XPD621
Model:
True Day/Night 580/700 TVL Vandal Resistant
IR Dome Camera with 25m Night Vision & Auto
Iris Varifocal Lens

Before you begin

• Please unpack the box carefully and identify that all the parts are present.
The camera is suitable for indoor or outdoor use. Please bear in mind the following
points when choosing a mounting position.
• The camera must be positioned so that it will not point directly into the sun (sunrise
and sunset) or any bright light, as this may cause damage to the camera.
• Do not cut the camera cables, this will void the warranty.
• Make sure you use only the recommended power supply. Damage caused to the
camera by incorrect voltage or wiring is not covered by the warranty.
Model:
XPD621
True Day/Night 580/700 TVL Vandal Resistant IR Dome
Camera with 25m Night Vision & Auto Iris Varifocal Lens

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XPD621 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XVision XPD621

Summary of Contents for XVision XPD621

  • Page 1: Before You Begin

    XPD621 Model: True Day/Night 580/700 TVL Vandal Resistant IR Dome Camera with 25m Night Vision & Auto Iris Varifocal Lens Before you begin • Please unpack the box carefully and identify that all the parts are present. The camera is suitable for indoor or outdoor use. Please bear in mind the following points when choosing a mounting position.

  • Page 2: Safety Precautions

    2. Product Description The XPD621 dome camera is designed for high risk applications and is able to withstand a blow from a 10 pound sledgehammer. It offers very high resolution images of 580 TVL in Colour mode and 700 TVL in B/W mode, with a low lux sensitivity of 0.0003 lux.
  • Page 3 700 TVL resolution images in B/W mode and 580 TVL in Colour. z Sony 1/3” Ex View CCD Image Sensor with Xvision XX3 DSP. z 2.8 to 11.0mm Aspherical Auto Iris Varifocal lens for 26° to 92° viewing angle for super sharp images and easy selection of the optimum viewing angle during installation.

  • Page 4: Installation

    5. Installation Unscrew the camera to also access the Camera 1. Select a suitable position on the wall or ceiling OSD Controls to install the camera. 2. Remove the dome housing from the camera housing by removing the four cross head retaining screws.

  • Page 5: Adjusting Lens

    5. Installation continued ADJUSTING LENS Make the Zoom Adjustment by rotating the screw anticlockwise for NEAR adjustment and clockwise for FAR ( ) adjustment until you get the desired view. Next make the Focal Adjustment by rotating the screw anti-clockwise for TELE adjustment and Clockwise for WIDE adjustment until you get the desired view.

  • Page 6: Camera Osd Control

    7. Camera OSD Control 1. Remove the dome housing to access the OSD Menu. (See Figure 1 for details). 2. Push the joystick controller down to access the menu options. Video Test Connector OSD Joystick Controller Actions Press this Control For this Action UP, DOWN Select a new item...
  • Page 7 9. SETUP Menu Functions 1. LENS <Option : DC / MANUAL> This option should be left on DC. 2. EXPOSURE <Option : SHUTTER / BRIGHTNESS / AGC / SENS-UP / BLC / D-WDR / RETURN> • SHUTTER: Adjusts shutter settings <AUTO / FLK / MANUAL> - AUTO - Adjusts shutter settings to control the brightness level on screen.

  • Page 8: White Balance

    9. SETUP Menu Functions continued 3. WHITE BALANCE <Option : ATW / AWB / AWC-SET / MANUAL / INDOOR / OUTDOOR > • ATW: Auto Tracking White Balance. Use this mode when the colour temperature is between 1800k~10,500k • AWB: Automatic White Balance. This feature automatically adjusts the colour temperature of the camera image to match the type of light available, so that white and other colours appear as natural as possible.
  • Page 9 9. SETUP Menu Functions continued 6. SPECIAL MENU 6.1 CAM TITLE <Option : ON / OFF> Use the feature to display a title on the monitor. CAM TITLE 0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z / = &...
  • Page 10 9. SETUP Menu Functions continued 6.4 MOTION <Option : ON / OFF> This function will transmit an alert signal when it detects motion on screen. MOTION AREA SELECT AREA 1 AREA DISPLAY LEFT/RIGHT WIDTH TOP/BOTTOM HEIGHT SENSITIVITY MOTION VIEW RETURN •...
  • Page 11 9. SETUP Menu Functions continued 7. ADJUST <Option : SHARPNESS / BLUE / RED / RETURN > Adjust sharpness / RED and BLUE levels on the camera image. MOTION SHARPNESS BLUE RETURN 8. RESET Resets all settings to Factory Default. 9.

  • Page 12: Specifications

    Dimensions (ØxH): 130mm x 111mm TECHNICAL SUPPORT: For Technical Support for any Xvision product please contact your local distributor. LIMITED WARRANTY: This product is supplied with a 3 Year warranty. The Warranty excludes products that have been misused, (including accidental damage) and damage caused by normal wear and tear. In the unlikely event that you encounter a problem with this product, it should be returned to the place of purchase.
