32 Model Supplement
450mm Min
For Servicing
Purposes &
Operating the
Controls
5mm Min In
Operation
5mm Min
450mm
7219708 - 01 (04/15)
At least
1.5°
345mm
5mm Min
175 mm Min (300mm
Min if using 80/125mm
flueing system)
763mm
150mm* Min
14.1 32 Model Supplement
Appliance Type
Appliance Category
Heat Input Qn Hs (Gross)
32 model
Heat Output Pn (Non-Condensing)
32 model
Heat Output Pnc (Condensing)
32 model
Gas Nozzle Injector
32 model
NATURAL GAS ONLY !
Max Gas Rate (Natural Gas - G20)
32 model
Dynamic (nominal) Inlet Pressure
(Natural Gas - G20)
mbar
with a CV of 37.78 MJ/m
Power Consumption
32 model
Weights
Packaged Boiler Carton
Installation Lift Weight
Outercase Dimensions
Casing Height
Overall Height Inc Flue Elbow
Casing Width
Casing Depth
Expansion Vessel - (For Central Heating
only. Integral with appliance)
Min Pre-charge Pressure 1.0
Max Capacity of
CH System
Primary Water Content
of Boiler (unpressurised) 2.8
*
This is MINIMUM
recommended dimension.
Greater clearance will aid
installation and maintenance.
32 Model Supplement
C
C
C
13
33
53
CAT I
2H
Max
Min
kW
35.52
6.99
Max
Min
kW
32
6.1
Max
Min
kW
33.9
6.6
mm
Ø 6.0
(After 10 mins)
m
3
/h
3.38
20
3
W
90
(32 model)
43.2kg
37.5kg
- 763mm
- 923mm
- 450mm
- 345mm
bar
litre
155
EcoBlue System
14
71
