Summary of Contents for Perfect Aire 3PES5000
- Page 1 Your Source for Home Comfort 5,000 BTU WINDOW AIR CONDITIONER USER MANUAL FOR MODEL: 3PES5000 Before using your window air conditioner, please read this manual carefully and keep it for future reference, along with your receipt.
-
Page 2: Table Of Contents
NOTE: All the illustrations in this manual are for explanation purposes only. Unit purchased may be slightly different. The design and specifications are subject to change without prior notice for product improvement. Contact Perfect Aire Consumer Services for details. Perfect Aire Consumer Services: 877-365-6274... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The seriousness is classified by the following indications. WARNING This symbol indicates the possibility of death or serious injury. - Page 4 ! CAUTION When removing air filter, do not Ensure proper ventilation touch metal parts of the unit. especially in rooms with a stove or other appliances. Doing so may cause an injury. Water may enter the unit and Failure to do so may result in an degrade the insulation causing an oxygen shortage.
-
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS For Your Safety WARNING! NOTE: The power supply cord with this • DO NOT store or use gasoline or other flammable vapors or liquids in the air conditioner contains a current vicinity of this or any other appliance. detection device designed to reduce the •... -
Page 6: Normal Sounds
NORMAL SOUNDS High Pitched Chatter High efficiency compressors Vibration may have a high pitched chatter during the cooling cycle. Unit may vibrate and make noise because of poor wall or window construction or incorrect installation. Sound of Rushing Air At the front of the unit, you may hear the sound of rushing air being moved by the fan Pinging or Switching... -
Page 7: Power Button
TEMP/TIMER Auto Auto AIR CONDITIONER FEATURES (CONTINUED) Cool Follow High The following instructions represent the Unit Controls. The same instructions can be used for the Remote Control. Mode On O POWER button The unit will automatically initiate the Energy Saver Energy Sleep Timer... - Page 8 AIR CONDITIONER FEATURES (CONTINUED) Mode On O ENERGY SAVER button This function is available on Cool, Dry, and Auto Energy Timer Sleep Saver (only Auto-Cooling and Auto-Fan) modes. In this Press the mode,the fan will continue to run for 3 minutes after the TEMP/TIMER “Energy compressor shuts off.The fan then cycles on for 2...
- Page 9 Auto Auto Cool Follow High AIR CONDITIONER FEATURES (CONTINUED) Mode On O CHECK FILTER button This feature is a reminder to clean the Air Filter for Press “Check Energy Timer Sleep more efficient operation. The LED (light) will illuminate after Filter”...
-
Page 10: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE YOU BEGIN CAUTION Read these instructions completely Do not, under any circumstances, cut or and carefully. remove the third (ground) prong from the power cord. IMPORTANT- Save these instructions. Do not change the plug on the power cord IMPORTANT- Observe all of the air conditioner. -
Page 11: Mounting Hardware
INSTALLATION INSTRUCTIONS (CONTINUED) PREPARE THE WINDOW C: Align the hole in the top rail with those in the Lower sash must open sufficiently to allow a clear top of the unit as shown in Fig.B vertical opening of 13 inches (330 mm). Side louvers and the rear of the AC must have clear air Fig.B space to allow enough airflow through the... - Page 12 INSTALLATION INSTRUCTIONS (CONTINUED) B. Slide the free end "｢" section of the panel SECURE THE ACCORDION PANELS directly into the cabinet as shown in Fig. 2. Slide the panel down. Be sure to leave A. Keeping a firm grip on the air conditioner, enough space to slip the top and bottom of carefully place the unit into the window opening so the frame into the rails on the cabinet.
-
Page 13: Removing Ac From Window
INSTALLATION INSTRUCTIONS (CONTINUED) B. Drive 3/4 " (19 mm) or 1/2 " (12.7 mm) If AC is Blocked by Stor m Window locking screws through frame holes into window sash (Fig. 8). Add wood as shown in Fig.11, or remove storm window before air conditioner is installed. -
Page 14: Care And Cleaning
CARE AND CLEANING CAUTION Clean air conditioner occasionally to keep it looking and operating like new. Be sure to unplug the unit before cleaning to prevent shock or fire hazards. Air Filter Cleaning The air filter should be cleaned at least every two weeks or as necessary. -
Page 15: Troubleshooting Tips
TROUBLESHOOTING TIPS Before calling for service, please review the chart below. Issue Possible Solutions • Be sure unit is not too large or too small for the area of the room. • Verify that all doors, windows, curtains and any other openings are closed off. Verify nothing is obstructing the front grille of unit, such as curtains, etc. - Page 16 Your Source for Home Comfort Distributed by: Perfect Aire, LLC 5151 Belt Line Rd. Suite 878 Dallas, TX 75254 877-365-6274 www.perfectaire.us Specification and performance data is subject to change without notice. Printed in China...
