- Page 1 8 Port Nway Gigabit Switch 065-7908A Model User‘s Guide...
- Page 2 CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. SIGNAMAX LLC • www.signamax.eu...
- Page 3 The compact rigid desktop size was specifically designed for small to medium workgroups. 065-7908A switch can be installed where space is limited; moreover, it provides smooth network migration and easy upgrade to network capacity.
-
Page 4: Package Contents
Package Contents Before you start to install this switch, please verify your package that contains the following items: One 065-7908A Gigabit Ethernet Switch One Power Cord One CD with User’s Manual Note: If any of these items is found missing or damaged, please contact your local supplier for replacement. - Page 5 LED Indicators of 8 Port 10/100/1000M Switch Status Description Power Power is on. Power is off. LINK/ACT Port is for connection. No connection. Flashing Data is transmitting or receiving 1000M Port is on 1000M status Port is on 10/100M status. SIGNAMAX LLC • www.signamax.eu...
- Page 6 It is simple and friendly to up-link to another switch without crossover cable. PC/Other devices to 065-7908A Gigabit Ethernet Switch Via a twisted pair cable straight through, 065-7908A switch can be connected to PCs, servers and other network devices. SIGNAMAX LLC • www.signamax.eu...
- Page 7 UTP/STP Transmission Media 100BaseTX Cat. 5 UTP/STP 1000BaseT Cat. 5E UTP/STP Per Port: LINK/ACT, 1000M LED Indicators Per Unit: Power Power Requirement 100~240V/AC, 50~60Hz Power Consumption 15 Watts (Max) Dimensions 228 × 123 × 44 mm SIGNAMAX LLC • www.signamax.eu...
- Page 8 (L x W x H) Weight 0.92 kg Operating 0 to 55℃ Temperature Storage -20 to 90℃ Temperature 10 to 90% RH Humidity (non-condensing) Certifications FCC Class B, CE SIGNAMAX LLC • www.signamax.eu...
