Thank you for purchasing our CS6900 / CS6900P color CCD camera. This operation manual contains some important information such as how to use this equipment correctly and safely. Please read through this manual carefully. After reading, keep this manual by the side of your equipment for your future reference.
Page 3
BEFORE USING THE CAMERA - GENERAL SAFETY INSTRUCTIONS This instruction manual contains important information for the operator (user) and/or people around him/her to avoid personal injuries, or property damages against him/her or people around him/her Ñ=by using this product correctly. Prior to use, read this operation manual carefully to fully understand its instructions for correct use.
Page 4
If any foreign objects gets into the camera, discontinue the use immediately. In the event that liquids, small particles, or any other foreign objects get into the camera, do NOT try to continue to use the camera.. To do so invites a fire or an electric shock hazard.
Page 5
CAUTION Do NOT connect/disconnect connectors with power ON. Before connecting/disconnecting connectors, make sure to check if the system is powered OFF. Doing so with power ON may cause a damage or an electric shock accident. Do NOT give a strong shock/impact against the camera-head. Avoid giving a strong shock against the camera head.
RESTRICTION FOR USE Do not attempt irregular signal interface other than specified. Under signal interface other than recommended/specified in this instruction manual, the camera might fail to exert the maximum performance. In much worse case, if you continue to use the camera under incorrect signal interface, part(s) of circuits might burn down.
1. Product Description Model CS6900 is an integrated (one-body) type color CCD camera employing a 1/2"size all-pixel-data-readout CCD. Thanks to its built-in RGB primary-color mosaic filter, this model realizes high resolution and high color reproduction. 2. Features (1) 1/2" size primary-color mosaic CCD A high color reproduction is ensured.
5. Designations and workings of each parts Rear-view: CS6900 / CS6900P (1) GAIN Control ①MG ------------------- Manual GAIN potentiometer (RGB simultaneously variable) ②WB-R ---------------- White-balance R potentiometer (R variable) ③WB-B ---------------- White-balance B potentiometer (B variable) (2) DC IN/SYNC DC+12V Power IN, Ex-sync HD/VD IN, and TRIG/WEN CLK Terminal This connector is for connection with a power supply, image processing equipment, etc.
6. How to mount the camera (1)Option 1: Using a camera tripod fixing kit [Tripod screws (1/4-20UNC)] Use an optional tripod fixing kit to fix the camera onto the tripod. (See the diagrammatic sketch shown below) (2)Option 2 : Using the mounting holes (Bottom side) Put M3 screws through these holes to fix the camera.
7. Connection (1)IN/OUT connector DC/SYNC connector (12P)-Manufactured by HIROSE DENKI Camera-side: HR 10A-10R-12PB, Cable-side: HrlOA-10P-12S RGB OUT connector (12P)Manufactured by HIROSE DENKI Camera-side: HR10A-10R-12SB, Cable-side: HR10A-10P-12P DC IN/SYNC RGB OUT R OUT +12 V IN R GND G OUT G GND HD/VD.GND B OUT HD.IN...
P.12/19 U 908 00-01-04 18:23 t9L-0001498142488101 8. Setting Setting of each mode can be done with the rear-panel DIP switch. To select modes, slide DIP switches numbered 1 through 8. The status is OFF when SW is in left position, ON when in right position.
Page 12
(5)Setting: Shutter-speed [DIP SW6, 7, and 8] (Initial Factory Setting: OFF= 1/60s (CS6900), 1/50s (CS6900P) Normal E shutter (s) RTS (s) CS6900 CS6900P CS6900 CS6900P 1/60 1/50 1/500 1/500 (OFF) (OFF) 1/125 1/125 1/1,000 1/1,000 1/250 1/250 1/2,000 1/2,000 1/500...
9. Specifications The part of specifications of CS6900P PAL version, which is not the same with CS6900 NTSC version, are shown in brackets [ ] in the table below. Model CS6900 [CS6900P] TV system EIA format [CCIR format] Image sensor...
Page 14
TRIG pulse width: Longer than 5 micro s (Negative) TRIG pulse interval: Longer than 2 FLD (Reset mode) Longer than 3 FLD (Non-reset mode) Output signal 1. WEN signal: CCD readout timing pulse under RTS Polarity: Negative Pulse width: 1H (1 FLD under RTS) Output level: From 3.5 through 4.5V(p-p) / 10k-ohm terminal 2.
Weight 10. Timing chart (1) Normal shutter 1/60 [CS6900P 1/50s] interlace mode In this mode, each RGB signal is output through RGB OUT connector in the interlace mode [CS6900 -1/6Os, CS6900P =1/5Os]. VD OUT HD OUT R OUT G OUT...
Page 16
TRIG IN VD OUT HD OUT Exporse-time R OUT G OUT B OUT (3) RTS 1/60s [1/50s] interlace mode (= Reset mode) In this mode, images started to be captured at ex-trigger input timing are output in the first field (=next FLD) after exposure-field by resetting horizontal/vertical sync. TRIG IN VD OUT HD OUT...
Page 17
CS6900 H-rate Timing 1CLK=1/12.27275MHz HD OUT VIDEO WEN OUT CS6900 H-rate Timing 1CLK=1/14.75000MHz HD OUT VIDEO WEN OUT...
