Teli CS3940 Operation Manual

Hight-resolution
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
High-Resolution CCD Camera
Model CS3940
Operation Manual
Thank you for purchasing our CS3940 CCD camera.
This operation manual includes some important information
such as how to use this equipment correctly and safely.
Please read through this manual carefully.
After reading, keep this manual by the side of your equipment for
your future reference.
Before use - General safety instructions
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
Contents
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
［ ［ ［ ［ Printed On Recycled Paper
Last update 2002/08/06
6
6
6
6
7
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
8
9
･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･ ･
14
16
18
Printed On Recycled Paper］ ］ ］ ］
Printed On Recycled Paper
Printed On Recycled Paper
D4110637B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS3940 and is the answer not in the manual?

Questions and answers

Related Manuals for Teli CS3940

Summary of Contents for Teli CS3940

  • Page 1: Table Of Contents

    Last update 2002/08/06 High-Resolution CCD Camera Model CS3940 Operation Manual Thank you for purchasing our CS3940 CCD camera. This operation manual includes some important information such as how to use this equipment correctly and safely. Please read through this manual carefully.
  • Page 2 Last update: 2002.0806 BEFORE USE - GENERAL SAFETY INSTRUCTIONS This instruction manual contains important information for the operator (user) and/or people around him/her to avoid personal injuries, or property damages against him/her or people around him/her by using this product correctly. •...
  • Page 3 Last update: 2002.0806 ●Handling Precautions DANGER If any overheating sign is observed, discontinue the use immediately. In the event that smoke, smell, or any other overheating sign is observed, turn its power switch OFF immediately and be sure to remove camera cable from camera connector. Do NOT try to continue to use this device.
  • Page 4 Last update: 2002.0806 DANGER Do NOT place any potentially hazardous things on this device. DO NOT place any things on this device which may, if its gets into the inside for the body damages the inner parts of the device (such as a flower pot, glass, cosmetics, a container filled with liquids or chemicals, as well as small metal parts, etc.).
  • Page 5 Last update: 2002.0806 CAUTION Do NOT connect/disconnect connectors before turning power off. Make sure to check the CCU power is OFF before connecting /disconnecting connectors. Otherwise, you might get an electric shock, your camera might break down. Avoid Do NOT give a strong shock/impact against the camera head. Avoid giving strong shock against the camera head is subjected to strong repetitive shocks.

  • Page 6: Restriction For Use

    Last update: 2002.0806 RESTRICTION FOR USE Avoid combine to signals other than specified. You cannot be obtained intrinsic performance in some cases of combinations with signals other than prescribed in this manual. If you continue to operate in such cases, it might cause to a heat generation on a part of circuits, leading to a breakdown.

  • Page 7: Product Description

    Last update: 2002.0806 1. Product Description Model CS3940 is a B/W CCD camera employing a 3/4 type all-pixel-data-read-out CCD, featuring ultra-high resolution. 2. Features (1) Ultra-high Resolution CS3940 features an ultra-high picture resolution through the adoption of a MEGA-pixel CCD (Total pixel count: 1,040,000 Active pixel count: 1,000,000 [1,004(H) x 1,004(V)]).

  • Page 8: Designation And Working Of Each Part

    Last update: 2002.0806 5. Designation and Working of Each Part Rear Panel (1) DC IN/SYNC Connector Input connector for the power supply, for TRIG/WEN connection terminal, and for HD/VD output terminal (under inner switch is ON). This connects to power-supply unit or image processor unit and so on. (2) DATA OUT Connector (Digital Data output terminal) Picture signal, HD, VD, and CLK are output in the format complying with TIA/EIA-644.

  • Page 9: Connection

    Last update: 2002.0806 6. Connection (1) DC IN/SYNC Connector (Camera side): HR10A-10R-12PB (Manufactured by HIROSE DENKI) Plug (Cable side): HR10A-10P-12S (Manufactured by HIROSE DENKI) Pin number Signal name +12V N.C. N.C. HD OUT* VD OUT* N.C. TRIG (Rear (Rear- - - - view) view) (Rear (Rear...

  • Page 10: Function Of Each Switch/Mode

    Last update: 2002.0806 7. Function of Each Switch/Mode The setting of each mode can be done with DIP switches located on the rear panel or inside. Rear-panel DIP SW Setting Function Mode SW1-4 SW1-5 Shutter OFF (OFF) (OFF) Normal shutter *1 *2 Partial-scan(SW1-6)*1 HV-reset Pulse mode...
  • Page 11 ! ! ! ! connected to the camera and after unplugging all connection cables. Caution CCD side Connector side Side view of CS3940 being removed its cover ＯＮ ＯＦＦ HD/VD output switch (IF Board) The specification is subject to change without notice.
  • Page 12 Last update: 2002.0806 (2) RTS control The camera goes into RTS (Random Trigger Shutter) mode when TRIG terminal voltage is in LOW (Higher than 1V), and starts light-exposure at the rising edge timing. Under the FIX mode, exposure-time is controlled with inner DIP switch setting. Under the PULSE mode, the exposure-time is determined by pulse width.
  • Page 13 Last update: 2002.0806 -2 HV-reset mode Exposure starts at the timing of TRIG signal IN. After each exposure is completed, the camera outputs video immediately by resetting HD and VD. Automatically returns to normal shutter if H level stays for 10V (1/3s) or longer TRIG IN is not acceptable for 1V after mode change TRIG IN...
  • Page 14 Last update: 2002.0806 (3) Partial-scan mode setting The partial-scan ON/OFF selection is made via the rear-panel DIP SW6 (= DIP 6 ON, 1/3 partial). Under the partial-scan mode, shutter-speed set via rear-panel DIP SW. VIDEO OUT （Normal） High-speed Normal-speed High-speed transfer transfer transfer...

  • Page 15: Specifications

    Last update: 2002.0806 8. Specification Model CS3940 Image sensor Interline CCD Total pixel 1028(H) x 1008(V) Active pixel 1004(H) x 1004(V) Unit cell size 7.4(H) x 7.4(V) micrometer Optical size 3/4 type equivalent format Scanning system Non-interlace Scanning frequency 30.12kHz(H) (Under shutter OFF) 29.91Hz(V) (All pixels read out)
  • Page 16 Last update: 2002.0806 FIX mode: Exposure time is determined by the shutter-speed PULSE mode: Exposure time depends on PULSE width V-reset mode: Video is output by resetting VD HV-reset mode: Video is output by resetting HD/VD Partial scan ON / OFF selection (Initial factory setting: OFF) 1/2 partial: Screen center 1/3 readout in Approx.

  • Page 17: Timing Chart

    Last update: 2002.0806 9. Timing Chart 9-1. Digital output timing (1) H rate (Under shutter OFF) TIA/EIA-644 (LVDS) Driver output voltage: Plus/minus 350mV [Differential output] / 100-ohm DATA 25.0ns 235CLK 86CLK 3CLK 1004CLK 1328CLK Total clock counts 1328CLK / 1H (33.2 micro s) DATA counts 1004CLK / 1H (25.1 micro s) 25.0ns...
  • Page 18 Last update: 2002.0806 (3) V rate TIA/EIA-644 (LVDS) Driver output voltage: plus/minus 350mV [Differential output] / 100-ohm DATA 1004H 1007H(29.91Hz) The specification is subject to change without notice. D4110637B...

  • Page 19: External View

    Kansai Branch: Nitto Building, 2-1-1 Sakaemachi-dori, Chuo-ku, Kobe, Hyogo, 650-0023, Japan Phone: +81-078-321-3461 Fax: +81-078-321-3463 Fukuoka Office: Yen building, 2-7-21, Hirao, Chuo-ku, Fukuoka, 810-0014, Japan Phone: +81-092-523-3395 Fax: +81-092-523-3397 URL: http://www.teli.co.jp The specification is subject to change without notice. D4110637B...
