Teli CSCS20BC2 Manual

Cleverdragon series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

CCD Camera

CleverDragon series
CSCS20BC2
Specification
CONTENTS
Restriction For Use ······························································2
Exemption Clauses ······························································3
Notes on using this product··················································4
1. Overview ·········································································7
2. Features············································································7
3. Configuration···································································8
4. Option parts ·····································································8
5. Function···········································································8
6. Specification ··································································13
7. Timing Chart··································································17
8. Guarantee·······································································22
9. Repair ············································································22
10. External-view Drawing ················································23
D4159008A
( 1 / 24 )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSCS20BC2 and is the answer not in the manual?

Questions and answers

Related Manuals for Teli CSCS20BC2

Summary of Contents for Teli CSCS20BC2

  • Page 1: Table Of Contents

    CCD Camera CleverDragon series CSCS20BC2 Specification CONTENTS Restriction For Use ······························································2 Exemption Clauses ······························································3 Notes on using this product··················································4 1. Overview ·········································································7 2. Features············································································7 3. Configuration···································································8 4. Option parts ·····································································8 5. Function···········································································8 6. Specification ··································································13 7. Timing Chart··································································17 8. Guarantee·······································································22 9.

  • Page 2: Restriction For Use

    Restriction For Use • Should the equipment be used in the following conditions or environments, give consideration to safety measures and inform us of such usage: 1. Use of the equipment in the conditions or environment contrary to those specified, or use outdoors. 2.

  • Page 3: Exemption Clauses

    • TELI assumes no responsibility or liability in the case damages or losses are caused by failure to observe the information contained in the operation manual and specifications. • TELI assumes no responsibility or liability in the case damages or losses are caused by use contrary to the instructions in this operation manual and specifications.

  • Page 4: Notes On Using This Product

    Notes on using this product • Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage the connection cable, since this may cause wire breakage. •...
  • Page 5 Notes on using this product • Avoid intensive light Do NOT expose the camera's image-pickup-plane to sunlight or other intense light directly. If the part of CCD is exposed to spot-intensive light, you might get a picture problem like blooming and/or smear. Under the comparison at the same video output level, the shorter the exposure time setting, the more smear is generated.
  • Page 6 CAUTIONS ON USE • When disposing of the camera Wastes of this product should be separated and discarded in compliance with the various national and local ordinances. This camera is showing the following symbol to body due to EU environmental regulation (Waste Electrical and Electronic Equipment (WEEE)).

  • Page 7: Overview

    2. Features (1) All-pixel reading The all-pixel reading system allows the CSCS20BC2 to read all pixels in just 1/19.5 second. CSCS20BC2 is equipped with a full-frame shutter that allows all-pixel reading even during shutter operations.

  • Page 8: Configuration

    3. Configuration Camera body ..................... 1 Operation Manual (Japanese) ..............1 Operation Manual (English) ..............1 4. Option parts (1) Camera mounting kit CPT8560 *NOTE: Contact your dealer / distributor for details of option units. *NOTE: Application software is not supplied as a standard item. 5.
  • Page 9 5-3. Command Communication Protocol The command communication protocol is the teli standard method (method in which parameters are set in the registers in the camera). In command send/receive operation, hexadecimal address and data are converted to ASCII data. All ASCII alphabetic characters used are uppercase characters.
  • Page 10 (2) Reading the register To read data from a register, send ', (comma)', 'R', 'Q' and [CR] code following the address. For example, to read data in address 0x91, send a command, as follows: ‘9’ ‘1’ ‘ , ’ ‘R’ ‘Q’...
  • Page 11 5-4. Register Map Read B&W Camera Address Write CSCS20BC2 0x00 Maker Name Maker Name ASCII Format TOSHIBA TELI R.O. 0x0F 0x10 Model Name Model Name ASCII Format CSCS20BC2 R.O. 0x2F 0x30 Serial Number Serial Number ASCII Format ex) 0100011 R.O.
  • Page 12 Read B&W Camera Frame Rate (@Normal Shutter) Address Write CSCS20BC2 Normal : 19fps Partial : The calculation from partial video width. Frame Rate 0x80 R.O. (Omit it after the decimal point. ) Default : 19fps @ Normal Scan Horizontal Resolution 0x82 R.O.

  • Page 13: Specification

    6. Specification [Electrical specification] (1) Imager all-pixel-data-readout interline transfer CCD 1434(H) × 1050(V) Number of total pixels 1392(H) × 1040(V) Number of effective pixels 1360(H) × 1024(V) Number of Video out pixels 6.47mm(H) × 4.84mm(V) Scanning area (= Equivalent to 1/2” type CCD size) 4.65µm(H) ×...
  • Page 14 [Electrical shutter specification] (1) Shutter Speed 2/1 to 1/20,000 [sec] Setting format: Numerator / Denominator [sec] Numerator: 1 to 255 Denominator: 1 to 20,000 *When you set the exposure time longer than approximately 1 second, white spots and the unevenness in highlight portion might occasionally be observed on screen. This phenomenon is due to the characteristics of the CCD image-pickup device, and do not reflect performance error in the pickup device or CCD Camera itself.
  • Page 15 [Mechanical spec] (1) Lens mount C-mount *Install a next lens; the C mount lens, its dimension of protrusion from flange is equal to or less than 7.9 mm. If a lens does not stand to this condition, it might not be installed to this camera. *Depending on the lens you use, the performance of the camera may not be brought out fully due to the deterioration in resolution and brightness in the peripheral area, occurrence of the ghost, aberration and others.
  • Page 16 [Communication specification] (1) Communication speed 9600 bps (fixed) (2) Start bit (3) Data bit (4) Parity None (5) Stop bit (6) Handshake None [Connector pin assignment] Video output/controlling/power supply connector: (Camera Link Base Configuration) CAMERA LINK Connector model: HDR-EC26FDTG2+ (Manufactured by Honda Connectors) Pin # I/O Signal name Pin # I/O...

  • Page 17: Timing Chart

    7. Timing Chart 7-1. Normal Scan (All pixel readout) As all pixels are read out in approx. 1/19.5s, you will get images with the higher V resolution (you have to change the shutter speed to 1/19.5s or shorter). Vertical Timing (maximum speed on all pixel readout mode) A = approx.
  • Page 18 7-2. Partial Scan Ranges except the range of the image output that the user set are not read. ex.1) Video Start Line =128, Video Width = 768 (maximum speed on all pixel readout mode) FVAL LVAL DVAL DATA OUT A = approx. 996.4us B = approx.
  • Page 19 ex. 2) Video Start Line =256, Video Width=512 (maximum speed on all pixel readout mode) FVAL LVAL DVAL DATA OUT A = approx. 1721.8us B = approx. 25.5ms (512H-336CLK) C = approx. 1586.7us D = approx. 28.8ms Video start line:256 Not read Video width:512 lines Valid lines:1024...
  • Page 20 7-3. Random Trigger Shutter In the random trigger shutter mode, you can shoot and grab an image at an arbitrary timing by trigger signal input from the external (It is not possible to use the Random Trigger Shutter concurrently with the Restart Reset mode).
  • Page 21 7-4. Restart / Reset The restart / reset function is available with the ext.VD signal. You can get an arbitrary slower shutter speed than normal shutter and random trigger shutter (It is not possible to use the Restart Reset mode concurrently with the Random Trigger Shutter mode).

  • Page 22: Guarantee

    If by any chance trouble by responsibility of our company occurs before an above period, TELI repairs it free of charge. - During terms of a guarantee, when the trouble cause is the case of below, TELI charges the repair costs.

  • Page 23: External-View Drawing

    10. External-view Drawing D4159008A ( 23 / 24 )
  • Page 24 Head Office: 7-1, 4 chome, Asahigaoka, Hino-shi, Tokyo, 191-0065, Japan (Overseas Sales Department) Phone: +81-42-589-8771 Fax: +81-42-589-8774 URL: http://www.toshiba-teli.co.jp The design and specification is subject to change without notice. Distributer ( 24 / 24 ) D4159008A...
