Teli CS9001 Series User Manual

Hide thumbs Also See for CS9001 Series:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual

CCD COLOR CAMERA

CS9001/CS9001P SERIES
1. INTRODUCTION ...............................................................................................1
2. FEATURES .........................................................................................................1
3. COMPONENTS ..................................................................................................2
(NTSC)................................................................................3
3.4. O
..........................................................................................................4
4. SPECIFICATIONS..............................................................................................5
5. MENU DISPLAY DETAILS ..............................................................................8
6. TYPICAL SPECTRAL RESPONSE...................................................................9
7.ATTACHED DRAWINGS ................................................................................12

Specifications

.......................................................................2
(PAL) ................................................................................3
． ..................................................................12
..........................................................14
Ver.5.00
Printed on recycled paper
D4134187A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS9001 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Teli CS9001 Series

Summary of Contents for Teli CS9001 Series

  • Page 1: Table Of Contents

    Ver.5.00 CCD COLOR CAMERA CS9001/CS9001P SERIES Specifications 1. INTRODUCTION ....................1 2. FEATURES ......................1 3. COMPONENTS ....................2 3.1. N ...............2 AMING OF THESE PRODUCTS 3.2. CS9001 S (NTSC)................3 ERIES 3.3. CS9001P S (PAL) ................3 ERIES 3.4. O ......................4 PTION 4. SPECIFICATIONS....................5 5.

  • Page 2: Restriction For Use

    CASES FOR INDEMNITY (LIMITED WARRANTY) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions.

  • Page 3: Introduction

    1. Introduction The CS9001/CS9001P Series is an NTSC/PAL separation method remote head type color camera and is adaptable to a variety of camera heads realizing ultra-small size and light weight. 2. Features (1) DC12 V Drive Power voltage of this product is DC12 V suitable for assembly within a device. When the product is to be used under 100 to 240 VAC, it is recommended that you use an optional power adapter.

  • Page 4: Components

    3. Components 3.1. Naming of these products (Example) –03 (2) (3) (4) (5) (6) (1) Trade mark : camera system (camera head + camera controller) : camera head : camera controller (2) “9” fixed (3) Size of CCD : 1/2 inches : 1/3 inches : 1/4 inches : 1/6 inches...

  • Page 5: Cs9001 Series (Ntsc)

    3.2. CS9001 Series (NTSC) The lineup of CS9001 Series is shown in the following table. Please specify the desired combination to our sales distributor when ordering. Camera head Camera controller Product Name Camera cable Individual Individual Dimensions Option name Size...

  • Page 6: Ption

    NOTE: About combination of camera heads and camera controller Be sure to use the CSH9**1(P) (camera head) combining with the CSU9*01(P) or CSU9*01(P)E (camera controller). Please do not combine the Teli’s conventional CS9000(P) series with them. To do so might cause a malfunction. CSU9000(P)

  • Page 7: Specifications

    4. Specifications * For items with no indication, the specification is combined with a camera cable of 3 m. Item CS9001 Series CS9001P Series TV system NTSC Image sensor ①CSH9201(P) Type 1/2 Interline CCD ②CSH9221(P) Type 1/2 Interline CCD ③CSH9301(P) Type 1/3 Interline CCD ④CSH9401(P)-**...
  • Page 8 Item CS9001 Series CS9001P Series ※Only for CS9**1(P)E, a RGB output is. Video output 1.0 V(p-p)/75Ω Positive polarity 1.0 V(p-p)/75Ω Positive polarity 0.286V(p-p)/75Ω 0.3V(p-p)/75Ω 1.0 V(p-p)/75Ω Positive polarity (Only G signal) 0.714V(p-p)/75Ω Positive polarity 0.7V(p-p)/75Ω Positive polarity ※Only CS9**1(P)E External sync output...
  • Page 9 Item CS9001 Series CS9001P Series DC12V±10% (Ripple voltage : 50mV ( p-p ) ) Power source Power consumption (DC12V) ①CS9**1(P) Approx. 550mA ②CS9**1(P)E Approx. 680mA Ambient condition Temperature 0℃∼40℃ Humidity 10∼90% (No condensation) Atmospheric pressure 500~1060hPa Outside size Refer to outside drawing Weight ･Camera head...

  • Page 10: Menu Display Details

    DISP Clear Clears the displayed item. Sets the shutter speed. * ALC MODE: Effective when AGC/MANU[ALC LED: lights (orange), unlit] 0 = OFF CS9001 Series : 1/60(S) CS9001P Series: 1/50(S) 1 = F. L CS9001 Series : 1/100(S) Shutter CS9001P Series: 1/120(S)

  • Page 11: Typical Spectral Response

    6. Typical spectral response The lens characteristics and light source characteristics is not reflected in table. CSH9201/CSH9221 CSH9201/CSH9221 1.00 0.80 0.60 0.40 0.20 0.00 Wave Length [nm] CSH9201P/CSH9221P CSH9201P/CSH9221P 1.00 0.80 0.60 0.40 0.20 0.00 Wave Length [nm] D4134187A...
  • Page 12 CSH9301/CSH9301P CSH9301/CSH9301P 1.00 0.80 0.60 0.40 0.20 0.00 Wave Length [nm] CSH9401 CSH9401-** 1.00 0.80 0.60 0.40 0.20 0.00 Wave Length [nm] D4134187A...
  • Page 13 CSH9401P-** CSH9401P 1.00 0.80 0.60 0.40 0.20 0.00 Wave Length [nm] CSH9501/CSH9501P CSH9501-03/05 CSH9501-** 1.00 0.80 0.60 0.40 0.20 0.00 Wave Length [nm] D4134187A...

  • Page 14: Attached Drawings

    7.Attached Drawings 7.1. Camera Head Dimensions． ①CSH9201(P) ②CSH9221(P) ③CSH9301(P) ④CSH9401(P)-** D4134187A...
  • Page 15 ⑤CSH9501-** D4134187A...

  • Page 16: Camera Controller Dimensions

    7.2. Camera Controller Dimensions ①CSU9*01(P) D4134187A...
  • Page 17 ②CSU9*01(P)E D4134187A...
  • Page 18 (Overseas Sales Department) Phone : +81-42-589-8771 : +81-42-589-8774 : http://www.toshiba-teli.co.jp Distributor • This product must be classified for disposal according to the laws of each country and municipal laws. • Information contained in this document is subject to change without prior notice.
