Apollo Modular Gym Systems (Deluxe); Parts List (Base Unit) - TuffStuff Apollo Owner's Manual

CHART
BOLD FONT = SUB-ASSEMBLY PARTS
REGULAR FONT = HARDWARE
ITEM NO. DESCRIPTION
1 ACTUATOR ARM
2 BACK PAD ADJUSTABLE BRACKET
3 BACK PAD ADJUSTABLE TUBE
4 BENCH PRESS ADJUSTABLE SEAT FRAME
5 BENCH PRESS BACK PAD
6 BENCH PRESS SEAT PAD
7 BOTTOM CONNECTOR PRESS BAR/PEC FLY
8 CABLE RETAINER BRACKET
9 CHROME PEC DEC SWIVEL HANDLE
10 CHROME SOLID GUIDE ROD 3/4 X 72
11 CIRCULAR PLATE W/AXLE
12 CLOSED-END DOUBLE PULLEY BRACKET
13 FOAM ROLL 1 X 5 1/2 X 7 1/4
14 FOAM ROLL 2 X 5 1/2 X 18
15 FOOT ROLL TUBE 1 X 29
16 FRONT UPRIGHT
17 GUIDE ROD RETAINER
18 GUIDE ROD RETAINER PRESS BAR STATION
19 HANDLE LEFT SIDE
20 HANDLE RIGHT SIDE
21 LAT BAR HOLDER 2 X 3
22 LAT CABLE
23 LEG EXTENSION ARM SUPPORT
24 LEG EXTENSION BACK PAD
25 LEG EXTENSION BOTTOM CONNECTOR
26 LEG EXTENSION CABLE
27 LEG EXTENSION FRONT FRAME
28 LEG EXTENSION SEAT FRAME
29 LEG EXTENSION SEAT PAD
30 LONG ADJUSTABLE STOPPER
31 MAGNETIC SELECTOR PIN W/COIL 3/8 X 4
32 MID ROW HANDLE LT SIDE
33 MID ROW HANDLE RT SIDE
34 MID ROW PULL ARM
35 PEC DEC ARM LEFT SIDE
36 PEC DEC ARM RIGHT SIDE
37 PEC DEC CABLE
38 PIVOT ARM LEG EXTENSION
39 PIVOT AXLE 1 X 8 1/8
40 PIVOT AXLE 1 X 9
41 PRESS BAR SELECTOR HOUSING
42 PRESS BAR (DETACHABLE HANDLES)
43 REINFORCEMENT PLATE 1/4 X 2 X 8 1/2
44 REMOVABLE HANDLE LT SIDE
45 REMOVABLE HANDLE RT SIDE
46 SAFETY SHIELD COVER PLATE 1 1/2 X 5
47 SWIVEL FOAM ROLL TUBE
48 TOP ADJUSTABLE LEG HOLDER TUBE
49 TOP PULLEY ASSEMBLY
50 WEIGHT SHIELD
51 WEIGHT SHIELD (APT-5.1)
52 WEIGHT SHIELD HOLDER
53 WEIGHT STACK FRAME
54 WEIGHT STACK SPACER 4"
56 10 LB STEEL WEIGHT PLATE BLACK 4 9/16 X 9 7/16
58 10 LB TOP PLATE W/ADJ SLTR BAR 19 BLK WTS
Apollo Modular Gym System (Base Unit)

Apollo Modular Gym Systems (Deluxe)

PART NO. QTY. QTY. ITEM NO.
UP0344 1 59 ABS PIPE 2 X 19 3/8
60 ALUMINUM CAM PLATE 3/4 X 5" RADIUS
UP0554 1
UP0347 1 61 ALUMINUM CAP 1.020" RD (CAP-100)
UP0676 1 62 ALUMINUM CAP 1.270" RD (CAP -125)
UP0370 1 63 ALUMINUM COLLAR 1.0312 ID X 1.521 OD X .500 THK.
UP0372 1 64 ALUMINUM FOOT ROLL HOLDER 1 5/16 ID X 4 1/2 OD X 3/4
UP2006 1 65 ALUMINUM FOOT ROLL HOLDER 2 3/8 ID X 4 1/2 OD X 3/4
UP0014 4 66 ALUMINUM PULLEY 3/8" X 3 1/2"
UP0324 2 67 ALUMINUM PULLEY 3/8" X 4 1/2"
UP0124 8 68 ALUMINUM WASHER 3/8 X 2.584 OD X .15 THK.
UP0671 1 69 BALL BEARING #W 516
UP0329 1 70 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8
UP0350 2 71 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1
UP2031 2 72 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 1/4
UP0974 1 73 CHROME CAP 2" RD
UP2008 1 74 CHROME WASHER 3/8 X 1 1/2
UP2033 3 75 CLEVIS BRACKET 3/16"
UP2010 1 76 COIL CHAIN Z/P 3/16 X 8
77 DECAL-1" RD SILVER MYLAR CIRCLE
UP0271 1
UP0270 1 78 DECAL-ADJUST CABLE HERE
UP0327 1 79 DECAL-CAUTION 1 3/4 X 5 1/2
UP2021 1 80 DECAL-CAUTION LAT BAR HOLDER 5 X 1
UP2028 1 81 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1 1/2
UP0371 1 82 DECAL-EXERCISE LAT, VERTICAL PRESS, PEC FLY & LEG EXT
UP2001 1 83 DECAL-EXR LAT, MID ROW, PEC FLY, LEG EXT & MULTI-PRESS
UP2025 1 84 DECAL-FOR BEST PERFORMANCE 1 1/4 X 1 1/2
85 DECAL-WEIGHT NUMBERS REF TP-10 (200 lbs)
UP0666 1
UP2002 1 86 DECAL-WARNING KEEP HANDS AND FINGERS...
UP0348 1 87 EDGE PROTECTOR CHROME 18 GA X 72
UP0331 1 88 FINISHED HEX NUT B/O 1/2-13
UP3035 4 89 FLAT PHILLIPS MACHINE SCREW 8-32 X 1/4
UP4236 * 1 90 FLAT PHILLIPS SCREW ZINC # 2 X 1/2
UP4237 * 1 91 FLAT PHILLIPS SCREW ZINC # 5 X 1/2
UP4221 * 1 92 FLAT WASHER B/O 3/4 X 2"
93 FLAT WASHER SAE B/O 3/8"
UP0819 1
UP0818 1 94 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1
UP2022 1 95 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/2
UP2030 1 96 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4
UP0152 2 97 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4
UP4238 * 1 98 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2
UP0326 1 99 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 1/2
UP3573 1 100 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 3/4
UP2106 3 101 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4
102 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4
UP3574 1
UP3575 1 103 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4
UP1767 1 104 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/4
UP2026 1 105 HEX KEY 3/32"
UP0672 1 106 HEX KEY ALLOY 1/8"
UP2007 1 107 HEX KEY ALLOY 3/16"
UP2017 3 108 HEX KEY ALLOY 7/32"
UP1750 1 109 LABEL-ADJUSTMENT BACK PAD 9/16 X 7.5
110 LABEL-ADJUSTMENT PRESS BAR 9/16 X 6
UP2016 8
UP2000 1 111 LAT BAR 48"
UP0786 2 112 LOW ROW BAR 20"
BNH1650 76 113 METAL HINGE
BNH1982 4 114 NYLON BALL 1 3/4 X 5/16

Parts List (Base Unit)

DESCRIPTION PART NO. QTY.
BNH1639 2
BNH1153 2
BNH0537 4
BNH0538 4
BNH1519 2
BNH1509 4
BNH1510 4
BNH1266 2
BNH0069 19
BNH1521 2
BNH0628 2
BNH0527 12
BNH0115 8
BNH0896 2
BNH1137 2
BNH1015 6
BNH0076 1
BNH1214 1
BNH0015 4
BNH0789 2
BNH0126 1
BNH0140 1
BNH0142 6
BNH1673 1
BNH1674
BNH0143 4
BNH1542 4
BNH0620 1
BNH1836 8
BNH0201 4
BNH0408 2
BNH1480 2
BNH1481 4
BNH0878 8
BNH0239 101
BNH0275 2
BNH0303 1
BNH0273 10
BNH0274 8
BNH0279 3
BNH0276 3
BNH0278 2
BNH0312 17
BNH0283 16
BNH0285 2
BNH0317 11
BNH0372 1
BNH0767 1
BNH0371 1
BNH0575 2
BNH0080 1
BNH0079 1
BNH0295 1
BNH0294 1
BNH0046 2
BNH0047 1
PARTS LIST
QTY. ITEM NO. DESCRIPTION
115 NYLON BUSHING 1 X 1 1/2 X 7/8 X 1 3/4 X 1/8
116 NYLON FLAT WASHER 1 X 1 1/4 X 1/16
117 NYLON FLAT WASHER 3/8 ID X 3/4 OD X 1/16 THK
118 NYLON INSERT JAM LOCK NUT B/O 3/8-16
119 NYLON INSERT LOCK NUT B/O 3/8-16
120 NYLON INSERT LOCK NUT B/O 5/16-18
121 NYLON SPACER 3/8 X 3/4 X 3/8
122 PLASTIC END CAP 2 X 3
123 PLASTIC INSERT CAP 1 3/4" SQ
124 PLASTIC INSERT CAP 1" X 2"
125 PLASTIC INSERT CAP 2 X 3
126 PLASTIC INSERT CAP 2" SQ
127 PLASTIC TIES 14 1/2"
128 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/4" SQ
129 PULL PIN 1/2 X 2 7/8 (YELLOW KNOB)
130 PULL PIN 1/2 X 3 1/2 (YELLOW KNOB)
131 PULL PIN 1/4 X 3 1/2 (YELLOW KNOB)
132 PVC 1 X 8 3/4
133 RETAINING SNAP RING EXT .925 X 1 X .042
134 ROLL PIN Z/P 3/8 X 1 1/2
135 RUBBER BUMPER 3/8 X 1 1/2
136 RUBBER DONUT 3/4 X 2 1/2
137 RUBBER GRIP 1 ID X .125 X 8
138 RUBBER GRIP 1 ID X .125 X 8 1/2
* 1 139 RUBBER GRIP 1 X 6 1/4
140 RUBBER GRIP 1.1875 ID X .125 X 13
141 RUBBER GRIP 1.1875 ID X .125 X 4 5/8
142 RUBBER GROMMET 3/4" ID
143 RUBBER STOPPER 1 ID X .187 X 3
144 SHOULDER BOLT ALLOY 3/8 X 3/4
145 SNAP LINK Z/P 8MM X 80MM
146 SOCKET HEAD CAP SCREW B/O 1/4-20 X 3/4
147 SOCKET SET SCREW ALLOY 1/4-20 X 1/4
148 SOCKET SET SCREW ALLOY 10-32 X 1/4
149 SOCKET SET SCREW ALLOY 10-32 X 1/8
150 SOCKET SET SCREW ALLOY 3/8-16 X 1/2
151 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2
152 SPLIT LOCK WASHER B/O 3/8"
153 SPLIT LOCK WASHER Z/P 1/2"
154 TUFFSTUFF LOGO ALUMINUM LARGE
155 TUFFSTUFF LOGO ALUMINUM SMALL
156 TURN/PULL PIN W/KNOB AND LOCK
157 URETHANE BUMPER 1 3/4
158 URETHANE BUMPER 962
* Mid Row Station Item Quantities
Apollo Modular Gym Systems (Standard)
Parts List (Base Unit)
All parts same as Deluxe, except for the parts listed below
ITEM NO. DESCRIPTION
66 NYLON PULLEY 3/8 X 3 1/2
67 NYLON PULLEY 3/8 X 4 1/2
REV1
PART NO. QTY. QTY.
BNH0531 4
BNH0393 2
BNH0248 4
BNH0365 18
BNH0214 46
BNH0215 2
BNH0392 2
BNH0606 4
BNH0053 2
BNH0005 4
BNH0052 1
BNH0012 9
BNH0703 2
BNH0059 2
BNH0641 1
BNH0603 4
BNH0713 1
BNH1611 2
BNH0419 2
BNH0483 1
BNH0514 1
BNH0068 8
BNH0966 2
BNH1075 2
BNH0296 4
BNH0853 * 2
BNH1643 6
BNH0401 8
BNH0976 2
BNH0718 2
BNH0065 3
BNH0452 2
BNH0790 1
BNH0473 4
BNH0473 24
BNH0474 6
BNH1131 2
BNH0658 10
BNH0572 4
BNH1324 2
BNH1323 2
BNH0989 2
BNH0229 8
BNH0244 2
PART NO. QTY. QTY.
BNH0553 2
BNH0506 19
