- Page 1 WG 10”/12” Series 10.4”/12.1” Multifunctional Touch Panel PC Quick Reference Guide Copyright Notice Copyright © 2007-2009 Technology Inc., ALL RIGHTS RESERVED. Part No. E20171203A0R...
-
Page 2: Table Of Contents
1.4.1 Front View..........................8 1.4.2 Rear View ..........................8 1.5 System Dimensions ....................9 1.5.1 WG-1201/1203 Front side and rear..................9 1.5.2 -1001/1003 Front side and rear..................10 1.5.3 Bottom and Rear ........................11 Hardware Configuration ..................12 2.1 Jumper and Connector Setting , Driver and BIOS Installing ........13 2.2 Installing Hard Disk &... -
Page 3: Getting Started
Quick Reference Guide 1. Getting Started 1.1 Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. -
Page 4: System Specifications
WG 10”/12” Series 1.3 System Specifications Panel WG-1201 WG-1001 Model 12.1”, 4:3 10.4”, 4:3 LCD size Display type SVGA SVGA Resolution 800 x 600 1024 x 768 800 x 600 1024 x 768 Color 262K 262K 262K 262K 0.3075mm(H) x 0.240mm(H) x... - Page 5 Quick Reference Guide External I/O Ports COM Port 1 x RS-232 Dual RTL8110SC Giga LAN Ethernet Port 1 x DB-15 VGA / LCD Port Line-out Audio Port USB Port 2 x USB 2.0 Power Supply Unit Power Input Power Output 5A (60W) Environment &...
- Page 6 WG 10”/12” Series Panel WG-1203 WG-1003 Model 12.1”, 4:3 10.4”, 4:3 LCD size SVGA SVGA Display type 800 x 600 1024 x 768 800 x 600 1024 x 768 Resolution Color 262K 262K 262K 262K 0.3075mm(H) x 0.240mm(H) x 0.264mm(H) x 0.20625mm(H) x Pixel pitch 0.3075mm(V)
- Page 7 Quick Reference Guide External I/O Ports COM Port 1 x RS-232/422/485 setting by BIOS*, optional extra 1 x RS-232/422/485 Dual RTL8111C Giga LAN Ethernet Port 1 x DB-15 VGA / LCD Port Line-out Audio Port USB Port 2 x USB 2.0 Power Supply Unit Power Input Power Output...
-
Page 8: System Overview
WG 10”/12” Series 1.4 System Overview 1.4.1 Front View 1.4.2 Rear View POWER Connectors Label Function Note POWER Power on button CF Type I/II Socket with Ejector Optional for 2 COM port Serial port DB-9 male connector Line-out audio jack LINE OUT 2 x USB 2.0 connector Dock USB... -
Page 9: System Dimensions
Quick Reference Guide 1.5 System Dimensions 1.5.1 WG-1201/1203 Front side and rear WG 10”/12” Series Quick Reference Guide... -
Page 10: Wg-1001/1003 Front Side And Rear
WG 10”/12” Series 1.5.2 WG-1001/1003 Front side and rear (Unit: mm) 10 WG 10”/12” Series Quick Reference Guide... -
Page 11: Bottom And Rear
Quick Reference Guide 1.5.3 Bottom and Rear M3*3 Note: The M3*3 screw holes are reserved for WG Series Panel Mount Brackets. Improper usage may harm the mechanical parts. WG 10”/12” Series Quick Reference Guide 11... -
Page 12: Hardware Configuration
WG 10”/12” Series 2. Hardware Configuration 12 WG 10”/12” Series Quick Reference Guide... -
Page 13: Jumper And Connector Setting , Driver And Bios Installing
Quick Reference Guide 2.1 Jumper and Connector Setting , Driver and BIOS Installing 2.1.1 WG-1003/1203 RS232/422/485 setting by BIOS The COM port setting of WG-1003/1203, which applying EBM-945GSE M/B, can be configured by BIOS. The path is shown as below. [BIOS Menu] [Integrated Peripherals] [Super IO Device]... -
Page 14: Installing Hard Disk & Memory
WG 10”/12” Series 2.2 Installing Hard Disk & Memory Step 1. Unfasten 6 screws from the case. Then take off the top chassis. Step 2. Insert the SODIMM into the memory socket. 14 WG 10”/12” Series Quick Reference Guide... - Page 15 Quick Reference Guide Step 3-1. HDD Installation: Insert the cable to connect the HDD and the SATA connecter. SATA Connector IDE Connector Step 3-2. SATA HDD Installation: By default, the SATA cables had been inserted to the according connectors. Just connect to SATA HDD with the two cables. WG 10”/12”...
- Page 16 WG 10”/12” Series Step 3-3. Insert the HDD into the Drive Bay. Remember to place the HDD down to the bottom exactly in order to screw the device tightly. Step 4. Place back the chassis with 6 screws locked. 16 WG 10”/12” Series Quick Reference Guide...
