Wiring using two Charging Devices
TO AUXILIARY
EQUIPMENT
FUSE
interVOLT Model
DCC1225ACD
Battery to Battery
Charging Device
12VDC - 12VDC
25 Amps max.
DCC PRO B
MAIN
12V
AUX 1
OK
TO
ENGINE
FUSE
FUSE
12V
interVOLT Model
DCC1225ACD
Battery to Battery
Charging Device
12VDC - 12VDC
25 Amps max.
DCC PRO A
DCC DISPLAY
TO AUXILIARY
EQUIPMENT
FUSE
12V
AUX 2
11
