GiantDragon B/W series
Instruction Manual
Thank you for purchasing our product.
Before using this CCD Color Camera, please read through this instruction manual
carefully in order to use this product correctly and safely.
After reading, keep this instruction manual handy so that you can refer to, whenever
you need it.
Safety Precautions
1. Overview ·····························································································1
2. Features ·······························································································1
3. Configuration ······················································································2
4. Optional part························································································2
5. Explanation rear panel·········································································3
6. Connection ··························································································4
7. Functions ·····························································································5
8. Timing chart ························································································8
9. Troubleshooting··················································································10
10. Specifications ···················································································11
11. Outline Drawing···············································································17
CCD Camera
CSGV90BC3
CSGX36BC3
CSGS20BC2
CSGU15BC18
CSGS15BC23
Contents
Printed on recycled paper
D4153659A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GiantDragon B/W Series and is the answer not in the manual?

Questions and answers

Related Manuals for Teli GiantDragon B/W Series

Summary of Contents for Teli GiantDragon B/W Series

  • Page 1 CCD Camera GiantDragon B/W series CSGV90BC3 CSGX36BC3 CSGS20BC2 CSGU15BC18 CSGS15BC23 Instruction Manual Thank you for purchasing our product. Before using this CCD Color Camera, please read through this instruction manual carefully in order to use this product correctly and safely.

  • Page 2: Safety Precautions

    Safety Precautions Before using this product, read these safety precautions carefully. Important information is shown in this Instruction Manual to protect users from bodily injuries and property damages, and to enable them to use the product safely and correctly. Please be sure to thoroughly understand the meanings of the following signs and symbols before reading the main text that follow, and observe the instructions given herein.
  • Page 3 [General Handing] WARNING ! ! ! ! Stop operation immediately when any abnormality or defect occurs. If abnormal conditions are present, such as smoke, a burning smell, ingress of water or foreign matter, or if the equipment is dropped or malfunctions, fire or electric shock may result. Be always sure to disconnect the power cable from the wall socket at once and contact your Unplug dealer.
  • Page 4 [General Handing] CAUTION ! ! ! ! Observe the following when installing the equipment: · Do not cover the equipment with a cloth, etc. · Do not place the equipment in a narrow location where heat is likely to accumulate. Otherwise, heat will accumulate inside the equipment, possibly resulting in a fire.

  • Page 5: Cases For Indemnity (Limited Warranty)

    CASES FOR INDEMNITY (LIMITED WARRANTY) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. ! In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions.

  • Page 6: Notes On Using This Product

    Notes on using this product ! ! ! ! Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage the connection cable, since this may cause wire breakage. ! ! ! ! Environmental operating conditions Do not use the product in locations where the ambient temperature or humidity exceeds the specifications.
  • Page 7 Following information is only for EU-member states: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
  • Page 8 环保使用期限标识，是根据电子信息产品污染控制管理办法以及，电子 信息产品污染控制标识要求(SJ/T11364-2006)、 电子信息产品环保使用期 限通则，制定的适用于中国境内销售的电子信息产品的标识。 电子信息产品只要按照安全及使用说明内容，正常使用情况下，从生产 月期算起，在此期限内，产品中含有的有毒有害物质不致发生外泄或突 变，不致对环境造成严重污染或对其人身、财产造成严重损害。 产品正常使用后，要废弃在环保使用年限内或者刚到年限的产品时，请 中华人民共和国 根据国家标准采取适当的方法进行处置。 环保使用期限 另外，此期限不同于质量/功能的保证期限。 The Mark and Information are applicable for People's Republic of China only. ＜ ＜ ＜ ＜ 产品中有毒有害物质或元素的名称及含量 产品中有毒有害物质或元素的名称及含量 产品中有毒有害物质或元素的名称及含量＞ ＞ ＞ ＞ 产品中有毒有害物质或元素的名称及含量 有毒有害物质或元素 部件名称 六价铬 多溴联苯 多溴二苯醚 铅（Pb）...
  • Page 9 1. Overview This GiantDragon B/W series is an integrated-(one-body)-type monochrome camera that adopts all pixel data readout inter line CCD. There are 4 models according to the sensor type. These are CSGV90BC3 (VGA), CSGX36BC3 (XGA), CSGS20BC2 (SXGA: 1/2 type), CSGU15BC18 (UXGA), and CSGS15BC23 (SXGA: 2/3 ®*...

  • Page 10: Optional Part

    ! Random trigger shutter The random trigger shutter function provides images in any timing by input of an external trigger signal. Trigger control from PC is possible. ! Scalable Selectable video output area. It can be higher frame rate by reducing vertical output area. And can be reduce occupied data rate of Gigabit Ethernet by reducing horizontal output area.

  • Page 11: Explanation Rear Panel

    5. Explanation rear panel (1) Ethernet Gigabit Ethernet Interface connector - Connector model P65-P01-19V8 (Supplied by SpeedTech Corp.) - Pin assignment Pin No. Function BI_DA+ BI_DA- BI_DB+ BI_DC+ BI_DC- LED1 BI_DB- BI_DD+ BI_DD- Rear View LED2 - Indication LED1: GREEN (ACT LED) LED1 indicates the state of ACT.
  • Page 12 6. Connection Connect this camera as shown in the figure below. (The figure below shows an example of connection. For details, contact our sales representative.) Option Camera Cable CPRC3910-** Option Camera Adapter CA130C CCD Camera TRIGGER CAMERA GiantDragon (Rear-side) AC100V IN VIDEO 　OUT CLOCK　OUT CA13 0 C...
  • Page 13 Control and setting of functions can be done by the camera control based on the Gigabit Ethernet digital camera protocol (GigEVision Ver.1.00). (1) Image output A format of the output image and frame rate which this GiantDragon B/W series supports is as follows. Model CSGV90BC3 CSGX36BC3...
  • Page 14 (6) Electronic shutter mode switching You can switch the shutter modes by adjusting the setting value of the command status register of the camera via the Gigabit Ethernet. The setting method has two kinds of the following. - Normal shutter Performs exposure control via the internal synchronization signal.
  • Page 15 (7) Scalable mode This camera has the scalable mode that can read out defined area of the screen. Only continuous rectangle units can be selected, concave or convex shape cannot be selected. - Window size: {A x m(H)} x {B x n(V)} * A and B are minimum unit size.

  • Page 16: Timing Chart

    8. Timing chart Image data outputs of this camera series are transferred with the UDP protocol of Gigabit Ethernet. Timing numerical value below is prescribed by absolute prerequisite that GiantDragon series use transmission band without restriction of other node. When there is a node transferring with GiantDragon concerned, it is not same the numerical value prescribed below.
  • Page 17 (2) In the random trigger shutter mode - When fixed mode (Video format: MONO 8, all pixel readout); TRIG_IN Expose GbE bus Image DLY1 - When pulse width mode (Video format: MONO 8, all pixel readout); TRIG_IN Expose GbE bus Image DLY1 Model name...

  • Page 18: Troubleshooting

    9. Troubleshooting If any trouble occurs in use, check the following first. If the trouble persists, contact your distributor or our sales representatives. * When user confirms the troubles, please confirms the troubles on the condition that user connected the camera system on the smallest composition and set 1500 byte / packet to the GVSP_SIZE (SCPSx) register for making cause of trouble clear.

  • Page 19: Specifications

    10. Specifications [Electrical specification] (1) Imager All-pixel-data-readout interline transfer CCD CSGV90BC3 CSGX36BC3 CSGS20BC2 CSGU15BC18 CSGS15BC23 Number of total pixels 692 x 504 1077 x 788 1434 x 1050 1688 x 1248 1434 x 1050 (H) * (V) Number of effective pixels 659 x 494 1034 x 779 1392 x 1040...
  • Page 20 ［ ［ ［ ［ Trigger signal specification］ ］ ］ ］ (1) External trigger input - Input level Low level: 0 to 0.5V High level: 2.0 to 5.0V - Polarity Positive / Negative bipolar - Pulse width 2us (Minimum) - Input impedance High impedance (2) Software trigger Set via the Gigabit Ethernet interface...
  • Page 21 ［ ［ ［ ［ Machine externals specification]］ ］ ］ ］ (1) Dimensions 44mm(W) x 29mm(H) x 70mm(D) (Not including protrusion) (2) Mass Approximately 120g (3) Lens mount C-mount Notes on combination of C-mount lens: - Depending on the lens you use, the performance of the camera may not be brought out fully due to the deterioration in resolution and brightness in the peripheral area, occurrence of a ghost, aberration and others.
  • Page 22 ［ ［ ［ ［ Typical spectral response］ ］ ］ ］ The lens characteristics and light source characteristics is not reflected in table. <CSGV90BC3> Wave Length[nm] <CSGX36BC3> 1000 Wave Length[nm] D4153659A...
  • Page 23 <CSGS20BC2> 1000 Wave Length[nm] <CSGU15BC18> 1000 Wave Length[nm] D4153659A...
  • Page 24 <CSGS15BC23> 1000 Wave Length [nm] D4153659A...

  • Page 25: Outline Drawing

    11. Outline Drawing D4153659A...
  • Page 26 NOTE D4153659A...
  • Page 27 NOTE D4153659A...
  • Page 28 (Overseas Sales Department) Phone : +81-42-589-8771 : +81-42-589-8774 : http://www.toshiba-teli.co.jp Distributor • This product must be classified for disposal according to the laws of each country and municipal laws. • Information contained in this document is subject to change without prior notice.

  • Page 29: Table Of Contents

    CCD Color Camera GiantDragon Color series CSGV90CC3 CSGX36CC3 CSGS20CC2 CSGU15CC18 Instruction Manual Thank you for purchasing our product. Before using this CCD Color Camera, please read through this instruction manual carefully in order to use this product correctly and safely. After reading, keep this instruction manual handy so that you can refer to, whenever you need it.

  • Page 30: Safety Precautions

    Safety Precautions Before using this product, read these safety precautions carefully. Important information is shown in this Instruction Manual to protect users from bodily injuries and property damages, and to enable them to use the product safely and correctly. Please be sure to thoroughly understand the meanings of the following signs and symbols before reading the main text that follow, and observe the instructions given herein.
  • Page 31 [General Handing] WARNING ! ! ! ! Stop operation immediately when any abnormality or defect occurs. If abnormal conditions are present, such as smoke, a burning smell, ingress of water or foreign matter, or if the equipment is dropped or malfunctions, fire or electric shock may result. Be always sure to disconnect the power cable from the wall socket at once and contact your Unplug dealer.
  • Page 32 [General Handing] CAUTION ! ! ! ! Observe the following when installing the equipment: · Do not cover the equipment with a cloth, etc. · Do not place the equipment in a narrow location where heat is likely to accumulate. Otherwise, heat will accumulate inside the equipment, possibly resulting in a fire.
  • Page 33 CASES FOR INDEMNITY (LIMITED WARRANTY) We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user in the following cases. ! In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions.
  • Page 34 Notes on using this product ! ! ! ! Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage the connection cable, since this may cause wire breakage. ! ! ! ! Environmental operating conditions Do not use the product in locations where the ambient temperature or humidity exceeds the specifications.
  • Page 35 Following information is only for EU-member states: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
  • Page 36 环保使用期限标识，是根据电子信息产品污染控制管理办法以及，电子 信息产品污染控制标识要求(SJ/T11364-2006)、电子信息产品环保使用 期限通则，制定的适用于中国境内销售的电子信息产品的标识。 电子信息产品只要按照安全及使用说明内容，正常使用情况下，从生产 月期算起，在此期限内，产品中含有的有毒有害物质不致发生外泄或突 变，不致对环境造成严重污染或对其人身、财产造成严重损害。 产品正常使用后，要废弃在环保使用年限内或者刚到年限的产品时，请 中华人民共和国 根据国家标准采取适当的方法进行处置。 环保使用期限 另外，此期限不同于质量/功能的保证期限。 The Mark and Information are applicable for People's Republic of China only. ＜ ＜ ＜ ＜ 产品中有毒有害物质或元素的名称及含量 产品中有毒有害物质或元素的名称及含量＞ ＞ ＞ ＞ 产品中有毒有害物质或元素的名称及含量 产品中有毒有害物质或元素的名称及含量 有毒有害物质或元素 部件名称 六价铬 多溴联苯 多溴二苯醚 铅（Pb） 汞（Hg）...

  • Page 37: Overview

    1. Overview This GiantDragon Color series is an integrated-(one-body)-type color camera that adopts all pixel data readout inter line CCD. There are 4 models according to the sensor type. These are CSGV90CC3 (VGA), CSGX36CC3 ®* (XGA), CSGS20CC2 (SXGA), and CSGU15CC18 (UXGA). For video output, the Gigabit Ethernet interface standard “IEEE802.3ab”...

  • Page 38: Configuration

    ! High-speed draft readout mode By thinning out vertical lines, it can be read all effective area at high-speed frame rate. ! Random trigger shutter The random trigger shutter function provides images in any timing by input of an external trigger signal. Trigger control from PC is possible.

  • Page 39: Explanation Rear Panel

    5. Explanation rear panel (1) Ethernet Gigabit Ethernet Interface connector - Connector model P65-P01-19V8 (Supplied by SpeedTech Corp.) - Pin assignment Pin No. Function BI_DA+ BI_DA- BI_DB+ BI_DC+ BI_DC- LED1 BI_DB- BI_DD+ BI_DD- Rear View LED2 - Indication LED1: GREEN (ACT LED) LED1 indicates the state of ACT.

  • Page 40: Connection

    6. Connection Connect this camera as shown in the figure below. (The figure below shows an example of connection. For details, contact our sales representative.) Option Camera Cable CPRC3910-** Option Camera Adapter CA130C CCD Color Camera TRIGGER CAMERA GiantDragon (Rear-side) VIDEO 　OUT AC100V IN CLOCK　OUT...

  • Page 41: Functions

    7. Functions Control and setting of functions can be done by the camera control based on the Gigabit Ethernet digital camera protocol (GigEVision Ver.1.00). (1) Image output A format of the output image and frame rate which this GiantDragon Color series supports is as follows. Model CSGV90CC3 CSGX36CC3...
  • Page 42 (7) High-speed draft readout mode By thinning out vertical lines, it can be read all effective area at high-speed frame rate. * As for CSGV90CC3 (VGA), this mode supports a fault. CSGV90CC3 CSGX36CC3 CSGS20CC2 CSGU15CC18 Draft mode Readout vertical line number Maximum frame rate 86 fps 34fps...
  • Page 43 (10) Scalable mode This camera has the scalable mode that can read out defined area of the screen. Only continuous rectangle units can be selected, concave or convex shape cannot be selected. - Window size: {A x m(H)} x {B x n(V)} * A and B are minimum unit size.

  • Page 44: Timing Chart

    8. Timing chart Image data outputs of this camera series are transferred with the UDP protocol of Gigabit Ethernet. Timing numerical value below is prescribed by absolute prerequisite that GiantDragon series use transmission band without restriction of other node. When there is a node transferring with GiantDragon concerned, it is not same the numerical value prescribed below.
  • Page 45 (2) In the random trigger shutter mode - When fixed mode (Video format: RGB 24 bit, all pixel readout); TRIG_IN Expose GbE bus Image DLY1 - When pulse width mode (Video format: RGB 24 bit, all pixel readout); TRIG_IN Expose GbE bus Image DLY1...

  • Page 46: Troubleshooting

    9. Troubleshooting If any trouble occurs in use, check the following first. If the trouble persists, contact your distributor or our sales representatives. * When user confirms the troubles, please confirms the troubles on the condition that user connected the camera system on the smallest composition and set 1500 byte / packet to the GVSP_SIZE (SCPSx) register for making cause of trouble clear.

  • Page 47: Specifications

    10. Specifications [Electrical specification] (1) Imager All-pixel-data-readout interline transfer CCD CSGV90CC3 CSGX36CC3 CSGS20CC2 CSGU15CC18 Number of total pixels 692 x 504 1077 x 788 1434 x 1050 1688 x 1248 (H) x (V) Number of effective pixels 659 x 494 1034 x 779 1392 x 1040 1628 x 1236...
  • Page 48 (8) Gamma correction ON(Gamma = 0.65) /OFF(Gamma = 1.0) switching initial factory setting: ON * When Raw output mode(8/10bit), Gamma correction function is disabled (OFF fixed). (9) Masking correction ON fixed * When Raw output mode(8/10bit), Masking correction function is disabled (OFF fixed). (10) White balance OPWB / MWB switching (initial factory setting: MWB) - OPWB (One Push White Balance)
  • Page 49 ［ ［ ［ ［ Electronic shutter specification］ ］ ］ ］ (1) AE （ Auto Exposure ） - Effective range 1/20000s to Setting value of the frame rate - Effective area Full screen - Exposure level -1EV to +1EV (1/3EV step) * When the random shutter is active, AE function is disabled.
  • Page 50 ［ ［ ［ ［ Machine externals specification]］ ］ ］ ］ (1) Dimensions 44mm(W) x 29mm(H) x 70mm(D) (Not including protrusion) (2) Mass Approximately 120g (3) Lens mount C-mount Notes on combination of C-mount lens: - Depending on the lens you use, the performance of the camera may not be brought out fully due to the deterioration in resolution and brightness in the peripheral area, occurrence of a ghost, aberration and others.
  • Page 51 ［ ［ ［ ［ Typical spectral response］ ］ ］ ］ The lens characteristics and light source characteristics is not reflected in table. <CSGV90CC3> Wave Length[nm] <CSGX36CC3> Wave Length[nm] D4153660A...
  • Page 52 <CSGS20CC2> Wave Length[nm] <CSGU15CC18> Wave Length[nm] D4153660A...

  • Page 53: Outline Drawing

    11. Outline Drawing D4153660A...
  • Page 54 NOTE D4153660A...
  • Page 55 NOTE D4153660A...
  • Page 56 (Overseas Sales Department) Phone : +81-42-589-8771 : +81-42-589-8774 : http://www.toshiba-teli.co.jp Distributor • This product must be classified for disposal according to the laws of each country and municipal laws. • Information contained in this document is subject to change without prior notice.

This manual is also suitable for:

Csgv90bc3Csgx36bc3Csgs20bc2Csgu15bc18Csgs15bc23

Table of Contents
