TuffStuff Apollo Owner's Manual page 8

FIG. 17 Caution: It is strongly recommended to use another
person in assisting with this assembly.
Attach the Top Pulley Assembly (#49) to the Front Upright (#16)
using two Hex Head Cap Screws 3/8-16 X 4 1/4 (#104), four Flat
Washers SAE 3/8" (#93), and two Nylon Insert Lock Nuts 3/8-16
(#119).
Loosely Fasten: Do not completely fasten this hardware
assembly at this time.
36
60
FIG. 19 Insert the Left Pec Dec Arm (#35) along with the Alumi-
num Cam Plate (#60) into the receptacle of the Front Upright (#16).
Repeat the same procedure for the Right Pec Dec Arm (#36).
Note: It is recommended to grease both axles of the Left and
Right Pec Dec Arms (#35, #36) with multi-purpose grease prior
to assembling.
7
49
16
35
60
16
18
53
FIG. 18 Using a utility knife, remove the two Plastic Ties (#127) from
the Press Bar Station Guide Rod Retainer (#18).
Next, affix the Top Pulley Assembly (#49) to the Press Bar Station
Guide Rod Retainer (#18) and the Weight Stack Frame (#53) using
two Hex Head Cap Screws 3/8-16 X 3 1/4 (#101), four Flat Washers
SAE 3/8" (#93) and two Nylon Insert Lock Nuts 3/8-16 (#119).
Fully Fasten: Proceed to align and fully fasten this hardware
assembly and the previous assemblies that were left loosely
fastened. (Assemblies described in FIG. 14 and FIG. 17).
15
119
8
FIG. 20 Secure the Left Pec Dec Arm (#35) into place using one
Button Head Socket Cap Screw 3/8-16 X 1 (#71), one Split Lock
Washer 3/8" (#152), and one Chrome Washer 3/8 X 1 1/2 (#74).
Repeat the same procedure for the Right Pec Dec Arm (#36).
Apollo Modular Gym System (Base Unit)
49
127
18
16
119
