XVision XP1080S20 Installation Manual

Quick installation speed dome
Hide thumbs Also See for XP1080S20:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
XP1080S20
Quick Installation Speed Dome Installation Manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XP1080S20 and is the answer not in the manual?

Questions and answers

Related Manuals for XVision XP1080S20

Summary of Contents for XVision XP1080S20

  • Page 1 XP1080S20 Quick Installation Speed Dome Installation Manual Version 1.0...

  • Page 2: Table Of Contents

    Table of Contents QUICK INSTALLATION SPEED DOME INSTALLATION ........7 1. 1 Installation Preparation ............................7 1. 2 Installation ................................8 1.2.1 Address and Baud Rate Setup ........................8 1.2.2 Install the transparent cover ......................... 9 1.2.3 Install the speed dome..........................10 1. 3 Initial Setup ................................
  • Page 3 HANG MOUNT BRACKET INSTALLATION............18 4. 1 Component Installation ............................. 18 4. 2 Installation ................................18 4.2.1 Installation Requirements ..........................18 4.2.2 Installation Steps ............................18 CORNER MOUNT BRACKET INSTALLATION ............20 5. 1 Component Installation ............................. 20 5. 2 Installation ................................
  • Page 4 Welcome Thank you for purchasing our speed dome! Please read the following safeguards and warnings carefully before you install or use the product!

  • Page 5: Important Safeguards And Warnings

    Important Safeguards and Warnings Safety Measures Qualified Engineer Needed  The installation engineer or maintenance engineer shall have corresponding CCTV system installation certificate or maintenance qualification certificate.  The installation engineer or maintenance engineer shall have qualification certificate for work at height.
  • Page 6 Safety Transportation  Heavy stress, violent vibration or water splash are not allowed during transportation, storage and installation.  This series product must use split type package during the transportation.  We are not liable for any damage or problem resulting from the integrated package during the transportation.

  • Page 7: Quick Installation Speed Dome Installation

    1 QUICK INSTALLATION SPEED DOME INSTALLATION 1.1 Installation Preparation Basic Requirement  All installation and operation here should conform to your local electrical safety codes.  Before installation, please open the package and check all the components are included. Please make sure the speed dome installation environment and installation mode can meet your requirement.

  • Page 8: Installation

    1.2 Installation Please note the quick installation speed dome includes the quick installation high speed dome, IP quick installation speed dome, tracing quick installation high speed dome, quick installation medium speed dome. The speed dome has several types of installation brackets. You can refer to the following contents for detailed information.

  • Page 9: Install The Transparent Cover

    1.2.2 Install the transparent cover First, you need to check the steel wire of the bracket is firmly secure or not. Please line up the captive screws to the quadrate groove of the bracket and then push the bracket into the internal enclosure. Fix these two captive screws. See Figure 1-3. Figure 1-3 Now you can install the quick installation port.

  • Page 10: Install The Speed Dome

    Figure 1-5 Note The video port is covered the heat shrink tube of high shrinking ratio. After the video connection, please heat the tube to make sure the video port is damp proof and water proof. 1.2.3 Install the speed dome After you complete the above steps, please pull the integration cable and multiple-function composite cable to the wall mount bracket.
  • Page 11 Figure 1-6 Important After the installation, please make sure:  The three stainless screws of the quick installation port are firmly secure.  The quick installation speed dome is fixed.  The speed dome is straight.  The steel wire connection is firm. After your installation, the interface is shown as in Figure 1-7.

  • Page 12: Initial Setup

    1.3 Initial Setup The default setup is:  Address: 1  Baud rate: 9600 1.4 Dial Switch Setup The two dial switches of the speed dome are SW1 and SW2. These are to specify the sp eed dome parameter such as protocol, baud rate, address and etc. When the button is ON, it is 1. In the SW1 and SW2, 1 is the lowest bit and the 8 is the highest bit.

  • Page 13: Address Setup

    2400bps 1200bps Please refer to the parity setup sheet for detailed information. Parity NONE EVEN NONE 1.4.2 Address Setup The speed dome address setup interface is shown as below. See Figure 1-9. Figure 1-9 The encode mode adopts binary system. 1 to 8 is valid bit. The highest address bit is 255. You can refer to the following sheet for more information.

  • Page 14: Bracket Dimensions

    2 BRACKET DIMENSIONS 2.1 Wall mount bracket The wall mount bracket dimensions are shown as below. See Figure 2-1. Figure 2-1 2.2 Hanging mount bracket (Multiple Lengths) The hanging mount bracket is shown as below. See Figure 2-2. The bracket length setup values are： ...

  • Page 15: Corner Mount Bracket

    2.3 Corner mount bracket The corner mount bracket is shown as below. See Figure 2-3. Figure 2-3 2.4 Pole mount bracket The corner mount bracket is shown as below. See Figure 2-4. Figure 2-4...

  • Page 16: Wall Mount Bracket Installation

    3 WALL MOUNT BRACKET INSTALLATION 3.1 Component Installation Wall mount bracket is shown as below. See Figure 3-1. Figure 3-1 3.2 Installation 3.2.1 Installation Requirements The wall mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments.
  • Page 17 Install the speed dome in the bracket. See Figure 3-3. Figure 3-3 Please refer to chapter 1.2 for detailed installation information.

  • Page 18: Hang Mount Bracket Installation

    4 HANG MOUNT BRACKET INSTALLATION 4.1 Component Installation Hang mount bracket and its components are shown as below. See Figure 4-1. Figure 4-1 4.2 Installation 4.2.1 Installation Requirements The hang mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments.
  • Page 19 Pull the cable through the steeve and then secure the steeve to the flange. Fix the M4 bolt. Please note, if the speed dome is installed in the outdoor environments, you need to paste enough Teflon tape at the top screw thread of the steeve and then turn the steeve to the flange firmly.

  • Page 20: Corner Mount Bracket Installation

    5 CORNER MOUNT BRACKET INSTALLATION 5.1 Component Installation Corner mount bracket and its components are shown as below. See Figure 5-1. Figure 5-1 5.2 Installation 5.2.1 Installation Requirements The corner mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments where there is a 90 degrees angle.
  • Page 21 Figure 5-3 Please refer to chapter 1.2 for detailed installation information.

  • Page 22: Pole Mount Bracket Installation

    6 POLE MOUNT BRACKET INSTALLATION Pole mount bracket and its components are shown as below. See Figure 6-1. Figure 6-1 6.1 Installation 6.1.1 Installation Requirements The corner mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments.
  • Page 23 Clamp and pole bracket connection Pole bracket and the pole connection Figure 6-3 After you installed bracket and external cover, loosen the captive screws and open the panel, pull the power cable through the hanging bracket and then fix the hanging bracket to the wall. Please pay attention to the waterproof between the bracket and the wall.

  • Page 24: Appendix Ⅰ Thunder Proof And Surge Protection

    7 APPENDIX Ⅰ THUNDER PROOF AND SURGE PROTECTION This series speed dome adopts TVS lighting protection technology. It can effectively prevent damages from various pulse signals below 1500W, such as sudden lighting and surge. While maintaining your local electrical safety code, you still need to take necessary precaution measures when installing the speed dome in the outdoor environment.

  • Page 25: Appendix Ⅱ About Rs485 Bus

    8 APPENDIX Ⅱ ABOUT RS485 BUS 8.1 RS485 Bus Main Feature RS485 is semi duplex communication cable of impedance 120Ω. Its max load amount is 32 effective loads (including main control device and devices to be charged). 8.2 RS485 Bus Transmission Distance When we take 0.56mm (24AWG) twisted-pair as communication cable, the max transmission distance (theoretically) are listed below (according to different baud rates).

  • Page 26: Rs485 Bus Faq

    Figure 8-2 8.4 RS485 Bus FAQ Phenomenon Possible Reasons Solution   Modify host or speed dome setup ； Speed dome Host address(baud rate) and  can run self- speed dome address(baud rate) Switch RS485 positive end and diagnosis but I are not match;...
