Technical Specifications

3 Technical Specifications
Appliance Type C C
13 33
Appliance Category CAT I
Heat Input Qn Hs (gross)
Max
12 model kW 13.32
15 model kW 16.65
18 model kW 19.98
24 model kW 26.64
28 model kW 31.08
Heat Output Pn (Non-Condensing)
Max
12 model kW 12.0
15 model kW 15.0
18 model kW 18.0
24 model kW 24.0
28 model kW 28.0
Heat Output Pnc (Condensing)
Max
12 model kW 12.7
15 model kW 15.9
18 model kW 19.0
24 model kW 25.4
28 model kW 29.6
Gas Nozzle Injector
12 model mm Ø 3.8
15 model mm Ø 4.2
18 model mm Ø 4.2
24 model mm Ø 5.0
28 model mm Ø 5.6
Electrical Supply 230V~ 50Hz
(Appliance must be connected to an
earthed supply)
Power Consumption
12 model W 75
15 model W 80
18 model W 80
24 model W 85
28 model W 90
14 EcoBlue System
C
NO x Class
53
2H
Electrical Protection
IPX5D (without integral timer)
IP20 (with integral timer)
Min
2.66
External Fuse Rating
3.44
3.99
Internal Fuse Rating
5.22
5.88 Condensate Drain
To accept 21.5mm (
Min
Flue Terminal
2.3
Dimensions
3.0
3.5
Connections
4.6 Gas Inlet
Heating Flow
5.1
Heating Return
Pressure Relief Discharge -
Min
Outercase Dimensions
2.5
Casing Height
3.3
Overall Height Inc Flue Elbow
3.8
Casing Width
4.9
Casing Depth
5.6
Clearances
Above Casing
Below Casing
Front
Front
L.H. Side
R.H. Side
*This is MINIMUM recommended dimension.
Greater clearance will aid installation and
maintenance.
Weights
Packaged Boiler Carton
Installation Lift Weight
Packaged Boiler Carton
Installation Lift Weight
See Section 14.1 '32 Model Supplement'
for data specific to the 32 model
3.1

Technical Data

5
3A
F2L
3 / in) plastic waste pipe
4
Diameter 100mm
Projection 125mm
copper tails
- 22mm
- 22mm
- 22mm
15mm
- 700mm
- 860mm
- 390mm
- 295mm
175 mm Min
150 mm* Min
450 mm Min
(For Servicing)
5 mm Min
(In Operation)
5 mm Min
5 mm Min
(12/15/18/24 models)
37.1kg
32.5kg
(28 model)
39.1kg
34.5kg
Central Heating Primary Circuit
Pressures
Safety Discharge
Max Operating
Min Operating
Recommended Operating Range
Expansion Vessel - (For Central Heating
only. Integral with appliance)
bar
Min Pre-charge Pressure 1.0
litre
Max Capacity of
CH System 100
Primary Water Content
of Boiler (unpressurised) 2.5
Temperatures
Boiler Flow Temp
(adjustable)
25°C to 80°C
NOTE: All data in this section are nominal
values and subject to normal production
tolerances.
7219708 - 01 (04/15)
bar
3
2.5
0.5
1-2
(± 5°C)
max
