-VD Phase-difference EXT. VD EXT. NO TP1 : 6. 0 µs TP2 : 3. 0 µs...
  • Page 26 (8)Random trigger shutter, FIX Mode (Internal-sync operation) TRIG (Exposure; VIDEO1 OUT VIDEO2 OUT WEN OUT *1: Setting through the CCU front rotary switch. You can set the shutter-speed with the CCU front panel rotary switch. After CCD exposure, VD gets reset in sync with HD to output video signal. Under 1/60s non-interlace, VIDEO 1 OUT only outputs signal.
  • Page 27 (10)Random trigger shutter, PULSE Mode (Internal-sync operation) TRIG (Exposure) VIDEO1 OUT VIDEO2 OUT *1: Determined by TRIG pulse width The shutter-speed is determined by the length of trigger pulse. After CCD exposure, VD gets reset in sync with HD to output video signal. Under 1/60s non-interlace, VIDEO 1 OUT only outputs signal.
  • Page 28 (12)H-rate timing...

  • Page 29: External View

    10. EXTERNAL-VIEW DRAWING (1)Camera-head...
  • Page 30 (2)Camera control unit...
  • Page 31 TOKYO ELECTRONIC INDUSTRY CO., LTD. Head Office: 4-7-1, Asahigaoka, Hino-shi, Tokyo 191-0065, Japan Phone: +81-(0)42-589-8771 FAX: +81-(0)42-589-8774 E-mail: k-amano@teli.co.jp Kansai Branch: Nitto Building, 2-1-2, Sakaemachi-dori, Chuo-ku, Kobe, Hyogo 650-0023, Japan, Phone : +81-(0)78-321-3461 FAX : +81-(0)78-321-3463 Fukuoka Office : Yen Building, 2-7-21, Hirao, Chuo-ku,...
