- Page 1 24 Port Nway Fast Ethernet Switch 065-7341 Model User‘s Guide...
- Page 2 CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. SIGNAMAX LLC • www.signamax.eu...
- Page 3 The compact rigid desktop size was specifically designed for small to medium workgroups. 065-7341 switch can be installed where space is limited; moreover, it provides smooth network migration and easy upgrade to network capacity.
-
Page 4: Package Contents
Package Contents Before you start to install this switch, please verify your package that contains the following items: One 065-7341 Fast Ethernet Switch One Power Cord One CD with User’s Manual Note: If any of these items is found missing or damaged, please contact your local supplier for replacement. - Page 5 LED Indicators of 24 Port 10/100M Switch Status Description Power Power is on. Power is off. LINK/ACT Port is for connection. No connection. Flashing Data is transmitting or receiving 10/100M Port is on 100M status Port is on 10M status. SIGNAMAX LLC • www.signamax.eu...
- Page 6 It is simple and friendly to up-link to another switch without crossover cable. PC/Other devices to 065-7341 Fast Ethernet Switch Via a twisted pair cable straight through, 065-7341 switch can be connected to PCs, servers and other network devices. SIGNAMAX LLC • www.signamax.eu...
- Page 7 Per Port: LINK/ACT, LED Indicators 10/100M Per Unit: Power Power Requirement 100~240V/AC, 50~60Hz Power Consumption 12 Watts (Max) 266 × 160 × 44 mm Dimensions (L x W x H) Weight 1.7 kg Operating 0 to 55℃ Temperature SIGNAMAX LLC • www.signamax.eu...
- Page 8 Storage -20 to 90℃ Temperature 10 to 90% RH Humidity (non-condensing) Certifications FCC Class B, CE SIGNAMAX LLC • www.signamax.eu...
