NOTICE
It is the Purchaser's/Owner's obligation:
1. To disclose and post all Rules & Regulations, Danger, Warning and Caution
labels affi xed on the machine to their customers/users.
2. Equipment to be installed by TFI Authorized Dealer or a service
company approved by TFI.
3. Provide trained personnel, supervision and correct usage of the equipment.
4. Provide scheduled inspection, maintenance & repairs and must be performed
by TFI Authorized Dealer or a service company approved by TFI.
5. Must use only genuine TFI replacement parts.
6.
Machine must be anchored to a solid and level surface.
TUFFSTUFF FITNESS INTERNATIONAL
OWNER'S MANUAL
OWNER'S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE
Smith Press Attachment
(Option for CXT-200)
CXT-225
CXT-225_Rev2
Revision Date 6-20-2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TuffStuff CXT-225
Summary of Contents for TuffStuff CXT-225
- Page 1 TUFFSTUFF FITNESS INTERNATIONAL OWNER’S MANUAL OWNER’S MANUAL Maintenance & Assembly Instructions IMPORTANT: KEEP THIS MANUAL FOR FUTURE REFERENCE CXT-225 NOTICE It is the Purchaser’s/Owner’s obligation: Smith Press Attachment 1. To disclose and post all Rules & Regulations, Danger, Warning and Caution (Option for CXT-200) labels affi xed on the machine to their customers/users.
-
Page 2: Table Of Contents
Should additional information be required, or should situations arise that are not covered by this owner’s manual, the matter should be directed to Customer Service at Tuff Stuff Fitness International Inc. in Chino, California. www.tuff stuffi tness.com CXT-225 Smith Press Attachment... -
Page 3: Safety Precautions
Safety Precautions 1. The Weight Lift Bar (CXT-225 Owner’s Manual part #8) has a twist locking mechanism that allows you to safely lock out the Weight Lift Bar (CXT-225 Owner’s Manual part #8) at virtually any setting. See Fig. A Fig. - Page 4 If problem persists, Do Not Use the Machine and contact your TuffStuff Retailer or Customer Service (888) 884-8275. Disengaged Press Bar During Exercise 5. The illustrations above depict the Weight Lift Bar (#8) disengaged setting which is used during exercise.
-
Page 5: Safety Precautions
Safety Precautions NOTE: WHEN NOT USING THE SMITH PRESS ATTACHMENT, FULLY ENGAGE THE WEIGHT LIFT BAR (#8) ON HIGHEST WEIGHT PRONGS AND SAFETY STOPPERS (#2, #3) RIGHT BELOW AS SHOWN BELOW. CXT-225 Smith Press Attachment www.tuff stuffi tness.com... -
Page 6: Important Safety Instructions
CAUTION: indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. www.tuff stuffi tness.com CXT-225 Smith Press Attachment... -
Page 7: Registration, Service & Assembly
Registration, Service & Assembly Thank you for purchasing the CXT-225 Smith Press Attachment. Weight Stack. This machine is part of the Tuff Stuff line of quality strength training equipment. To maximize your use of the equipment, please study the Owner’s Manual thoroughly. -
Page 8: Inspection/Maintenance
Professional Service Company approved by TFI. Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website www.tuff stuffi tness.com INSPECTION / MAINTENANCE RECORDS DATE REPLACEMENT REPAIRS INSPECTED BY WARRANTY REPAIRS DATE REPLACEMENT REPAIRS INSPECTED BY www.tuff stuffi tness.com CXT-225 Smith Press Attachment... -
Page 9: Anchoring Unit
Anchoring Unit Holes on shoe plates are provided for anchoring the unit to the fl oor. (See anchoring hole locations below) CXT-225 Smith Press Attachment www.tuff stuffi tness.com... -
Page 10: Danger, Warning, & Caution Labels Information
Carefully read ALL Danger, Warning & Caution labels posted on the machine CXT-225 Smith Press Attachment www.tuff stuffi tness.com... - Page 11 Carefully read ALL Danger, Warning & Caution labels posted on the machine CXT-225 Smith Press Attachment www.tuff stuffi tness.com...
- Page 12 Carefully read ALL Danger, Warning & Caution labels posted on the machine www.tuff stuffi tness.com CXT-225 Smith Press Attachment...
- Page 13 Facility Sign with your order, you can obtain one at no cost to you from Tuff Stuff Fitness by contacting our service department at: 1 (888) 884-8275 service@tuff stuff .net service1@tuff stuff .net CXT-225 Smith Press Attachment www.tuff stuffi tness.com...
-
Page 14: Label Instructions
3. Line up the top and side edges of the label with the bottom and side edges of the existing (small) label on the CXT-200 weight shield. 4. Make sure label is straight and slowly press into place from top to bottom. www.tuff stuffi tness.com CXT-225 Smith Press Attachment... -
Page 15: Step 1
Step 1 Remove CXT-200 Chin-up Bar NOTE: 1. It is strongly remmended that two people participate in the assembly of this unit. Loosely Tighten Loosely Tighten Loosely tighten all hardware in this step. CXT-225 Smith Press Attachment www.tuff stuffi tness.com... -
Page 16: Step
Step 2 Note: 1. Once linear shaft (#1) is in place, raise it to assemble hardware shown below. Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this step. www.tuff stuffi tness.com CXT-225 Smith Press Attachment... -
Page 17: Step 3
Step 3 Note: 1. Once linear shaft (#1)is in place, raise it to assemble hardware shown below. Fully Tighten 100% Fully Tighten Wrench tighten all hardware in this and previous loosely tighten steps. CXT-225 Smith Press Attachment www.tuff stuffi tness.com... -
Page 18: Parts List
LABEL DANGER SECURE BAR CATCH (SIZE 4 X 2) BNH3003 HEX HEAD CAP SCREW GR 5 Z/P 3/8 16 X 2 1/2 BNH2044 LABEL CXT 225 UPRIGHT NUMBERS 1 1/8 X 65 BNH3154 www.tuff stuffi tness.com CXT-225 Smith Press Attachment... -
Page 19: Exploded View
Notes CXT-225 Smith Press Attachment www.tuff stuffi tness.com... -
Page 20: Basic Exercise Guide
Warm up properly with stretchings, calisthenics or cardiovascular exercises. Never hold your breath – general rule of thumb is to exhale when you exert. www.tuff stuffi tness.com CXT-225 Smith P... -
Page 21: Notes
Press Attachment... -
Page 22: Warranty
No modification of this warranty or waiver of its terms shall be binding on either party unless approved in writing by an authorized repre- sentative of the party. Contact TuffStuff Fitness International at 13971 Norton Avenue, Chino, CA 91710, before returning any defective equipment. - Page 23 Exploded View Remove CXT-200 Chin-up Bar 17 42 23 23 42 17 23 28 23 42 17 23 28 33 23 23 27 CXT-225 Smith Press Attachment www.tuff stuffi tness.com...
