XVision XPD421DNV Instruction Manual

Colour 580tvl, dynamic night view, dnr & auto iris varifocal lens
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XPD421DNV
Model:
Dynamic Night View, DNR Dome
Camera

Before you begin

•
Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor or outdoor use. Please bear in mind the following points when
choosing a mounting position.
•
The camera must be positioned so that it will not point directly into the sun (sunrise and
sunset) or any bright light, as this may cause damage to the camera.
•
Avoid viewing areas where half the area is in bright sunlight and the other half is dark,
such as in the shadow of a building. All types of cameras have difficulty in 'seeing' with
such a large lux level variation.
•
Do not cut the camera cables, this will void the warranty.
•
Make sure you use only the recommended power supply. Damage caused to the camera by
incorrect voltage or wiring is not covered by the warranty.
Model:
XPD421DNV
Colour 580TVL, Dynamic Night
View, DNR & Auto Iris Varifocal Lens

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XPD421DNV and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XPD421DNV

Summary of Contents for XVision XPD421DNV

  • Page 1: Before You Begin

    XPD421DNV Model: Dynamic Night View, DNR Dome Camera Before you begin • Please unpack the box carefully and identify that all the parts are present. The camera is suitable for indoor or outdoor use. Please bear in mind the following points when choosing a mounting position.

  • Page 2: Safety Precautions

    2. Product Description The XPD421DNV Colour, varifocal dome camera is designed for high risk applications. It offers very high resolution Colour 580TVL images and 0.002 lux low light sensitivity from its Sony 1/3" CCD sensor. It features Dynamic Night View, Smart DNR for disk saving and a Varifocal Auto Iris Lens.
  • Page 3 3. Features Sony 1/3" CCD Image Sensor for 580 TVL resolution images Samsung DSP Chip & Xvision X3 DSP Software 2.8 to 11.0mm Auto Iris Varifocal lens for 26° to 92° viewing angle for super sharp images and easy selection of the optimum viewing angle during installation.

  • Page 4: Installation

    5. Installation 1. Select a suitable position on the wall or ceiling to install the camera. 2. Remove the dome housing from the camera housing. 3. Secure the camera in the desired ceiling position with the four fixing screws (as shown in Figure 1). Figure 1 4.

  • Page 5: How To Operate

    6. How to Operate 1. Connect the video output to the monitor or other video device through a 75 Ohms type coaxial cable. 2. Connect the power source, insert the AC plug into the AC socket and the DC plug into the DC Jack (+12V DC in jack centre) (as shown in Figure 3).

  • Page 6: Camera Osd Control

    7. Camera OSD Control Press this Control Action Push DOWN UP, DOWN Select a new item to Setup LEFT, RIGHT Select a menu item menu SETUP (MENU) Access a sub menu 8. OSD Menu Structure SET UP MENU LENS Option MANUAL SHUTTER MANUAL...

  • Page 7: Setup Menu Functions

    9. SETUP Menu Functions 1 LENS <Option: DC / MANUAL> Selects lens type. 2 SHUTTER <Option: OFF / FLK / MANUAL/ ESC> Adjusts shutter settings. Flickerless mode (FLK) reduces on-screen flickering. Electronic Shutter Control (ESC) adjusts brightness level on screen. Manual mode allows you to adjust the shutter speed from 1/60~1/120,000 of a second (NTSC), or 1/50~1/120,000 (PAL).
  • Page 8 9. SETUP Menu Functions (continued) 4 BACK LIGHT <Option: OFF / LOW / MIDDLE / HIGH> Provides light level control to overcome severe backlighting conditions. 5 AGC <Option: OFF / LOW / MIDDLE / HIGH> Adjusts value of AGC gain. Increase the GAIN level to brighten the picture.

  • Page 9: Special Menu Functions

    9. SETUP Menu Functions (continued) 9 EXIT Exit the SETUP menu and returns to video monitoring. 10. SPECIAL Menu Functions On the SETUP menu, press the menu control UP or DOWN and then select SPECIAL. Press the SETUP (MENU) control to access the SPECIAL MENU. 1 CAMERA ID <Option: OFF / ON>...

  • Page 10: Motion Det

    10. SPECIAL Menu Functions (continued) 2 COLOUR <Option: AUTO / ON> AUTO= Automatically detect colour or black/white ON= Full time colour mode 3 SYNC <Option: INT / L/L> INT = Synchronize the vertical interval sync pulse of your camera with other equipment to reduce the effect of picture roll on the monitor.
  • Page 11 10. SPECIAL Menu Functions (continued) AREA SEL= Select a motion detection grid (top left, top right, bottom left, bottom right) to modify. AREA STATE= Activate or deactivate the selected grid. TOP/DOWN/LEFT/RIGHT= Press LEFT or RIGHT menu control left or right to alter the dimensions of the selected grid. 5 PRIVACY <Option: OFF/ON>...
  • Page 12 10. SPECIAL Menu Functions (continued) 8 RESET Restore all factory default settings. 9 RETURN Return to the main SETUP menu. 11. Using the Chameleon Cover 1. Simply place the chameleon cover over the dome and press down until your hear it click. 2.

  • Page 13: Specifications

    12. Specifications Model: XPD421DNV Picture Type: Colour Image Sensor: Sony 1/3” CCD DSP: Samsung DSP Chip & Xvision X3 DSP Software Resolution: 580TVL Colour Lens Viewing Angle: 26 to 92° Infra Red Nightvision: Minimum Illumination: 0.002 Lux Audio: Operating Voltage:...
  • Page 14 NOTES...
  • Page 15 NOTES...

  • Page 16: Technical Support

    TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a limited 3 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
