- Page 1 Mealstream EC501 USER GUIDE IMPORTANT INFORMATION READ BEFORE USE PLEASE SAVE THESE INSTRUCTIONS...
-
Page 2: Table Of Contents
CONTENTS Safety instructions ..........3 Electrical supply ..........3 Precautions ............4 Installation instructions ........5 Suitable cooking utensils ........6 Introduction ............8 Main features ............. 9 Control panel ........... 10 Operating instructions: Manual mode ........... 11 Programing number pads ....... 12 Running a Program ......... -
Page 3: Safety Instructions
This appliance must be earthed. Failure to do so may result in electric shock and death. The Mealstream EC501 ( 30A ) must be connected to a separate electrical supply rated at 30 Amps by a qualified and approved electrician. A suitable 30 amp rated isolating switch with a 3mm contact gap on both poles should be fitted for each oven installed. -
Page 4: Precautions
PRECAUTIONS TO BE OBSERVED Read this manual before using your oven. As with all electrical appliances, it wise to have the electrical connections inspected periodically. The oven interior, door seals should be cleaned frequently, following the instructions described in the CLEANING section. There is no need to switch off your oven after each function but remember to switch off at the end of the day or period of operation. -
Page 5: Installation Instructions
INSTALLATION Remove packing material and protective film from the oven. Check for obvious signs of transit damage. If necessary, inform the supplier IMMEDIATELY. Note: LOCATION AND POSITIONING The air intake is located under each side of the oven, Choose a site away from major heat sources. even with the clearance DO NOT position so that hot air is drawn in from fryers, grills, griddles, specified below it is... -
Page 6: Suitable Cooking Utensils
SUITABLE COOKING UTENSILS Manufacturer’s instructions should be checked to determine the suitability of individual containers or utensils using each of the cooking functions. The following chart provides general guidelines: Heat resistant containers Toughened glass Do not use items with metallic Vitreous ceramics decoration. - Page 7 THE USE OF METALLIC ITEMS IN COMBINATION AND MICROWAVE ONLY FUNCTIONS Some of the interior panels in Mealstream 501 ovens are vitreous enamel which acts as an insulator and allows safe use of metal in controlled conditions. (The vitreous enamel tray supplied can be upturned and used as a permanent base.) Position large metal pans and trays centrally in the oven at least 40mm ( 1.5 inches ) from side walls.
-
Page 8: Introduction
Multi-Stage Programming The Mealstream EC501 offers even greater flexibility by allowing multi-stage programming. This enables the exact conditions required for quality results to be set according to the food type. -
Page 9: Main Features
Found on the rear panel, this states the serial obstruction. number, model type, electrical specifications and OVEN CAVITY Merrychef address and telephone number. The cavity is constructed mainly from stainless steel DOOR and vitreous enamelled panel on the door. It must This is a precision-made energy barrier with three be kept clean see CLEANING). -
Page 10: Control Panel
CONTROL PANEL MULTI-STAGE INDICATOR PROGRAM PAD TIME/ERROR DISPLAY CANCEL PAD TEMPERATURE SETTING PADS POWER PADS CONVECTION PAD TIME/PROGRAM SELECT PADS COLON TIME/ERROR DISPLAY POWER PADS CANCEL/ CALLBACK ‘C’ PAD Cancels all timed cooking cycles, pre-programmed operations There are 4 Microwave Power Pads to select from: 25%, 50%, 75%, and 100%. -
Page 11: Operating Instructions
OPERATING INSTRUCTIONS: MANUAL MODE The oven can be operated in WARNING: manual or programmed mode. It DO NOT APPLY MICROWAVE ENERGY WHEN OVEN IS EMPTY is important to understand manual mode prior to attempting DO NOT USE THE OVEN WITHOUT program operation. -
Page 12: Programing Number Pads
PROGRAMMING NUMBER PADS ( 0-9 ) Pre-programming allows repetitive cooking procedures to be stored for ease of use. Each program can comprise up to three stages, allowing at each independent An amount of experimentation control of Convection temperature, Stage time and Microwave power level. will be required to determine However, programs must be used with caution since if the food to cook the correct program for a... -
Page 13: Running A Program
RUNNING A PROGRAM Using number pad keys to run a programme Programs 0 to 9 can be recalled using the number pad keys. The following procedure should be used to activate these programs. Pre-heat the oven to the required starting temperature by pressing a TEMPERATURE SETTING PAD. -
Page 14: Manual Controls ( Rd501 Models )
MANUAL CONTROLS ( MODEL RD501 ) Switch on oven. Set required oven temperature by turning the temperature control dial clockwise. The convection temperature indicator will illuminate until the set temperature is achieved. For best results, wait for this to happen. The indicator will go on and off as temperaturre within the oven is maintained. -
Page 15: Daily Cleaning
CLEANING For the oven to operate at peak efficiency, the cavity, door and air filters must be kept clean. A daily cleaning routine will ensure that you comply with the required hygiene standards and will help to maintain and prolong the efficiency of your oven. Follow the SAFETY INSTRUCTIONS at the beginning of this manual. -
Page 16: Problem Solving
PROBLEM SOLVING Error code display The Mealstream EC501 will identify some of the most common problems by flashing an error message code in the time display window. Error code display Fault Recommended action Door not fully shut. Close door fully. -
Page 17: Service Contact Details
Unless this card is received, the terms of the guarantee will commence from the date of despatch from the manufacturer and NOT from the date of purchase. If, after referring to the PROBLEM SOLVING section, you need a service engineer, telephone the Merrychef Service Control Centre.
